16
Only in Max. Mode Only in Max. Mode
Slow SP & Saving
Fault Settings
Parameters
Function & Default Function & Default
Energy Saving Phase Loss
0 (MIN) Enabled
Slow Speed TRQ. Phase Sequence
8 Disabled
Max Slow SP Time Auto Reset
30 SEC. Disabled
Store Settings Thermistor Type
Slow SP & Saving PTC
Thermistor Trip
Disabled
Undercurrent RST
Disabled
Store Settings
Fault Settings
Appears when in
Test/Maintenance
Test/Maintenance
***Statistics***
Display and default
values
Auto Test
Press UP Key
Firmware Version
STRT-GE-270508
Store Settings
Default Data
Reset Statistics
Calibration VOLT
0 VOLT
Calibration CURR
5% of Ir
Note: There are three different groups of COMM. Protocol parameters. Each group of COMM. Protocol parameters
are only valid when its corresponding optional PCB is installed.
25
16
Only in Max. Mode
I/O Settings
- **** - Parameters
Function & Default
PROG. Input #7
Reset
PROG. Input #8
Dual Settings
PROG. Fault Relay
At Fault Close
Relay ON Delay
0 SEC.
Relay OFF Delay
0 SEC.
Analog Output
I, 0...200% OF Im
Store Settings
I/O Settings
• Control Keypad
16
Only in Max. Mode
COMM. Parameters
- **** -
Function & Default
COMM. Protocol
Modbus
Baud Rate
9600 (MODBUS)
Parity Check
EVEN
Station Number.
OFF
S. Link Par. Set
DISABLED
Ser. Link Control
DISABLE
Store Settings
COMM. Parameters
COMM. Protocol
Profibus
Baud Rate
AUTO (Profibus)
Parity Check
AUTO (Profibus)
PROFI. Network ID
OFF
S. Link Par. Set
Disabled
Ser. Link Control
Disabled
Store Settings
COMM. Parameters
COMM. Protocol
DeviceNet
Baud Rate
Set Manually
Parity Check
AUTO (DeviceNet)
DeviceNet ID
Set Manually
S. Link Par. Set
Disabled
Ser. Link Control
Disabled
Store Settings
COMM. Parameters
16
Statistical Data
- **** -
Function & Default
Last Start Time
No Data
Last Start Curr.
No Data
Elapsed Run Time
0 Hours
Number Of Starts
0
Last Fault
No Data
Motor FLT Current
0 % of Im
Fault Counter
0
Previous Fault -1
No Data
PREVIOUS Fault -9
No Data
