GE ASTAT XT QT 0008U Series User Manual page 105

Number Parameter Name
25 Motor Fault Current
37 Thermal Capacity
109 Actual_Data_Group_1
110 Actual_Data_Group_2
111 Actual_Data_Group_3
112 Actual_Data_Group_4
113 Actual_Data_Group_5
114 Actual_Data_Group_6
115 Actual_Data_Group_7
116 Actual_Data_Group_8
117 Actual_Data_Group_9
118 Actual_Data_Group_10
119 Actual_Data_Group_11
120 Actual_Data_Group_12
121 Actual_Data_Group_13
122 Actual_Data_Group_14
123 Actual_Data_Group_15
124 Actual_Data_Group_16
125 Actual_Data_Group_17
126 Actual_Data_Group_18
127 Actual_Data_Group_19
128 Actual_Data_Group_20
• Appendix B - Profibus
105
Description
12: Reserved
13: External Fault
14: Wrong Parameters
15: EMI/RFI Fault
16: Reserved
17: Reserved
18: Thermistor.
19: Frequency.
Current at trip time, Amp.
Simulated winding temperature, %. 100% = trip
Group of 20 actual parameters selected by setting
parameters 90..109.
Group of 20 actual parameters selected by setting
parameters 90..109.
Group of 20 actual parameters selected by setting
parameters 90..109.
Group of 20 actual parameters selected by setting
parameters 90..109.
Group of 20 actual parameters selected by setting
parameters 90..109.
Group of 20 actual parameters selected by setting
parameters 90..109.
Group of 20 actual parameters selected by setting
parameters 90..109.
Group of 20 actual parameters selected by setting
parameters 90..109.
Group of 20 actual parameters selected by setting
parameters 90..109.
Group of 20 actual parameters selected by setting
parameters 90..109.
Group of 20 actual parameters selected by setting
parameters 90..109.
Group of 20 actual parameters selected by setting
parameters 90..109.
Group of 20 actual parameters selected by setting
parameters 90..109.
Group of 20 actual parameters selected by setting
parameters 90..109.
Group of 20 actual parameters selected by setting
parameters 90..109.
Group of 20 actual parameters selected by setting
parameters 90..109.
Group of 20 actual parameters selected by setting
parameters 90..109.
Group of 20 actual parameters selected by setting
parameters 90..109.
Group of 20 actual parameters selected by setting
parameters 90..109.
Group of 20 actual parameters selected by setting
parameters 90..109.
