USING THE EVALUATION BOARD

POWER SUPPLY

Power can be supplied to the EVAL-ADAU1850EBZ in one of three
ways:
Connecting the USB cable to P1 (see
►
Connecting a 3.8 V to 5 V dc power to P3
►
Connecting an isolated external power supply to P7 for AVDD,
►
P8 for IOVDD, and P9 for HPVDD_L
If using a 5 V power supply, the on-board regulator generates the
1.8 V, 3.3 V, and 1.3 V dc supplies. The 1.3 V dc supply from
U1 can be adjusted by changing the values of R29 and R30. For
detailed power supply and jumpers, refer to
the default SPI communication on board, the IOVDD supply can
only be jumped to 3.3 V.
Table 1. Power Supply Jumper Settings
Source Jumpers
AVDD_1850 JP1
HPVDDL_1850 JP3
IOVDD JP17
IOVDD_1850 JP11 from IOVDD JP11 from IOVDD JP11 from IOVDD

CONTROL PORT

The EVAL-ADAU1850EBZ is configured to SPI mode by default.
2
To operate the codec in I C or universal asynchronous receiv-
er/transmitter (UART) mode, R10 to R14 are recommended to be
uninstalled. By default, these resistors are connected. For detailed
connection and jumpers on P2 and JP16, refer to
Table 2. Control Port Settings
Test
P2 Pin Name Point
1 SCL/SCLK TP16
3 ADDR1/MOSI/RX TP17
5 SDA/MISO/TX TP18
7 ADDR0/SS TP19

CODEC SYSTEM

Clock Option
The EVAL-ADAU1850EBZ has three options for providing a master
clock to the ADAU1850. The first option is to provide an external
MCLK signal directly to the CLKIN pin of the codec from P16 and
disable the on-board oscillator by placing a jumper on Header JP2.
The second option is to use the on-board 24.576 MHz oscillator.
These two options can be chosen through JP7. The third option is
to use the internal RC oscillator to generate a master clock where
JP2 needs to be jumped to disable the on-board oscillator.
analog.com
Figure 2)
Table 1. When using
Internal External
1.8 V P7
1.3 V P9
1.8 V or 3.3 V P8
Table 2.
JP16 JP16
Pull-Up Pull- Down
Pin 1 and Pin 2 Pin 2 and Pin 3
Pin 4 and Pin 5 Pin 5 and Pin 6
Pin 7 and Pin 8 Pin 8 and Pin 9
Pin 10 and Pin 11 Pin 11 and Pin 12
EVAL-ADAU1850
Power-Down
The EVAL-ADAU1850EBZ can power down all analog and digital
circuits of the codec in two ways: pressing the S1 button or placing
a jumper on the JP10 header.
Inputs and Outputs
The EVAL-ADAU1850EBZ has multiple audio input and output
options, including digital and analog. Three analog inputs are con-
figurable as microphone or line inputs. Two of these analog inputs
are differential or single-ended, and one is only single-ended. One
differential output can also be used in headphone or line output
mode.
For microphone signals, the two differential (ADC0 and ADC1)
ADAU1850 analog inputs can be configured as single-ended inputs
with an optional programmable gain amplifier (PGA) mode. But
the ADC2 can only be single-ended with an optional PGA mode.
The headphone output can be set as a line output driver or as a
headphone driver. In line output mode, the typical load is 10 kΩ. In
headphone output mode, the typical load is 16 Ω to 32 Ω.
Serial Audio Interface
2
Serial audio signals in I S, left justified, right justified, or time divi-
sion multiplexed (TDM) format are available via the P10 serial audio
interface header to connect an external I
device. The IOVDD logic level is 1.8 V or 3.3 V.
2
S- or TDM-compatible
Rev. A | 8 of 12
