Digital Electro-pneumatic
Regulator
EVD-1000/3000 Series
INSTRUCTION MANUAL
SM-A40414-A
• Read this Instruction Manual before using the product.
• Read the safety notes carefully.
• Keep this Instruction Manual in a safe and convenient place for future reference.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EVD-1000 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for CKD EVD-1000 Series

Summary of Contents for CKD EVD-1000 Series

  • Page 1 Digital Electro-pneumatic Regulator EVD-1000/3000 Series INSTRUCTION MANUAL SM-A40414-A • Read this Instruction Manual before using the product. • Read the safety notes carefully. • Keep this Instruction Manual in a safe and convenient place for future reference.

  • Page 2: Preface

    • Since there are a wide variety of customer applications, it is impossible for CKD to be aware of all of them. Depending on the application or usage, the product may not be able to exercise its full performance or an accident may occur due to fluid, piping, or other conditions.

  • Page 3: Safety Information

    SM-A40414-A SAFETY INFORMATION SAFETY INFORMATION When designing and manufacturing any device incorporating the product, the manufacturer has an obligation to ensure that the device is safe. To that end, make sure that the safety of the machine mechanism of the device, the pneumatic control circuit, and the electric system that controls such mechanism is ensured.

  • Page 4: Precautions On Product Use

    SM-A40414-A SAFETY INFORMATION Precautions on Product Use DANGER Use the product within the specified voltage range. Applying voltage beyond the specified range may cause a malfunction, damage to the sensor, electric shock, or fire. Do not connect a load exceeding the rated output. The output circuit may become damaged or a fire may occur.
  • Page 5 Before using the product as an air blow with the control pressure of the secondary side released to the atmosphere, test the usage under actual conditions of use or contact CKD. The pressure may fluctuate depending on the piping and blowing conditions.
  • Page 6 When using the product out of the specified conditions or for a special application, consult CKD about the specifications. Do not use the product where it is exposed to direct sunlight or where water, oil, and other liquids may directly splash onto the product.
  • Page 7 SM-A40414-A SAFETY INFORMATION Note 2020-10-05...

  • Page 8: Table Of Contents

    SM-A40414-A CONTENTS CONTENTS PREFACE ........................... i SAFETY INFORMATION ....................ii Precautions on Product Use ..................iii Precautions on Design and Selection ................iii CONTENTS ........................vii PRODUCT OVERVIEW ..................... 1 Part Name ......................1 1.1.1 Body ........................ 1 1.1.2 Names and functions of display and operation panel ........3 Functions......................
  • Page 9 SM-A40414-A CONTENTS REFERENCE INFORMATION ................. 45 Correspondence between the Parallel Input Signal and the Control Pressure 45 Correspondence between the Preset Memory and the Input Signal ....46 WARRANTY PROVISIONS ..................47 Warranty Conditions ..................47 Warranty Period ....................47 2020-10-05 viii...

  • Page 10: Product Overview

    SM-A40414-A 1. PRODUCT OVERVIEW 1. PRODUCT OVERVIEW 1.1 Part Name 1.1.1 Body ◼ EVD-1000 Series D-sub connector 15 pin plug LED display Connector fixing base Operation keys Port R (pilot air exhaust) Threaded hole for mounting the bracket Exhaust port...
  • Page 11 SM-A40414-A 1. PRODUCT OVERVIEW ◼ EVD-3000 Series D-sub connector 15 pin plug Connector fixing base LED display Operation keys Exhaust port Port R (main air exhaust) (pilot air exhaust) Threaded hole for mounting the bracket 2020-10-05...

  • Page 12: Names And Functions Of Display And Operation Panel

    SM-A40414-A 1. PRODUCT OVERVIEW 1.1.2 Names and functions of display and operation panel 3-digit number LED display (green) Output display (red) ⚫ In the RUN mode (pressure display), the pressure or ⚫ "F" is displayed during function setting function setting data is displayed. confirmation.

  • Page 13: Functions

    Switch output is available only for the switch output type. This function cannot be used for analog output type. Target model: EVD-1□00-□□SN, EVD-1□00-□□SP, EVD-3□00-□□SN, EVD-3□00-□□SP Proportional value change is a function limited to the maximum pressure 100 kPa type. Target model: EVD-1100-□□□, EVD-3100-□□□ * For EVD-1500, EVD-1900, EVD-3500, EVD-3900, contact your nearest CKD sales office or distributor. 2020-10-05...

  • Page 14: Model Number Indication

    SM-A40414-A 1. PRODUCT OVERVIEW 1.3 Model Number Indication ◼ EVD-1000 Series EVD-1 C1B1 Description Symbol Pressure specification Pressure specification 100 kPa 500 kPa 900 kPa Input specification Input specification 0 VDC to 10 VDC 0 VDC to 5 VDC 4 mADC to 20 mADC...
  • Page 15 SM-A40414-A 1. PRODUCT OVERVIEW ◼ EVD-3000 Series EVD-3 C1B3 Symbol Description Pressure specification Pressure specification 100 kPa 500 kPa 900 kPa Input specification Input specification 0 VDC to 10 VDC 0 VDC to 5 VDC 4 mADC to 20 mADC Parallel 10-bit Port size Port size...

  • Page 16: Specifications

    SM-A40414-A 1. PRODUCT OVERVIEW 1.4 Specifications ◼ EVD-1100-0/1/2/P (maximum pressure: 100 kPa) EVD-1100-[*1][*2]□ EVD-1100-P[*2]□ (*1--- 0/1/2) Descriptions Analog type Parallel type Clean compressed air (equivalent to ISO Class 1. 3. 2) Working fluid 160 kPa Max. working pressure Control pressure +50 kPa Min.
  • Page 17 SM-A40414-A 1. PRODUCT OVERVIEW ◼ EVD-1500-0/1/2/P (maximum pressure: 500 kPa) EVD-1500-[*1][*2]□ EVD-1500-P[*2]□ (*1--- 0/1/2) Descriptions Analog type Parallel type Clean compressed air (equivalent to ISO Class 1. 3. 2) Working fluid 700 kPa Max. working pressure Control pressure +100 kPa Min.
  • Page 18 SM-A40414-A 1. PRODUCT OVERVIEW ◼ EVD-1900-0/1/2/P (maximum pressure: 900 kPa) EVD-1900-[*1][*2]□ EVD-1900-P[*2]□ (*1--- 0/1/2) Descriptions Analog type Parallel type Clean compressed air (equivalent to ISO Class1. 3. 2) Working fluid 1000 kPa Max. working pressure Control pressure + 100 kPa Min.
  • Page 19 SM-A40414-A 1. PRODUCT OVERVIEW ◼ EVD-3100-0/1/2/P (maximum pressure: 100 kPa) EVD-3100-[*1][*2]□ EVD-3100-P[*2]□ (*1--- 0/1/2) Descriptions Analog type Parallel type Clean compressed air (equivalent to ISO Class 1. 3. 2) Working fluid 160 kPa Max. working pressure Control pressure +50 kPa Min.
  • Page 20 SM-A40414-A 1. PRODUCT OVERVIEW ◼ EVD-3500-0/1/2/P (maximum pressure: 500 kPa) EVD-3500-[*1][*2]□ EVD-3500-P[*2]□ Descriptions (*1--- 0/1/2) Analog type Parallel type Clean compressed air (equivalent to ISO Class 1. 3. 2) Working fluid 700 kPa Max. working pressure Control pressure +100 kPa Min.
  • Page 21 SM-A40414-A 1. PRODUCT OVERVIEW ◼ EVD-3900-0/1/2/P (maximum pressure: 900 kPa) EVD-3900-[*1][*2]□ EVD-3900-P[*2]□ Descriptions (*1--- 0/1/2) Analog type Parallel type Clean compressed air (equivalent to ISO Class1. 3. 2) Working fluid 1000 kPa Max. working pressure Control pressure + 100 kPa Min.

  • Page 22: Dimensions

    SM-A40414-A 1. PRODUCT OVERVIEW 1.5 Dimensions ◼ EVD-1000 Series D sub-connector 15-pin/plug 2-#4-40UNC φ4.2 Port R (Pilot air Exhaust port) 2- (Select by port diameter) Rc1/4 4-M3 depth 6 G1/4 NPT1/4 φ5.3 EXH port 2020-10-05...
  • Page 23 SM-A40414-A 1. PRODUCT OVERVIEW ◼ EVD-3000 Series D sub-connector 15-pin/plug 2-#4-40UNC φ4.2 Port R (Pilot air Exhaust port) 2- (Select by port diameter) Rc1/4 G1/4 EXH port 2-M4 depth12 (Select by port diameter) NPT1/4 Rc3/8 Rc3/8 G3/8 NPT3/8 G3/8 NPT3/8 2020-10-05...

  • Page 24: Internal Structure

    SM-A40414-A 1. PRODUCT OVERVIEW 1.6 Internal Structure ◼ EVD-1000 Series Part name Material PBT resin D-sub connector Housing ABS resin Controller board 3-way valve Valve base Polyphenylene sulfide resin Pilot chamber Polyphenylene sulfide resin Body Aluminum alloy die casting Pressure sensor...
  • Page 25 SM-A40414-A 1. PRODUCT OVERVIEW ◼ EVD-3000 Series Part name Material PBT resin D-sub connector Housing ABS resin Controller board 3-way valve Valve base Polyphenylene sulfide resin Pilot chamber Polyphenylene sulfide resin Aluminum alloy die-casting, etc. Piston body assembly Aluminum alloy die-casting Body ―――...

  • Page 26: Installation

    Install a pneumatic filter immediately before the circuit in which pneumatic components are used. Install the product so that the exhaust port is not blocked and there is sufficient space for exhaust. ・EVD-3000 Series ・EVD-1000 Series Pilot exhaust air Pilot exhaust air Wall Wall...
  • Page 27 SM-A40414-A 2. INSTALLATION Attach the optional bracket to the bottom of the product. For the optional bracket, refer to "6.1 Optional Part Model Number". ・EVD-1000 Series Cross headed pan machine screw with B-type can be installed in both directions. spring retainer M3 x 8...

  • Page 28: Piping

    SM-A40414-A 2. INSTALLATION 2.2 Piping CAUTION Do not remove the port seal until just before piping. If the port seal is removed before ready to begin piping, foreign matters may enter from the piping ports and cause a failure or malfunction. Fully flush and clean the air pipe before use.

  • Page 29: Wiring

    SM-A40414-A 2. INSTALLATION 2.3 Wiring WARNING Check the connector pins and the cable conductor colors before wiring. Incorrect wiring may cause damage, failure, and malfunctions of the product. Check the wire color described in the Instruction Manual before wiring. Check the wiring insulation. Make sure that the wires do not contact other circuits and there is no ground fault and insulation failure between terminals.

  • Page 30: D-Sub Connector

    Hold the D-sub connector firmly so that it faces up or sideways when inserting it. The rotating mechanism of the D-sub connector allows a 90 degree rotation. ・EVD-3000 Series ・EVD-1000 Series Hold firmly when Hold firmly when inserting the connector.

  • Page 31: Cable Connection

    SM-A40414-A 2. INSTALLATION 2.3.2 Cable connection ◼ Analog input type: EVD-1□00-0/1/2, EVD-3□00-0/1/2 D-sub socket 6 to 9 Optional cable Brown Orange Yellow Gray White Green Blue Black insulator color Analog Switch Error Item Preset input signal Input signal Power output output output Power...

  • Page 32: Example Of Internal Circuit And Load Connection

    SM-A40414-A 2. INSTALLATION 2.3.3 Example of internal circuit and load connection ◼ Analog input type: EVD-1□00-0/1/2, EVD-3□00-0/1/2 • EVD-1□00-□□AN, EVD-3□00-□□AN: Analog output + error <NPN> output type Pin 5 (power +) Signal generator Pin 1 (preset bit 1) Pin 2 (preset bit 2) Pin 3 (preset bit 3)
  • Page 33 SM-A40414-A 2. INSTALLATION ◼ Analog input type: EVD-1□00-0/1/2, EVD-3□00-0/1/2 • EVD-1□00-□□AP, EVD-3□00-□□AP: Analog output + error <PNP> output type Pin 5 (power +) Pin 13 (analog output) Output protection Pin 14 Max. 50 mA circuit (error output) Pin 11 (analog input) Signal generator Pin 1 (preset bit 1)
  • Page 34 SM-A40414-A 2. INSTALLATION ◼ Parallel input type: EVD-1□00-P, EVD-3□00-P • EVD-1□00-□□AN, EVD-3□00-□□AN: Analog output + error <NPN> output type Pin 5 (power +) Pin 12 (MSB bit 10) Pin 11 (bit 9) Pin 9 (bit 8) Pin 8 (bit 7) Pin 7 (bit 6) Pin 6 (bit 5) Pin 4 (bit 4)
  • Page 35 SM-A40414-A 2. INSTALLATION ◼ Parallel input type: EVD-1□00-P, EVD-3□00-P • EVD-1□00-□□AP, EVD-3□00-□□AP: Analog output + error <PNP> output type Pin 5 (power +) Pin 13 (analog output) Max. 50 mA Pin 14 (error output) Pin 12 (MSB bit 10) Pin 11 (bit 9) Pin 9 (bit 8) Pin 8 (bit 7) Pin 7 (bit 6)

  • Page 36: Usage

    SM-A40414-A 3. USAGE 3. USAGE CAUTION Create a program and control circuit that ignores signals for approximately two seconds immediately after energized. Pressure control will not operate for approximately two seconds immediately after energized for self-diagnosis. Stop the device before changing the set output value. Control system devices may operate unintentionally.
  • Page 37 SM-A40414-A 3. USAGE ◼ Parallel input type EVD-1□-P□□-□-□, EVD-3□-P□□-□-□ Input signal type code Description Parallel 10-bit input Direct memory input 2020-10-05...

  • Page 38: Zero/Span Adjustment

    SM-A40414-A 3. USAGE 3.1.2 Zero/span adjustment If the preset input or direct memory input is selected on the F1 screen, this function is disabled. The F2 screen shows whether the zero/span adjustment is enabled or disabled and its set value. When the function is disabled: When the function...

  • Page 39: Switch Output (Evd-□□□□-□□Sn/Sp)

    SM-A40414-A 3. USAGE 3.1.4 Switch output (EVD-□□□□-□□SN/SP) This function is disabled for analog output type. "--" is displayed on the screen but the function cannot be used. The F4 screen shows whether the switch output is enabled or disabled and its set value. <...

  • Page 40: Proportional Value Change (Evd-□100-□□□)

    SM-A40414-A 3. USAGE 3.1.5 Proportional value change (EVD-□100-□□□) This screen is not displayed for EVD-1500, EVD-1900, EVD-3500, EVD-3900. In the F5 screen, whether the proportional value change is enabled or disabled and its set level can be When the function is disabled (standard value)* factory setting confirmed.

  • Page 41: How To Set (Setting Mode)

    Target model: EVD-1□00-□□SN, EVD-1□00-□□SP, EVD-3□00-□□SN, EVD-3□00-□□SP, Note 4: Proportional value change is a function limited to the maximum pressure range 100 kPa type. Target model: EVD-1100-□□□, EVD-3100-□□□ * For EVD-1500, EVD-1900, EVD-3500, EVD-3900 contact your nearest CKD sales office or distributor. 2020-10-05...

  • Page 42: Key Lock

    SM-A40414-A 3. USAGE 3.2.2 Key lock Key lock prevents incorrect operation. When the power is turned on (including re-turn on), the key is locked. Release the key lock before changing the setting. ⚫ How to release key lock Press & hold both at least 2 seconds. ⚫...
  • Page 43 SM-A40414-A 3. USAGE ◼ Input signal for parallel input type At least 2 seconds When parallel input is selected *Factory setting After data is confirmed, the setting mode is canceled and returns to screen F1. At least 2 seconds When direct memory input is selected Switches to direct memory input setting mode (Refer to "Direct memory input") At least 2 seconds...

  • Page 44: Zero/Span Adjustment

    SM-A40414-A 3. USAGE 3.2.4 Zero/span adjustment In F2 screen, press and hold the [SET] key at least two seconds to switch to the setting mode. At least 2 seconds For full-scale operation *Factory setting After the data is confirmed, the setting mode is canceled After the data is confirmed, the setting mode is canceled and returns to screen F2.

  • Page 45: Switch Output (Target Model: Evd-□□□□-□□Sn/Sp)

    SM-A40414-A 3. USAGE 3.2.6 Switch output (target model: EVD-□□□□-□□SN/SP) This function is disabled for analog output type. "--" is displayed on the screen but the function cannot be used. In F4 screen, press and hold the [SET] key at least two seconds to switch to the setting mode. At least 2 seconds When switch output is not used *Factory setting...

  • Page 46: Proportional Value Change Setting (Evd-□100-□□□)

    SM-A40414-A 3. USAGE 3.2.7 Proportional value change setting (EVD-□100-□□□) This screen is not displayed for EVD-1500, EVD-1900, EVD-3500, EVD-3900. In the F5 screen, press and hold the [SET] key at least two seconds to switch to the setting mode. <F5 screen> At least 2 seconds If not using the proportional value change function *Factory setting After the data is confirmed, the setting mode is canceled...

  • Page 47: Factory Setting Mode (Initialization)

    Target model: EVD-1□00-□□SN, EVD-1□00-□□SP, EVD-3□00-□□SN, EVD-3□00-□□SP Note 3: The proportional value change function is available only with the type having a maximum pressure of 100 kPa. Target model: EVD-1100-□□□, EVD-3100-□□□ * For EVD-1500, EVD-1900, EVD-3500, EVD-3900 contact your nearest CKD sales office or distributor. 2020-10-05...

  • Page 48: Maintenance And Inspection

    • Are the valves exhausting properly? ◼ Operation of pneumatic actuator • Are operations smooth? • Is the actuator reaching the end stop properly? • Are loads connected properly? If an abnormality is found, contact your nearest CKD sales office or distributor. 2020-10-05...

  • Page 49: Troubleshooting

    SM-A40414-A 5. TROUBLESHOOTING 5. TROUBLESHOOTING 5.1 Problems, Causes, and Solutions If the product does not operate as intended, check the table below for a possible solution. Problem Cause Solution Release the key lock according to "3.2.2 Key lock" and Key is locked. change the settings.
  • Page 50 Note 1: The proportional value change function is available only with the type having a maximum pressure of 100 kPa. Target model: EVD-1100-□□□, EVD-3100-□□□ For EVD-1500, EVD-1900, EVD-3500, EVD-3900 contact your nearest CKD sales office or distributor. If you have any other questions or concerns, contact your nearest CKD sales office or distributor. 2020-10-05...

  • Page 51: Error Code

    Error occurred during EEPROM ● Contact your nearest CKD sales office or distributor. reading or writing. Error occurred during memory reading ● Contact your nearest CKD sales office or distributor.

  • Page 52: Optional Part Model Number

    SM-A40414-A 6. OPTION 6. OPTION 6.1 Optional Part Model Number Symbol Description Cable option Analog 9-conductor cable, 1 m Analog 9-conductor cable, 3 m Parallel 15-conductor cable, 1 m Parallel 15-conductor cable, 3 m Cable option ● EVD-C1, EVD-C3 Shielded wire ●...
  • Page 53 SM-A40414-A 6. OPTION EVD- Symbol Description Bracket option B-type bracket, floor mounted, EVD-1000 L-type bracket, wall mounted, EVD-1000 B-type bracket, floor mounted, EVD-3000 L-type bracket, wall mounted, EVD-3000 ●EVD-B1 ●EVD-L1 4-full R 4-full R ●EVD-B3 ●EVD-L3 4-full R 2020-10-05...

  • Page 54: Reference Information

    SM-A40414-A 7. REFERENCE INFORMATION 7. REFERENCE INFORMATION 7.1 Correspondence between the Parallel Input Signal and the Control Pressure The parallel input signal is 10-bit and ranges from 0 to 1023 when converted to a decimal number. Input signal = EVD set pressure (kPa)/maximum control pressure x 1023 The maximum control pressure is as follows: ・100 kPa for EVD-1100, 3100 ・500 kPa for EVD-1500, 3500...

  • Page 55: Correspondence Between The Preset Memory And The Input Signal

    SM-A40414-A 7. REFERENCE INFORMATION 7.2 Correspondence between the Preset Memory and the Input Signal D-sub socket pin no. Optional cable Preset memory no. Yellow Orange Brown insulator color Input type Bit 3 Bit 2 Bit 1 Input signal 2020-10-05...

  • Page 56: Warranty Provisions

    If the product specified herein fails for reasons attributable to CKD within the warranty period specified below, CKD will promptly provide a replacement for the faulty product or a part thereof or repair the faulty product at one of CKD’s facilities free of charge.
