Connectors
Part Description
26 position connector
Cable connector
Shroud
Coaxial cable
SPORT1 and SPORT3 Connector (P15)
and
SPORT1
SPORT3
Part Description
20 position AMPMODU system 50
receptacle
20 position AMPMODU system 20
connector
20 position AMPMODU system 20
connector (w/o lock)
Flexible film contacts (20 per con-
nector)
Power Connector (P16)
The power connector (
the EZ-KIT Lite board.
Part Description
2.5 mm Power Jack (
3-20
Manufacturer
Honda
Mating Connector
Honda
Honda
Gore
are connected to a 20-pin connector.
Manufacturer
AMP
Mating Connector
AMP
AMP
AMP
) provides all of the power necessary to operate
P16
Manufacturer
)
SWITCHCRAFT
P16
Digi-Key
ADSP-21161N EZ-KIT Lite Evaluation System Manual
Part Number
RMCA-26JL-AD
RMCA-E26F1S-A
RMCA-E26L1A
DXN2132
Part Number
104069-1
2-487937-0
2-487938-0
487547-1
Part Number
RAPC712
SC1152-ND
