B.5. Setting Parameters Registers for Data Request
Parameter
Main Parameters
Starter Current
Motor Current
Line/Delta Configuration
Undercurrent_FLT
Undercurrent_DLY
O/C JAM Fault
O/C JAM Delay
Overload_Class
Overload_Protect
Undervoltage_FLT
UnderVoltage_DLY
Overvoltage_FLT
Overvoltage_DLY
Reserved
Start Settings
Soft Start Curve
Kickstart Time
Starting Voltage/Current
Current Limit
Ramp UP Time
Max. Start Time
Number of Starts
Duty Cycle Time
Start_Lockout
EOR Relay Delay
Reserved
Stop Settings
Soft Stop Curve
Ramp DOWN Time
End Torque
Reserved
Dual Settings
Starting VOLT-2
Current Limit-2
Ramp UP-2
Ramp DOWN-2
Motor Current-2
Reserved
Slow SP & Saving Parameters
Energy Saving
Slow Sp eed TRQ.
Max_Slow_SP_Time
Reserved
Fault Settings
Phase Loss
Phase Sequence
Auto Reset
• Appendix B - Profibus
106
#
Range
0
8..1400
1
4..1750
2
0 (Line), 1 (Inside Delta)
3
0..90 (% of FLA)
4
1..40
5
200..850 (% of FLA)
6
0..50
7
75..150
8
1..10
9
120..600
10
1..10
11
150..750
12
1..10
14..23
24
0..10 (5..9 are reserved)
25
0..10 (Tenth Seconds)
26
10..80
27
100..500
28
1..90
29
1..250
30
1..10 & (11 = OFF)
31
1..60
32
1..60
33
0..40
35..39
40
0..10 (5..9 are reserved)
41
1..30
42
0..10
43..47
48
10..80 % of full voltage
49
100..500
50
1..90
51
1..30
52
5..1400
53..55
56
1..10
57
1..10
58
1..250
59..62
63
0..1
64
0..1
65
0 / 1 (0 - No, 1 - Yes)
Default
58 (Amp.)
58 (Amp.)
0 (Line)
0 (% of FLA)
10 (Seconds)
850 (% of FLA)
5 (0.5 Sec.)
115 (% of FLA)
4 (Seconds)
300 (Volt)
5 (Seconds)
480 (Volt)
2 (Seconds)
0 (Standard).
0 (No Pulse)
30 (% of full
voltage)
400 (% of FLA)
10 (Seconds)
30 (Seconds)
10
30 (Minutes)
15 (Minutes)
5 (Seconds)
0 (Standard)
10 (Seconds)
0 (Minimum)
30
400 % of FLA
10 (Seconds)
10 (Seconds)
31 (Amp.)
0
8
30 (Seconds)
0 (No)
0 (No)
1 (No)
