The VisualDSP++ 3.5 Installation Quick Reference Card included in your
package will guide you through the licence installation and registration
process (refer to Tasks 1, 2, and 3).

Setting Up EZ-KIT Lite Hardware

The EZ-KIT Lite evaluation system contains ESD
(electrostatic discharge) sensitive devices. Electrostatic
charges readily accumulate on the human body and
equipment and can discharge without detection. Per-
manent damage may occur on devices subjected to
high-energy discharges. Proper ESD precautions are
recommended to avoid performance degradation or
loss of functionality. Store unused EZ-KIT Lite boards
in the protective shipping package.
The ADSP-21161N EZ-KIT Lite board is designed to run outside your
personal computer as a stand-alone unit. You do not have to open your
computer case.
To connect the EZ-KIT Lite board:
1. Remove the EZ-KIT Lite board from the package. Be careful when
handling the board to avoid the discharge of static electricity,
which may damage some components.
2. Figure 1-1
and LEDs used in installation. Confirm that your board is set up in
the default configuration before moving to the next step.
3. Plug the provided power supply into
board. Visually verify that the green power LED (
verify that the two red RESET LEDs (
moment and then go off.
ADSP-21161N EZ-KIT Lite Evaluation System Manual
shows the default jumper settings, connector locations,
Getting Started
on the EZ-KIT Lite
P16
) is on. Also
LED11
and ) go on for a
LED1 LED8
1-5
