GE ASTAT XT QT 0008U Series User Manual page 118

Attribute
ID
25
26-45
C.10.3. Common Services
Service
Code
0E
HEX
C.11. Main Parameter Object (71
C.11.1. Class Attributes (Instance 0)
Attribute
ID
1
C.11.2. Instance Attributes (Instance 1)
Attribute
ID
1
2
3
4
5
6
7
8
9
10
11
12
13
• Appendix C - DeviceNet™ to Modbus™ Gateway
118
Name Description
09: Shorted SCR.
10: Long Start Time
11: Slow Speed Time
12: Reserved
13: External Fault
14: Wrong Parameters
15: EMI/RFI Fault
16: Too Many Starts
17: Reserved.
18: Thermistor.
19: Frequency.
Motor Fault Current at trip time (Amp)
Current
Actual_Data_Grou 20 actual parameters selected
p by Setting Parameters 90-109
Implemented for
Class Level
Yes
1 Instance)
HEX –
Name
Revision
Name
Starter Current
Motor Current
Line/Delta
Configuration
Undercurrent FLT
Undercurrent DLY
O/C JAM Fault
O/C JAM Delay
Overload Class
Overload Protect
Under voltage FLT
Under voltage DLY
Over voltage FLT
Over voltage DLY
Service Name
Instance Level
Yes Get Attribute Single
DeviceNet
Data Type
UINT
Range Default
Value
8-1400 58
(Amps)
4-1750 58
(Amps)
0 – Line 0
1 – Inside
Delta
0-90 (% of 0
Im)
1-40 (Sec) 10
200-850 400
(% of Im)
0-50 5
(0.5 Sec.)
75-150 115
(% of Im)
1-10 (Sec.) 4
120-600 300
(Volt)
1-10 (Sec) 5
250-750 400
(Volt)
1-10 (Sec) 2
Access Modbus
Rule Address
Get 40281
Get 40365-
40384
Data Value Access
Rule
1 Get
Access Modbus
Rule Address
Get/Set 40001
Get/Set 40002
Get/Set 40003
Get/Set 40004
Get/Set 40005
Get/Set 40006
Get/Set 40007
Get/Set 40008
Get/Set 40009
Get/Set 40010
Get/Set 40011
Get/Set 40012
Get/Set 40013
