Display Mode

4.7.1
Function &
Default
A
Motor Current
0
V
Line Voltage
0 Volt
Kohm
Thermistor Input
3.1 Kohm
Displays in MINIMIZED MODE and MAXIMIZED MODE.
17
Parameters cannot be programmed in page 0.
18
26
– Page 0
17 18
Unit
Displays operating current of the motor.
ASTAT-XT's Default Display. After pressing the Mode or Select keys, a time
delay is initiated. Following the delay the LCD returns to display Motor
Current.
If current is lower than 0.1 of the rated current of the ASTAT-XT, the display
will show: I < 0.1 Ir
Displays the mains voltage.
Displays the resistance level of the motor's thermistor.
