• Interface Connectors
14-Pin Emulator Connector for JTAG Interface
SPORT Connectors
Link Port 0 and Link Port 1
External Port Connectors (not populated)
• General-Purpose IO
4 Push Button Flags
3 Push Button Interrupts
6 LED Outputs
• Analog Devices ADP3338 and ADP3339 Voltage Regulators
• Breadboard area with typical SMT footprints
The EZ-KIT Lite board has a Flash memory device that can be used to
store user-specific boot code. By configuring the jumpers for EPROM
boot, the board can run as a stand-alone unit. The ADSP-21161N
EZ-KIT Lite package contains a Flash programmer utility, which allows
you to program the flash memory. The
is described on page
and
SPORT0 SPORT2
audio-signal processing applications.
off-board connectors of other serial devices.
Additionally, the EZ-KIT Lite board provides un-installed expansion con-
nector footprints that allow you to connect to the processor's External
Port (EP) and Host Processor Interface (HPI).
ADSP-21161N EZ-KIT Lite Evaluation System Manual
2-8.
connect to the audio codec, facilitating creation of
SPORT1
"Using Flash Programmer Utility"
and connect to
SPORT3
