Product Overview; System Overview; System Structure - CKD ERL2 Series Instruction Manual

SM-612226-A/4

1. PRODUCT OVERVIEW

1.1 System Overview

1.1.1 System structure

Surge protector
AX-NSF-RAV-781BXZ-4
(sold separately)
Power*
24 VDC
power*
Noise filter
AX-NSF-NF2015A-0D
(sold separately)
Devices indicated with an asterisk (*) are not supplied with the product.
Item
Standard structure
(when a set model number
is selected)
Sold separately
Provided for free
I/O cable
EC-CBLIF1
Teaching pendant
(sold separately)
communication cable
Controller
EC-CBLPC2
EC07
(sold separately)
EC63
ECPT
Motor/encoder relay cable
EC-CBLME1
Part name
Controller
Actuator
I/O cable
Motor/encoder relay cable
Teaching pendant
Computer communication cable
Surge protector
Noise filter
Software for Windows
ETP2
Computer
RS485 interface*
Product name/Model no.
EC07/EC63/ECPT
ERL2/ESD2 Series
EC-CBLIF1
EC-CBLME1
ETP2
EC-CBLPC2
AX-NSF-RAV-781BXZ-4
AX-NSF-NF2015A-0D
E Tools
1
1. PRODUCT OVERVIEW
PLC*
Software for Windows
E Tools
(provided for free)
Computer*
ERL2 Series
ESD2 Series
Actuator
2018-11-12
