4. After the DSP RESET LED (
ify that the yellow USB monitor LED (
that the board is communicating properly with the host PC and is
ready to run VisualDSP++.
5. Verify that the USB driver software is installed properly.
Open Windows Device Manager and verify that ADSP-21161N
EZ-KIT Lite shows under ADI Development Tools with no excla-
mation point, as in
Figure 1-12. Device Manager Window
If using an EZ-KIT Lite on Windows 98, disconnect the USB
cable from the board before booting the PC. When Windows 98 is
booted and you are logged on, re-connect the USB cable to the
board. The operation should continue normally from this point.
ADSP-21161N EZ-KIT Lite Evaluation System Manual
) blinks for the second time, ver-
LED8
Figure 1-12.
Getting Started
) is lit. This signifies
LED10
1-15
