Analog Devices ADSP-21161N EZ-KIT Lite Manual page 104

A
1
OUT1L-
DAC1 LEFT
OUT1L+
2
VREF
3
OUT1R-
DAC1 RIGHT
OUT1R+
4
A
B
R61 C38
5.49K 100PF
1206 1206
R59 R62
11.0K 3.32K
1206 1206
C36
330PF
805 2
C35
100PF
1206
3
C37
680PF
R60 805 R64
5.49K 1.65K
1206 1206
R63 C39
2.74K 220PF
1206 1206
AGND
R69 C44
5.49K 100PF
1206 1206
R67 R70
11.0K 3.32K
1206 1206
C42
330PF
805 6
C41
100PF
1206
5
C43
680PF
R68 805 R72
5.49K 1.65K
1206 1206
R71 C45
2.74K 220PF
1206 1206
AGND
B
C
DAC1_LEFT
R65
U17
604
1206
1
SSM2275
SOIC8
C40 R66
2200PF 49.9K
1206
1206
DAC1_RIGHT
R73
U17
604
1206
7
SSM2275
SOIC8
C46 R74
2200PF 49.9K
1206 1206
C
P8
CT26
CON011
68UF
CAP003
LOOP_DAC1_LEFT 2
3
AGND
P8
CT27
CON011
68UF
CAP003
LOOP_DAC1_RIGHT 1
3
ANALOG
AGND
DEVICES
Title 21161N EZ-KIT LITE - DAC1 OUTPUT
Approvals Date
Drawn
Size Board No.
Checked
B
Engineering
Date
11-12-2002_17:12
D
1
2
3
20 Cotton Road
Nashua, NH 03063
4
Rev
A0157-2000
2.4
Sheet 13 OF 24
D
