Jumper Settings
Figure 3-2. Jumper Locations
MCLK Selection Jumper (JP3)
The
jumper is used to select the MCLK source for the AD1836 and
JP3
AD1852.
3-6
ADSP-21161N EZ-KIT Lite Evaluation System Manual
JP11: ADC1 Input Selector
JP5: FLAG1 Enable
JP1: External Memory
Width
JP22: BMS Enable
JP19: DSP ID
JP20: Boot Mode
JP21: Clock Mode
JP26: SW1 Enable
JP27: SW2 Enable
JP4: FLAG0 Enable
JP23: AD1836 Control Select
JP6: Sample Frequency
JP3: MCLK Select
JP2: SPDIF Select
JP9: Mic Gain Right
JP10: Mic Gain Left
JP7: ADC2 Input Mode Left
JP8: ADC2 Input Mode Right
