Locating components in the vehicle

Accessing the parking light circuit
8
933.MA3 2.41.198.9 2016 Mazda CX-5 (Smart Key)
©2023 VOXX•DEI LLC. All rights reserved.
1. Grab parking light handle and pull in the direction of the arrow.
2. Push the clip to remove the parking light switch.
3. Remove the white cover to expose the connector.
4.Access the parking light connector and wire.
