Parts List - Analog Devices DC2702B-B Demo Manual

PARTS LIST

ITEM QTY REFERENCE
Additional Demo Board Circuit Components
1 0 C1, C2, C14, C16, C17, C29, C31, C32
2 0 D1, D2
3 0 R3, R8, R26, R27, R61, R62, R64, R67,
R68, R74, R75, R83, R88, R89, R93
4 16 R9, R28, R29, R33, R35, R38, R41,
R63, R65, R66, R91, R92, R96-R99
5 5 R48, R100-R103
6 0 R49
7 0 R82
8 0 R104, R105
Hardware
1 26 E1-E26
2 3 JP1, JP2
3 1 J1
4 3 J2, J3, J4
5 6 J5-J10
6 12 J5-J10
7 6 J5-J10
8 6 J5-J10
9 1 J11
10 1 J12
11 4 MH1-MH4
12 3 XJP1, XJP2
DEMO MANUAL DC2702B-B
PART DESCRIPTION
CAP ., OPTION, 0603
DIODE, OPTION, SOD-323
RES., OPTION, 0603
RES., 0Ω, 1/10W, 0603, AEC-Q200
RES., 0Ω, 3/4W, 2010, AEC-Q200
RES., OPTION, 2010
RES., OPTION, 1206
RES., OPTION, 0805
TEST POINT, TURRET, 0.064", MTG. HOLE
CONN., HDR, MALE, 1mm × 3mm × 2mm,
VERT, STR, THT
CONN., SHROUDED HDR, MALE,
2 × 6, 2mm, VERT, STR, THT
CONN., RF , BNC, RCPT JACK,5-PIN, STR,
THT, 50Ω
STUD, FASTENER, #10-32s
NUT, HEX, STEEL, ZINC PLATE, 10-32
RING, LUG, CRIMP , #10, NONINSULATED,
SOLDERLESS TERMINALS
WASHER, FLAT, STEEL, ZINC PLATE, OD:
0.436 [11.1]
CONN., HDR, MALE, 2 × 7, 2mm, R/A THT
CONN., HDR, FEMALE, 2 × 7, 2mm, R/A THT
STANDOFF , NYLON, SNAP-ON, 0.50"
CONN., SHUNT, FEMALE, 2 POS, 2mm
MANUFACTURER/PART NUMBER
NIC, NRC06ZOTRF
VISHAY, CRCW06030000Z0EA
NIC, NRC50ZOTRF
PANASONIC, ERJ12ZY0R00U
VISHAY, CRCW20100000Z0EF
MILL-MAX, 2308-2-00-80-00-00-07-0
WURTH ELEKTRONIK, 62000311121
FCI, 98414-G06-12ULF
AMPHENOL RF , 112404
PENNENGINEERING, KFH-032-10ET
KEYSTONE, 4705
KEYSTONE, 8205
KEYSTONE, 4703
MOLEX, 0877601416
MOLEX, 877601416
SULLINS CONNECTOR SOLUTIONS,
NPPN072FJFN-RC
WURTH ELEKTRONIK, 702935000
WURTH ELEKTRONIK, 60800213421
Rev. 0
9
