Comm. Parameters
4.7.11
Function &
Default
COMM. PROTOCOL
DeviceNet
Baud Rate
Set Manually
Parity Check
AUTO (DeviceNet)
DeviceNet ID
Set Manually
S. Link Par. Set
Disabled
Ser. Link Control
Disabled
Store Settings
COMM. Parameters
• Control Keypad
43
– Page 8 – With the DeviceNet Optional PCB
42
Range Unit
Profibus/
Modbus/
DeviceNet
Enabled/
Disabled
Enabled/
Disabled
Enabled/
Disabled
Description
Sets ASTAT-XT's communication protocol.
Operational when the optional communication PCB is
installed.
Set the Baud Rate by changing the position of the
rotary switches on the optional PCB as shown on section
C.1.5 page 109.
User can not change Parity Check value.
Set the unit ID by changing the position of the rotary
switches on the optional PCB as shown on section C.1.5
page 109.
Enables parameter modification via serial
communication
Enables start, stop, reset etc. via serial communication
Same as Store Settings Main Settings on
page 28.
Note:
After changing communication parameters and storing
them, control power must be switched OFF and ON to
load new communication parameters.
