APPENDIX VII - THERMAL PERFORMANCE

All thermal tests were conducted at room temperature with no air flow with a load of 8A. A pre-soaking time of one hour was
before collecting any data. An infrared thermal camera was used for the measurement.
Figure 92 – Thermal image at 36 VDC, 8A load, no air flow, 1 hour soaking time.
