23 1 ADSP-21161NKCA100
PBGA225
1MM SPACING REV. X1.2
24 1 ADP3338AKC-33 SOT-223
3.3V-1.0AMP REGULA-
TOR
25 2 ADP3339AKC-5 SOT-223
5V-1.5A REGULATOR
26 1 ADP3338AKC-18 SOT-223
1.8V-1A REGULATOR
27 10 LMV722M SOIC8
DUAL AUDIO OP AMP
28 3 4.7uF 25V 10% C
TANT
29 1 PWR 2.5MM_JACK
CON005
RA
30 1 USB 4PIN CON009
USB
31 1 TORX173 6PIN CON008
FIBER OPTIC REV MOD-
ULE
32 1 RCA 4X2 CON011
RA
33 1 RCA 1X1 CON012
BLK
34 1 RCA 2X2 CON013
35 2 LNKPRT 12X2 CON010
ADSP-21161N EZ-KIT Lite Evaluation System Manual
U1 ANALOG
DEVICES
VR2 ANALOG
DEVICES
VR1, VR5 ANALOG
DEVICES
VR3 ANALOG
DEVICES
U12-20, U28 NATIONAL
SEMI
CT23-25 AVX
P16 SWITCH-
CRAFT
P2 MILL-MAX
P4 TOSHIBA
P8 SWITCH-
CRAFT
P5 SWITCH-
CRAFT
P6 SWITCH-
CRAFT
P13-14 HONDA
(TSUSHINK)
Bill Of Materials
ADSP-21161NCCA100
ADP3338AKC-3.3
ADP3339AKC-5-REEL
ADP3338AKC-1.8
LMV722M
TAJC475K025R
SC1152-ND12
897-30-004-90-000000
TORX173
PJRAS4X2U01
PJRAN1X1U01
PJRAS2X2S01
RMCA-EA26LMY-0M03-A
A-3
