Page 1 Wallbox eVolve Rapid Series Installation & User Manual...
Page 3: Wallbox Evolve Rapid
C O P Y R I G H T I N F O R M AT I O N This document is copyrighted, 2022 by Circontrol, S.A. All rights are reserved. Circontrol, S.A. reserves the right to make improvements to the products described in this manual at any time without notice.
Page 5: Table Of Contents
Here’s your guide to install Wallbox eVolve Rapid 1 — So, Hello! 2 — Before the installation A - Important safety instructions B - Electrical wiring considerations C - Important Electrical Safety Instructions D - EVSE Classification 3 — Overview 4 —...
Page 6 Wallbox eVolve Rapid Manual...
Page 7: So, Hello
So, hello! This manual provides commissioning and use instructions information about Wallbox eVolve Rapid, which has been designed and tested to allow electric vehicle charging, specified in IEC 61851. This document has different sections such as step-by-step installation procedure and technical data. THE FOLLOWING SYMBOLS ARE USED FOR IMPORTANT SAFETY INFORMATION IN THIS DOCUMENT ELECTRIC RISK...
Page 8: Important Safety Instructions
• Do not use this unit for anything other close...). than electric vehicle charging modes are expected in IEC 61851. • Use only Circontrol supplied spare parts. • Do not modify this unit. If modified, CIRCONTROL will reject all • Do not use this unit if the enclosure...
Page 9: Before Installation
Before installation Electrical wiring considerations Take into consideration this section before start wiring connections of the Charge Point. 1 — E L E C T R I C A L P R O T E C T I O N S Charge point may not include elements of electrical protection.
Page 10: Important Electrical Safety Instructions
Wallbox eVolve Rapid Manual Important Electrical Safety Instructions Read carefully all the instructions before starting in order to ensure properly handling of electrical parts. A safe work environment is not enough to control all potential electrical hazards. It is recommended to be very cautious and work safely. So, the safety rules shown below could help to control risks of injury or death from workplace hazards.
Page 11: Devse Classification
EVSE Classification Classification of the unit according to the IEC 61851-1:2017: 1 — Power supply Input • EV supply equipment connected to AC supply network • Permanently connected 2 — Power supply Output • DC EV supply equipment 3 — Environmental conditions •...
Page 12 Wallbox eVolve Rapid Manual What’s included: Installation & Wall plates Charge Point User Manual Electric Cable roller Fixation cabinet key + screw security key...
Page 13: Overview
Overview Basic Serie Satellite Serie 1 — Hat 5 — Wall support 9 — Stop button 2 — Key lock access 6 — Base 10 — Power input 3 — Ventilation 7 — LED Beacon light 4 — Cable output 8 —...
Page 14 Wallbox eVolve Rapid Manual Charge point: Measures in mm...
Page 15: Dimensions
Dimensions Wall plates:...
Page 16 Wallbox eVolve Rapid Manual What is needed: Fixation Wall plates screw Wall screws Anchors Screws and anchors are NOT INCLUDED. It is highly recommended that the installation kit would be installed in brick or concrete wall. Before the installation, a qualified installer must check that the wall is in a perfect condition, and which screws and anchors are suitable for that conditions.
Page 17: Installation
Installation Space requirements When installing the unit, some space shall be reserved for usability, maintenance and safety reasons. Please comply accordingly to your country specifications. The next picture shows the minimum distances: Measures in mm Front view y* distance shall be chosen according to your country rules...
Page 18: B Plates Fixation
Wallbox eVolve Rapid Manual Plates fixation Install the plates on the wall considering the distances and the wall holes template shown on the image below: Measures in mm Front view y* distance shall be chosen according to your country rules...
Page 19: C Positioning
Positioning Place the Charge Point on the previously installed wall plates.
Page 20: D Opening
Wallbox eVolve Rapid Manual Opening Introduce provided eVolve Rapid security key in the lock located at the top part of the unit and the electric cabinet key at the bottom lock of the unit. Then, the unit is unlocked and ready to be opened. Pull outward the Tamper switch* to operate the Charge Point.
Page 21: E Unit Fixation
Unit fixation Once the charging point is opened, tighten the provided fixation screw in the lower wall plate in order to secure the unit to the wall and make sure all components remain as by default before proceeding.
Page 22: F Connections
Wallbox eVolve Rapid Manual Connections Put your electrical connections inside the Charge Point, introducing cables through the rounded lower part, as indicated in the pictures below. Upper Lower Cable entry Cable entry It is higly recommended to install around an extra 20cm of power supply cables and store it in the Charge Point bottom cap to make maintenance tasks without disconnecting any wiring connections.
Page 23: G Wiring
Wiring THREE-PHASE CHARGE POINT Connect to the 400VAC. Terminal block maximum cross-section: 16mm Type of cable allowed by the terminal block: Aluminium & copper Al/Cu Do not forget to connect the ground cable to the ground terminal Make sure all screws are securely tightened at 4...5 Nm...
Page 24: H Verification
Wallbox eVolve Rapid Manual Verification 1 — P O W E R I N P U T Before proceeding, make sure voltage is present in the terminal blocks. Pay special attention to Neutral Cable. 2 — M A I N T E N A N C E M O D E Pull outward the Tamper Switch located in lower half of the Charge Point.
Page 25: I How To Use And Configure Satellite Wallbox
Rapid Basic Serie it is not configurable. In order to see how to use it, see chapter “How to use Basic Wallbox” in this manual. Note: Ask Circontrol Support Department in order to register in the Circontrol Expert Area.
Page 26: Start Charging
Wallbox eVolve Rapid Manual eVolve Rapid Basic Serie it is not configurable. As detailed in previous chapters, the unit has a LED beacon light and two illuminated buttons, the start and stop ones. The LED beacon light is located just above the start and stop buttons. Standby When LED beacon is green and the start button is also green, it means that the unit is available and ready to start a charge transaction (A status,...
Page 27: How To Use Basic Wallbox
How to use Basic Wallbox Charged When the EV is fully charged, it turns to Standby step, in which both LED beacon and start button are green. Stop charging While the unit is in charge status or is completely charged, the user is available to finish the charge pressing the stop button.
Page 28 Wallbox eVolve Rapid Manual General Specifications AC Power Supply 3P + N + PE AC Input Voltage 400V +/- 10% three-phase Power Factor > 0.98 Efficiency 94% at nominal output power Frequency 50 / 60Hz Required power supply capacity 27 kVA Maximum AC input current 39 A Maximum output power...
Page 29: Technical Data
Technical Data Satellite Master Ethernet UTP Communication Optional devices Safety Protections RCD type B 30mA MCB curve C Model Specifications Models Wallbox Satellite Wallbox Basic Operating Temperature -5ºC to +45ºC -5ºC to +45ºC Environment Indoor Indoor Dimensions (W x H x D) 382 x 984 x 236 mm 382 x 984 x 236 mm Weight...
Page 30 Wallbox eVolve Rapid Manual...
Page 31: Need Help
Need help? In case of any query or need further information, please contact our Support Department: support@circontrol.com circontrol.com (+34) 937 362 940 (+34) 937 362 941...

This manual is also suitable for:

Basic series Satellite series Wallbox satellite Wallbox basic
