Menu Group - High Temp; Menu Group - A-Scan; Menu Group - B-Scan - Cygnus 1 Ex Manual

Menu Group - High Temp

Enable
Surface Temp
Temp Units
Coefficient

Menu Group - A-Scan

Auto Range
Zoom
Range
Rectification
Grid
Fill

Menu Group - B-Scan

Save to
Datalogger
Scan Range
Cygnus 1 Ex Operating Manual
Set the High Temperature Compensation feature On or
Off.
Set the surface temperature for compensation.
Select between C and F units for surface temperature.
Sets the temperature compensation coefficient value.
The default values for steel is "-0.000182", equal to -1%
per 55C rise in temperature.
So, -0.000182 = (-1%/55C)/100%
Set the A-Scan Auto-Range feature On or Off.
Set the A-Scan Zoom mode.
Set the A-Scan graph X axis range.
Set the A-Scan Rectification mode.
RF = no rectification
FW = full-wave rectification.
+HW = positive half-wave rectification.
-HW = negative half -wave rectification.
Set the A-Scan Grid mode.
Off = No grid lines.
Half = grid lines at 1/5
Full = grid lines at 1/10
Sets if the rectified A-Scan signal is filled down to the y=0
baseline.
Non = No fill.
Below = Fill down to the baseline.
Saves the current B-Scan data to a new Linear Datalogger
Record. This can take some time if there are lots of B-
Scan points.
Set the Thickness Range for the B-Scan graph.
This is the vertical height of the B-Scan graph, the Y axis.
Page 77 of 91
