Parameter
Thermistor Type
Thermistor Trip
Undercurrent RST
Reserved
I/O Settings
Prog. Input #7
Prog. Input #8
Prog. Fault Relay
Relay ON Delay
Realy OFF Delay
Analog Output
Reserved
Communication Parameters
COMM. Protocol
Baud Rate
Parity Check
Station Number
S. Link Par. Set
S. Link Control
Reserved
Modbus_#_Array
• Appendix B - Profibus
107
# Range
66 0 / 1 (0 - PTC, 1 - NTC)
67 0..100 Tenth Kohm 0.1..10 K
68 10..120 (&121=OFF)
69..71
72 0..2(0=En.Save,1=S.Spd,2=Rst)
73 0..2(0=D.Adj.,1=Rvrs,2=Rst)
74 0..1 (0=Fault, 1=Fault-Fail Safe)
75 0..3600
76 0..3600
77 0- Current, 0..200% of motor FLA
78
80 0 – Modbus, 1-Profibus
81 12..96 (*100)
82 0/1/2 (Even / Odd / No)
83 1..247 & (248= Off)
1..126 & (127= Off) for Profibus
84 0 (Disable), 1 (Enable)
85 0 (Disable), 1 (Enable)
86..88
89..108 (# of parameter)
Defaults # are:
1 - Logic Status, 2 - I, 3 - V, 5 - Control In, 11 –
Thermistor Resistance, 37 - Thermal Capacity, 10 -
frequency, 4 - Phase Sequence, 6 - Dip Switch, 18
- Total Run Time, 19 - Total Starts, 20 - Last Start
Period, 21 - Last Start Peak I, 22 - time to start, 23
- Total Trips, 24 - last trip Number, 25 - Pre Trip I,
26 - Time to Reset U/C, 39 - Spare, 40 – Spare
Default
0 (PTC)
0 (Off)
121 (Off)
0 (Energy
Saver)
0 (Dual Adjust)
0 (Fault)
0 (Seconds)
0 (Seconds)
0 (Current)
1 - Profibus
96 (9600 bps)
0 (Even)
248 (Off)
0 (Disable)
0 (Disable)
