Introduction
The Ethernet port of the Master Charge
Point is located at the bottom left side of
the rear part of the HMI screen.
Before proceeding , make sure all the following is ready:
Computer running
at least Microsoft
Windows XP.
There is only one Ethernet port on the
Satellite Charge Point and it is located
on the TCP1RS. The location of this device
may vary depending on the model,
for more information please contact
Circontrol Post-Sales Department.
UTP Cable (at least one
for each Charge Point)
IPSetup.exe ( Can be
downloaded for free
from Circontrol Expert
Area)
