SM-612226-A/4

1.3 Model Number Indication

1.3.1 ERL2 Series (slider type)

Set model number (actuator, controller, and cable)
[A] Body size
Model
<Example of model number indication>
[A] Body size
[B] Motor mounting
direction
[C] Screw lead
[D] Stroke
[E] Brake
[F] Origin position
[G] Relay cable length
[H] Controller
[I] I/O cable length
Actuator model number
[A] Body size
[B] Motor mounting direction
[C] Screw lead
Series
Mounting method
[B] Motor mounting direction
[C] Screw lead
[D] Stroke
[E] Brake
: 60
: Standard
[F] Origin position
(straight)
: 6 mm
: 500 mm
[G] Relay cable length
: With brake
: Motor side
: Movable cable 10 m
: EC07 DIN rail mount
: 2 m
[I] I/O cable length
[E] Brake
[F] Origin position
[D] Stroke
Cable model number
Relay cable
Symbol
[A] Body size
Body size 45
Body size 60
[B] Motor mounting direction
Standard (straight)
Rightward
Leftward
Downward
[C] Screw lead
6 mm
12 mm
[D] Stroke
Symbol
Length
50 mm
100 mm
150 mm
200 mm
250 mm
300 mm
350 mm
400 mm
450 mm
500 mm
550 mm
600 mm
700 mm
[E] Brake
Without brake
With brake
[F] Origin position
Motor side
Opposite side of the motor
[G] Relay cable length
None
Fixed cable 1 m
Fixed cable 3 m
Fixed cable 5 m
Fixed cable 10 m
Movable cable 1 m
Movable cable 3 m
Movable cable 5 m
Movable cable 10 m
[H] Controller
[H] Controller
None
[I] I/O cable length
None
2 m
Note 3
3 m
Note 3
5 m
Note 1: If selecting "N" for controller, also select "N" for I/O cable length.
Note 2: Use PLC unit which satisfies the ECPT pulse string signal input specifications (refer to
pages 5 to 13 in "SM-612271 Controller Instruction Manual").
Note 3: If the controller is E or F, these cables can be used only when the differential system is
used as the pulse string signal system.
Only the 2 m cable can be used for the open collector system.
Fixed/Movable
Cable length
4
1. PRODUCT OVERVIEW
Description
Body size/Motor mounting direction
Note 1
Standard mount
DIN rail mount
Standard mount
DIN rail mount
Note 2
Standard mount
Note 2
DIN rail mount
I/O cable
Cable length
Controller series
2018-11-12
