Monitoring Network Intersite Links

Figure 5-10 Monitoring Network Sites Screen
Table 5-9 Information in the Monitoring Network Sites Screen
Column
Site Name
# of Calls
Bandwidth Used
Average Bit Rate
% Packet Loss
Average Jitter
Average Delay
You can view the status of links between sites in a video conferencing network.
Network intersite links consist of:
• Direct links between two sites in an H.323 network.
• Multisite links that use two or more direct links and include links to the
Internet.
Description
Name of the site as defined in Directory Services.
Number of calls occurring at a site.
Percentage of the maximum available bandwidth being
used by calls on the site.
Average bit rate for all calls on the site.
The percentage of packet loss, compared to the total
number of packets being sent over time.
The average jitter for all calls on the site.
The average delay for all calls on the site.
Device and Site Monitoring
5-15
