Ordering Information; Bill Of Materials - Analog Devices EVAL-ADAU1850 User Manual

User Guide

ORDERING INFORMATION

BILL OF MATERIALS

Table 4.
Qty Reference Designator
5 C1, C2, C6, C8, C11
12 C3, C4, C9, C10, C12, C13, C14,
C15, C16, C17, C18, C26
1 C19
5 C20, C21, C22, C23, C24
4 C25, C27, C35, C37
3 C28, C36, C47
1 C30
1 C31
2 C32, C38
5 C34, C39, C41, C43, C45
1 C46
3 C40, C42, C44
2 C5, C7
2 D1, D2
2 E1, E2
2 L1, L2
1 P1
4 P4, P5, P6, P11
20 R1, R2, R9, R10, R11, R12, R13,
R16, R17, R18, R19, R20, R21,
R32, R33, R42, R44, R45, R46, R47
2 R3, R14
8 R15, R29, R31, R38, R41, R43,
R48, R49
5 R22, R24, R25, R26, R27
1 R23
1 R28
1 R30
6 R34, R35, R36, R37, R39, R40
1 R4
5 R5, R6, R7, R8, R50
1 U1
1 U2
1 U3
1 U4
1 U5
1 U6
1 Y1
1 Y2
analog.com
Description
4.7 µF, 25 V, 10%, X5R, 0603 ceramic capacitors
0.1 µF, 25 V, 10%, X7R, 0402, ceramic capacitors
10 µF, 25 V, 10%, X5R, 0603, ceramic capacitor
47 µF, 6.3 V, 10%, X7R, 1210, ceramic capacitors
2.2 µF, 25 V, 10%, X5R, 0603, ceramic capacitors
1 µF, 25 V, 10%, X7R, 0603, ceramic capacitors
0.01 µF, 25 V, 10%, X7R, 0402, ceramic capacitors
1 nF, 25 V, 10%, X7R, 0402, ceramic capacitors
1 µF, 6.3 V, 10%, X7R, 0402, ceramic capacitors
0.1 µF, 6.3 V, 10%, X5R, 0201, ceramic capacitors
Surface-mount device (SMD)/surface-mount technology
(SMT), 0201, 0.1 µF, 10 V, X5R, 10% multilayer ceramic
capacitor
10 µF, 6.3 V, 20%, X5R, 0402, ceramic capacitors
18 pF, 25 V, 5%, C0G, 0201, ceramic capacitors
Schottky diode barrier rectifier
Inductor, ferrite bead
Inductor, RF ceramic chip
Connector PCB, micro USB 2.0, right angle, 0.65 mm
pitch
Connector PCB, 3.5 mm, surface-mount audio jack
stereo
0 Ω jumper, 1/16 W, 0402
SMD, 1 kΩ, 1%, 1/10 W, 0402 resistors
SMD, 10 kΩ, 5%, 1/10 W, 0402 resistors
SMD 49.9 kΩ, 1%, 1/10 W, 0402 resistors
SMD 49.9 Ω, 1%, 1/10 W, 0402 resistor
SMD 475 Ω, 1%, 1/10 W, 0402 resistor
SMD 6.2 kΩ, 5%, 1/10 W, 0402 resistor
SMD 33 Ω, 1%, 1/10 W, 0402 resistors
SMD 12 kΩ 1%, 1/16 W, 0402 resistor
SMD 2 kΩ, 1%, 1/10 W, 0402 resistors
500 mA low dropout (LDO) CMOS linear regulator
Electrically erasable programmable read only memory
(EEPROM)
High accuracy, ultralow LDO regulator
500 mA, low dropout CMOS linear regulator
USB to multipurpose UART/first in, first out (FIFO)
ADAU1850 Lark-Lite
12 MHz, 10 ppm, 18 pF, 3.2 mm × 2.5 mm × 0.8 mm
IC crystal clock oscillator
EVAL-ADAU1850
Value Vendor Order Number
4.7 µF GRT188R61E475KE13D
0.1 µF GRM155R71E104KE14D
10 µF GRM188R61E106KA73D
47 µF GCJ32ER70J476KE19L
2.2 µF GRM188R61E225KA12D
1 µF GCM188R71E105KA64D
0.01 µF C1005X7R1E103K050BB
1 nF 04023C102KAT2A
1 µF GRM155R70J105KA12D
0.1 µF GRM033R60J104KE19D
0.1 µF GRM033R61A104KE15D
10 µF GRM155R60J106ME15J
18 pF GRM0335C1E180JA01D
DFLS220L-7 DFLS220L-7
80 Ω at 100 MHz BLM41PF800SN1L
100 nH L-07CR10JV6T
ZX62-B-5PA(33) ZX62-B-5PA(33)
SJ-3523-SMT SJ-3523-SMT
0 Ω RC0402JR-070RL
1 kΩ ERJ-2RKF1001X
10 kΩ ERJ-2GEJ103X
49.9 kΩ ERJ-2RKF4992X
49.9 Ω ERJ-2RKF49R9X
475 Ω ERJ-2RKF4750X
6.2 kΩ ERJ-2GEJ622X
33 Ω ERJ-2RKF33R0X
12 kΩ RC0402FR-0712KL
2 kΩ ERJ-2RKF2001X
ADP1715ARMZ-R7 ADP1715ARMZ-R7
93LC56BT-I/OT 93LC56BT-I/OT
ADP3335ARMZ-1.8 ADP3335ARMZ-1.8
ADP1715ARMZ-3.3-R7 ADP1715ARMZ-3.3-R7
FT232HL-REEL FT232HL-REEL
ADAU1850 ADAU1850
12 MHz ABM8AIG-12.000MHZ-1Z-T
24.5760 MHz KC2520K24.5760C10E00
Rev. A | 11 of 12
