6
Setup webpage
Option only available to access in case of Master Charge Point.
Setup webpage allows managing networking setup, upgrading devices and other options.
Once the Service PC is already connected to Charge Point, it is possible to open Setup
Webpage through the IP entered. Open a web browser on the service PC and enter this
IP, next image will appear.
The web-page opened shows the 'Dashboard' Overview' as a main screen, but there are
many more options. In the next points, they will be explained.
A)
Dashboard
In the right top corner it is shown the search engine icon, the language list and information
about the Charge Point. Once the info button is pressed, it appears the screen displayed
above, with model and firmware version information, among others.
