NEMA Ratings
2.2
4
Light Duty
Nema 10
Current 230V 460V
rating
5
A HP HP
8 2 5
17 5 10
34 10 25
54 20 40
65 20 50
72 25 50
104 40 75
130 50 100
156 60 125
170 60 125
262 100 200
387 150 300
414 150 350
480 200 400
610 250 500
820
Note:
Select the appropriate ASTAT-XT, according to the main power supply and motor voltage rating.
Use QT1xxxxUxxxx units for power supply and motors rated at 230V-500V
Use QT2xxxxUxxxx units for power supply and motors rated at 460V-600V
Ratings in Amps. given for ambient temperature up to 40°C and 1000m altitude.
4
For higher ambient temperature between 40°C and 50°C, derate the current by 2.5% for each °C that is above 40°C.
Light duty ratings, only NEMA Class 10 protection is allowed.
5
Normal duty ratings, NEMA Class 10 and 20 protections are allowed.
6
Heavy duty ratings, NEMA Class 10, 20 and 30 protections are allowed
7
. Recommended Motor and Type Unit Ratings.
Normal Duty
Nema 20
575V Current 230V
rating
6
HP A HP
5 8 2
15 17 5
30 31 10
50 44 15
60 58 20
60 72 25
100 85 30
125 105 40
150 145 50
150 170 60
250 210 75
400 310 100
400 390 150
500 460 150
580 200
820 250
• Types and Ratings
9
Heavy Duty
Nema 30
460V 575V Current
rating
7
HP HP A
5 5 8
10 15 12
20 25 31
30 40 44
40 50 55
50 60 66
60 75 80
75 100 99
100 150 130
125 150 134
150 200 203
250 300 310
300 400 361
350 400 432
400 400 552
500 500 690
Type Unit
230V 460V 575V
HP HP HP
2 5 5 QTx0008Uxxxx
3 7.5 10 QTx0017Uxxxx
10 20 25 QTx0031Uxxxx
15 30 40 QTx0044Uxxxx
20 40 50 QTx0058Uxxxx
20 50 60 QTx0072Uxxxx
30 60 75 QTx0085Uxxxx
40 75 100 QTx0105Uxxxx
50 100 125 QTx0145Uxxxx
50 100 125 QTx0170Uxxxx
75 150 200 QTx0210Uxxxx
100 250 300 QTx0310Uxxxx
150 300 300 QTx0390Uxxxx
150 350 400 QTx0460Uxxxx
200 400 500 QTx0580Uxxxx
250 500 QTx0820Uxxxx
