SM-612226-A/4

4.1 Periodic Inspection

In order to use the product under optimum conditions, perform a periodic inspection two to three times a
year.
Inspect the timing belt every 500 km.

4.1.1 Inspection item

Turn off the power before performing items 1, 2, 3, and 4 below.
No.
Inspection item
1 Check that the mounting bolts on the
product, the screws on the terminal block,
and the connectors are not loose.
2 Check that there are no scratches and
cracks on the cables.
3 Check that foreign matters are not
accumulating or are not stuck in between
the movable section.
4 Check that there are no scratches, cracks,
and tears on the timing belt.
5 Check that there are no vibrations or
abnormal sounds while the product is
stopped or operated.
6 Check that the power supply voltage is
normal.
Note 1: Use a soft cloth for cleaning and make sure not to leave foreign matters on the movable section.
Inspection method
Looseness check Tighten the loose parts.
Visual inspection Replace the cable.
Visual inspection Clean the parts.
After cleaning, apply grease.
Recommended grease:
Visual inspection Replace the timing belt.
Noise inspection Contact your dealer.
Tester Check the power system and use the product
within the power supply voltage range described
in the Specifications.
45
4. MAINTENANCE AND INSPECTION
Action
Note 1
Lithium grease
AFF grease (THK Co., Ltd.)
