Gauge Menu

Menu Operation

All the gauge's features and settings can be accessed via the Menu, to display the
Menu just press the Menu key from any measurement screen.
The menu is split into two columns, the left column are the Groups, the right
column are the selected Group's Items.
Fig 35. Menu – Basic Features Gauge
• Use the up and down ▲▼ navigation keys to select an item.
• Use the left and right ◄ ► navigation keys to go between a Group and its
Items.
• Press the √ key to select an Item.
• Press the X key to cancel.
• Press the Menu key to exit the menu.

Menu Group - Datalogging

No Record is Open

New Record
Open Record
Protect Record
Delete Record
Delete All Records
Cygnus 1 Ex Operating Manual
Creates a New datalogging record, choosing from
various options like record type.
Select and Open an existing datalogging record.
Select and Protect a datalogging record.
Select and Delete a datalogging record.
Delete all the datalogging records from the file system.
You will be prompted twice to confirm the deletion.
Page 74 of 91
Fig 36. Menu – All Features Gauge
