Host Processor Interface Connector (P10)
A 20-pin 0.05' spacing connector provides access to some of the proces-
sor's External Port signals. By default, this connector is not populated.
Part Description
20-pin 0.05' (male)
Female to female cable
JTAG Connector (P12)
The JTAG header (
emulator pod. When an emulator is connected to the JTAG header, the
USB debug interface is disabled.
Pin 3 is missing to provide keying. Pin 3 in the mating connector should
have a plug.
When using an emulator with the EZ-KIT Lite board, follow the
connection instructions provided with the emulator.
Part Description
14-pin IDC Header (
Link Port Connectors (P13–14)
Each link port is connected to a 26-pin connector. Refer to EE-106 found
on the ADI website at
about the link port connectors.
ADSP-21161N EZ-KIT Lite Evaluation System Manual
Manufacturer
Samtec
Mating Connector
Samtec
) is the connecting point for a JTAG in-circuit
P12
Manufacturer
)
Berg
P12
http://www.analog.com
EZ-KIT Lite Hardware Reference
Part Number
FTSH-110-01-F-D-K
FFSD-10-D-5.000-01-N
Part Number
54102-T08-07
for more information
3-19
