• Minimum and Reference thickness limits can be specified in a record.
• Radial Points can be added to any Linear or Grid measurement point.
• You can start logging measurements from any location in the record.
• Grid records can have a 'grid patten' specified.

Creating a New Record

1. From the Menu, select Data Logging,
then New Record.
Press the √ key to start.
2. Select the Type of Record you want to
create.
3. Set the parameters for the new record
in the list displayed.
Use the Change function key to edit a
parameter.
4. When all the parameters have been
set, press the Create function key to
create the new record and start
logging.
