Section 4 – Operating Instructions
In this manual all the features are described, but the features available
on your gauge will depend on its variant.

Quick Start Guide

1. Fit a Battery Pack.
2. Turn on the gauge.
3. Connect a Probe.
4. Select the Probe (if prompted).
5. Zero the Probe (if prompted).
6. Select the Measurement Mode required.
7. Check the measurements are correct using the Test Block – Calibrate if
measurements are incorrect.
8. Start taking measurements.

Taking Measurements

Ultrasonic Probes

The performance of any thickness gauge and its ability to get a reliable
measurement depends on selecting the right ultrasonic probe for the application
and conditions. The Cygnus 1 Ex gauge is therefore offered with a selection of
probes suitable for most thickness gauging applications.
The following section helps you select the right probe for the application.
The gauge must be set for the probe connected to it, see Setting the
Probe Type on page 48.

Measuring Metals

Material Coating Corrosion
Steels Any
Steels Any
Cygnus 1 Ex Operating Manual
Typical
Thickness
Non to 1 mm+
Moderate (0.04"+)
Non to 2 mm+
Moderate (0.08"+)
Page 21 of 91
Recommended..
Probe Measurement Mode
S5A Multiple Echo
S3C Multiple Echo
