Pre-installation and application warnings

This section highlights important information for this specific firmware and will assist in pricing accordingly, as
START HERE
well as bringing awareness to any operational or vehicle limitations.
Compatibilities and Requirements
T-Harness
compatible
Vehicle Takeover
Firmware notes
Doors: To remote start the engine, the hood, hatch and all doors must be closed.
Š
Runtime: It is normal for the key symbol to flash during remote start runtime.
Š
Caution: In these vehicles, the factory keyless entry module is sensitive to interference and may cease to operate without notice.
Š
Ensure you disconnect the (-) terminal of the battery prior to disconnecting and reconnecting the connectors at the start/stop module
below the steering wheel to avoid damage to the keyless entry module.
T-Harness (THMAN1):
Š
•All T-Harness wires not listed in the diagram are not required for the installation. Loose wires such as Siren Output and
Hood Input may need to be pulled from the tapped section of the T-harness. Refer to the "wiring diagram with T-Harness"
for more information on connections and installation instructions.
•The optional Plug & Play THMAN1 T-Harness is sold separately.
•All T-Harness wires not listed in the diagram are not required for the installation.
Fuses: It is important to check that the fuses are positioned correctly in the module. Proper fuse positioning is displayed
Š
on each wiring diagram.
Š Unless specified otherwise, all connectors are displayed from the wire side.
Š Refer to the Vehicle connections section following the installation diagram.
Footnotes
[1] Hood pin: The installation of an aftermarket hood pin is only required on vehicles that are not equipped with a factory hood pin or if
not supported in data.
[2] Siren: Only required when enabling the security features during module flashing.
[3] Runtime: Connection required to retain vehicle takeover and OEM remote functionality during remote start runtime.
[4] Parking lights: Connection required when not supported in data. See the Locating components in the vehicle section for more
information about accessing the parking wiring.
5
933.MA3 2.41.198.9 2016 Mazda CX-5 (Smart Key)
©2023 VOXX•DEI LLC. All rights reserved.
THMAN1
Refer to the Quick Reference Guide section for more details.
Keys required for 1 Keys required
programming for operation
