Vehicle connections

The connection information listed below is specific to the 2016 Mazda CX-5 (Smart Key). Refer to "Pre-installation and application warnings" for a list of important notes.
Data harness, 8-pin white connector (H1)
Module
Conn./Pin Color Description
H1/1 Tan (Data) HS CAN Low
H1/2 Tan/Black (Data) HS CAN High
H1/3 Orange/Brown No Connection
H1/4 Orange/Green No Connection
H1/5 Lt. Green No Connection
H1/6 Violet/Brown (MUX) Lock Output
H1/7 Orange/Black (Data) Keyless Data
H1/8 Yellow/Black No Connection
Analog input/output harness, 22-pin white connector (H2)
Module
Conn./Pin Color Description
H2/1 Lt. Green/Black
(-) Pk Light Output
H2/2 Blue/White No connection
H2/3 Dk. Green/Black (-) Ground When Armed (GWA) Output
H2/4 Red/White (-) Trunk Output
H2/5 Brown/Black (-) Horn Output
H2/6 Brown/White No Connection
H2/7 White (+) No connection
H2/8 Violet/Black (+) Accessory Output
H2/9 Dk. Blue/Black
(-) Ignition Interrupt Output
H2/10 Lt. Blue/Black (-) PTS Output
H2/11 Brown/Red
(+) Siren Output
H2/12 Pink No Connection
10 933.MA3 2.41.198.9 2016 Mazda CX-5 (Smart Key)
©2023 VOXX•DEI LLC. All rights reserved.
Connects To
Wire Location
Start Stop Unit in steering column, white 24 pin plug, pin 8
Start Stop Unit in steering column, white 24 pin plug, pin 7
No Connection
No Connection
No Connection
No Connection
Start Stop Unit in steering column, white 32 pin plug, pin 9
No Connection
Connects To
Wire Location
[4] Parking Light Switch Assembly inside steering column, white 6 pin plug,
pin 3
Connection required when not supported in data.
No Connection
Starter:
Start Stop Unit in steering column, white 24 pin plug, pin 23
Ignition:
Start Stop Unit in steering column, white 24 pin plug, pin 10
Must use a relay.
Must use a 1N4002 diode or larger.
No Connection
Horn Switch-Clock Spring, white 14 pin plug, pin 1
No Connection
No Connection
Start Stop Unit in steering column, white 24 pin plug, pin 14
[3] Must use a relay.
Must use a 1N4002 diode or larger.
10A fuse to 12V.
Start Stop Unit in steering column, white 32 pin plug, pin 17
Connection required to retain vehicle takeover and OEM remote
functionality during remote start runtime.
Start Stop Unit in steering column, white 32 pin plug, pin 20
[2] Only required when enabling the security features during module
flashing.
No Connection
(+/-) Wire Color Connection
Data Red/Yellow (HS CAN) Mandatory
Data White/Black (HS CAN) Mandatory
Data Green/Orange Mandatory
(+/-) Wire Color Connection
- Yellow Optional
+ Brown/Black Security Only
+ Lt. Green/Red
- Blue Optional
+ Brown/Red Mandatory
Cut Violet Remote Start
Only
- Lt. Green/Red Remote Start
Only
Security Only
