1.2 Part Name
1.2.1 ERL2 Series (slider type)
Opposite side of the motor
1.2.2 ESD2 Series (rod type)
Opposite side of the motor
Steel tape
Slider
Slider body
Rod
Body
Spacer (option)
2
Connection
Motor
plate
section
Motor side
Connection
Motor section
plate
Motor side
1. PRODUCT OVERVIEW
2018-11-12
