SM-612226-A/4
1.3.3 ERL2 Series (slider type) optional parts
If the workpiece to be attached to the slider interferes with the motor section of the ERL2 Series (slider
type), use the following slider spacer kit.
Slider spacer kit: SSP
Model number for ERL2-45: EA-45-SSP
Dimensions
Model number for ERL2-60: EA-60-SSP
Dimensions
2-ø3H7, 7 deep
4-M4, 8 deep
2-ø3H7, 7 deep
4-M5, 10 deep
6
1. PRODUCT OVERVIEW
2018-11-12
