Gaind -- Set Gain Of Incoming Dtmf Tones; Gaindit -- Set Gain Of Incoming Dtmf Tones - Polycom Vortex EF2201 Command List

Example Description
T01GAINA6 Set phone input gain to 6 dB.
T01GAINA>3 Increase phone input gain by 3 dB.
T01GAINA? Query phone input gain.

8.29. GAIND -- Set Gain of Incoming DTMF Tones

This command sets the gain of the incoming DTMF tones. The gain of the outgoing DTMF depends on
the country that the Vortex is configured for (see the COUNTRY) command. This command is an alias
for the command. It is provided for backwards compatibility with and ease of migration from
GAINDIT
the EF200. When possible, the
This command is an integer command. See
The minimum and maximum values for this command are -20 and 20, respectively.
This command is saved to non-volatile memory only as part of a preset. The state of this command will
be restored after power-up only if a preset is saved and that preset is set to be the power-on preset.
Example Description
T01GAIND6 Set incoming DTMF gain to 6 dB.
T01GAIND>3 Increase incoming DTMF gain by 3 dB.
T01GAIND? Query incoming DTMF gain.

8.30. GAINDIT -- Set Gain of Incoming DTMF Tones

This command sets the gain of the incoming DTMF tones. The gain of the outgoing DTMF depends on
the country that the Vortex is configured for (see the COUNTRY) command.
This command is an integer command. See
The minimum and maximum values for this command are -20 and 20, respectively.
This command is saved to non-volatile memory only as part of a preset. The state of this command will
Status Message
T01GAINA6
T01GAINAx, where x is the new value of the
phone input gain. If this command was issued after
the example above, then the status message would
be T01GAINA9.
T01GAINAx, where x is the new value of the
phone input gain. If this command was issued after
the example above, then the status message would
be T01GAINA9.
command should be used instead of this command.
GAINDIT
Section 6.2
Section 6.2
for more information on this type of command.
Status Message
T01GAIND6
T01GAINDx, where x is the new value of the
incoming DTMF gain. If this command was
issued after the example above, then the status
message would be T01GAIND9.
T01GAINDx, where x is the new value of the
incoming DTMF gain. If this command was
issued after the example above, then the status
message would be T01GAIND9.
for more information on this type of command.
