Calibrate Voltage And Current (Factory Use Only!); Mode - GE ASTAT XT QT 0008U Series User Manual

Solid state soft starter
Table of Contents

Advertisement

Press the Mode and go back to:
Motor Current
0

Calibrate Voltage and Current (Factory Use Only!)

4.5.5
Press the Mode and ▼ keys simultaneously. The LCD will display:
Test/Maintenance
Statistics
Press the Select key five times. The LCD will display:
Calibration VOLT
0 VOLT
Press the Select key. The LCD will display:
Calibration CURR
5% of Ir
Press the Mode and ▼ keys simultaneously to exit the Test/Maintenance mode.
Mode Pages
4.6
Upon initiation of the ASTAT-XT, the LCD displays motor's operating current:
Motor Current
0
You can review all mode pages by pressing the Mode key:
Main Settings
- **** -
Start Settings
- **** -
Stop Settings
- ****
-
DUAL Settings
Parameters
Slow SP & Saving
Parameters
Fault Settings
- **** -
I/O Settings
Parameters
COMM. Parameters
- **** -
Statistical Data
- **** -
• Control Keypad
23
These pages are skipped if ASTAT-XT is programmed to Minimized
Mode and are shown only in Maximized Mode. Refer to section 5.5.1
on page 49 for changing mode from Minimized Mode to Maximized

Mode.
