Directed DS3+ Installation Manual page 11

Module
Conn./Pin Color Description
H2/13 Violet No Connection
H2/14 Brown No Connection
H2/15 White/Blue No Connection
H2/16 Red/Blue No Connection
H2/17 Black/White No Connection
H2/18 Orange/Black (+) Trunk Input
H2/19 Blue No Connection
H2/20 Green No Connection
H2/21 Gray
(-) Hood Switch Input
H2/22 Violet/White No Connection
Main harness, 12-pin black connector (H3)
Module
Conn./Pin Color Description
H3/1 Blue/White
Relay N.C. - Parking Light Interrupt (vehicle side)
H3/2 Blue/Red Relay N.O. No Connection
H3/3 Blue Relay COM - Parking Light Interrupt (connector side)
[4]
H3/4 White/Brown Relay N.C. - No Connection
H3/5 White Relay COM - (+) Starter Output
H3/6 Red (+) 12 Volt Input
H3/7 Lt. Green/Red Relay N.O. - (+)12V Input
H3/8 Lt. Green Relay COM - (+) Ignition Output
H3/9 Lt. Green/White Relay N.C. - No Connection
H3/10 Black (-) Ground
H3/11 White Relay COM - (+) Starter Output
H3/12 Red (+) 12 Volt Input
Relay harness, 10-pin white connector (H4)
Module
Conn./Pin Color Description
H4/1 N/A No Connection
11 933.MA3 2.41.198.9 2016 Mazda CX-5 (Smart Key)
©2023 VOXX•DEI LLC. All rights reserved.
Connects To
Wire Location
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
No Connection
[1] The installation of an aftermarket hood pin is only required on vehicles
that are not equipped with a factory hood pin or if not supported in
data.
No Connection
Connects To
Wire Location
[4] Parking Light Switch Assembly inside steering column, white 6 pin plug,
pin 4
Connection required when not supported in data.
No Connection
Parking Light Switch Assembly inside steering column, white 6 pin plug,
pin 4
Connection required when not supported in data.
No Connection
Start Stop Unit in steering column, white 24 pin plug, pin 23
Driver Kick Fuse Box, rear, white 1 pin plug, pin 1
Driver Kick Fuse Box, rear, white 1 pin plug, pin 1
Start Stop Unit in steering column, white 24 pin plug, pin 10
No Connection
Start Stop Unit in steering column, white 24 pin plug, pin 23
Driver Kick Fuse Box, rear, white 1 pin plug, pin 1
Connects To
Wire Location
No Connection
(+/-) Wire Color Connection
(+/-) Wire Color Connection
Cut Green Remote Start
Only
Cut Green Optional
+ Brown/Black Remote Start
Only
+ White (50A) Mandatory
+ White (50A) Remote Start
Only
+ Lt. Green/Red Remote Start
Only
(chassis ground) Mandatory
+ Brown/Black Remote Start
Only
+ White (50A) Mandatory
(+/-) Wire Color Connection
