Summary of Contents for Teldat SDE
- Page 1 Manual Teldat S.A. Installation Manual Copyright© Teldat Dm949 Version 1.1.3 02/2025 Teldat S.A.
- Page 2 This publication is subject to change. Teldat S.A. offers no warranty whatsoever for information contained in this manual. Teldat S.A. is not liable for any direct, indirect, collateral, consequential or any other damage connected to the deliv- ery, supply or use of this manual.
-
Page 3: Table Of Contents
Table of Contents Teldat S.A. Table of Contents Chapter 1 About this Guide ........1 Supported devices . - Page 4 Table of Contents Teldat S.A. Technical specifications ....... . A.3.1 Hardware architecture .
-
Page 5: Chapter 1 About This Guide
1 About this Guide Teldat S.A. Chapter 1 About this Guide This installation guide for the SDE router contains information on how to correctly install this device in a working en- vironment. 1.1 Supported devices The information provided in this installation guide only applies to the SDE router. -
Page 6: Chapter 2 Components And Power Supply
2 Components and Power Supply Teldat S.A. Chapter 2 Components and Power Supply The following chapter provides detailed information on the chassis of the SDE routers and its components. This in- cludes information on: • Components. • Assembly. • Power supply. - Page 7 2 Components and Power Supply Teldat S.A. Dell PowerEdge R660 front panel components are as follows: Item Feature Description Left control panel Accommodates the system health, system ID, status LED, and the iDRAC Quick Sync 2 (wireless) indicator. Drive Allows you to install drives that are supported on your system.
- Page 8 2 Components and Power Supply Teldat S.A. Fig. 4: Left control panel view Dell PowerEdge left control components are as follows: Item Feature Description Status LED indicators Indicates the status of the system. System health and ID indicators Indicates the system health.
- Page 9 2 Components and Power Supply Teldat S.A. 2.1.1.4.2 Right control The following figure shows the Right control panel view Fig. 5: Right control panel view Dell PowerEdge right control components are as follows: Element Feature Description Power button Indicates whether the system is powered on or off.
- Page 10 2 Components and Power Supply Teldat S.A. 2.1.1.5.1 Supermicro SYS-511E-WR control Control Panel Supermicro SYS-511E-WR Control Panel Fig. 7: Supermicro SYS-511E-WR control panel panel components are as follows: Item Description UID LED Button Push this button to turn on the blue UID LED indicators, both at the front and at the rear.
-
Page 11: Rear Panel
2 Components and Power Supply Teldat S.A. Blue, blinking at 1 Hz UID has been activated using the BMC to locate the server in a rack environment. Blue, blinking at 2 Hz BMC is resetting Blue, blinking at 4 Hz... - Page 12 2 Components and Power Supply Teldat S.A. Dell PowerEdge R660 Rear Panel Fig. 9: The following table provides information and a description of each component: Item Feature Description BOSS-N1 module BOSS module for internal system boot. Power supply unit PSU1 is the system's primary PSU.
- Page 13 2 Components and Power Supply Teldat S.A. BOSS riser Allows you to connect BOSS card. PCIe expansion card riser 2 Allows you to connect PCI Express expansion cards. Rear drive module Allows you to install rear drives supported on your system.
-
Page 14: Rack Installation
The SDE devices can be installed in a 19” rack. 2.2.1 Standalone An SDE device can be placed as a standalone on a flat, stable surface. The adhesive rubber feet must be stuck to the underside panel to prevent the router from sliding. -
Page 15: Connecting The Data
- user: admin - password: admin 2.4.2 Connecting for configuration To access the SDE device via the local console, a monitor and a keyboard can be connected to it (using the VGA and USB ports, respectively) Default credentials are: user: admin password: admin 2.5 Remote access... - Page 16 Fig. 13: iDRAC login page The default access user and password is teldat/teldat. This user will have access for monitoring purposes only. Once these credentials have been written, pushing "Log In" must give access to the iDRAC's main page.
-
Page 17: Supermicro - Bmc Access
2 Components and Power Supply Teldat S.A. Fig. 15: iDRAC virtual console 2.5.2 SuperMicro - BMC access BMC or "Baseboard Management Controller" is a system that allows users to remotely monitor and control Supermi- cro devices. To access this system remotely, it is first necessary to configure the BMC network settings from the sys- tem BIOS. -
Page 18: Factory Reset
The BMC web interface should appear on the screen. Fig. 18: BMC login page The default access user and password are teldat/teldat_Operator. This user will only have access for monitoring pur- poses. Once these credentials have been entered, the BMC's main page may be accessed by pushing "Login". -
Page 19: Default Configuration
Note that this boot option is only available for OSDx version v3.9.1.2 or higher. 2.6.1 Default configuration The default configuration of the SDE device is as follows: set interfaces bridge br0 address dhcp set interfaces bridge br0 dhcp client fallback 192.168.1.1/24... -
Page 20: Chapter 3 Compliance
3 Compliance Teldat S.A. Chapter 3 Compliance 3.1 Manufacturer information Dell Brand Manufacturer Dell Technologies Country Contact www.dell.com/support/home. Supermicro Brand Manufacturer Super Micro Computer, Inc. Country Contact www.supermicro.com/en/support. 3.2 Safety warnings The electric current in power cables and communication cables is dangerous. To prevent electric shocks, connect all the cables before applying electrical current. -
Page 21: Ec Declaration Of Conformity
3 Compliance Teldat S.A. 3.5 EC declaration of conformity English (EN) Hereby, Teldat S.A. declares that the radio equipment type SDE is in compliance with: Directive 2014/30/EU (EMC) Directive 2014/35/EU (LVD) Directive 2009/125/EC (ErP) Directive 2011/65/EU (RoHS) of the European Parliament and of the Council. -
Page 22: Appendix A Technical Information
Restart the system. Update any required drivers for the PCIe card. Reinstall the card. A.2 Updating the software The SDE software can be updated to newer versions. Please contact your dealer for information on new releases. For further information, please see manual: “Teldat Dm945-I_Provisioning SDWAN devices" (chapter 5) . A.3 Technical specifications... -
Page 23: Hardware Architecture
2x1100W REGULATORY MODEL SDE-20000-R2 SDE-20000-R2 COMERCIAL CODE SDX6120-28K SDX6120-28KS R660xs Hardware architecture MODELS SDE-20K R2 SDE-22K R2 SDE-24K R2 PROCESSORS Intel® Xeon® Silver 4410Y Intel® Xeon® Gold 6526Y Intel® Xeon® Gold 6448Y 2GHz 12 Core Processor, 2.8GHz 16 Core Processor, 2.1GHz 32 Core Processor,... -
Page 24: Nic
Technical Information Teldat S.A. SuperMicro Hardware architecture MODELS SDE-20K R3 SDE-22K R3 SDE-24K R3 PROCESSORS Intel® Xeon Silver 4510 Intel® Xeon Silver 4516Y+ Intel® Xeon Gold 6530 2.4G, 12C/24T, 16GT/s, 2.2G, 24C/48T, 16GT/s, 2.1GHz, 32C/64T, 16GT/s, 30M Cache, Turbo, HT... -
Page 25: Dimensions And Weight
Technical Information Teldat S.A. A.3.4 Dimensions and weight MODEL DIMENSION WEIGTH Dell PowerEdge R640 21.9 Kg Dell PowerEdge R660 22.51 Kg Dell PowerEdge R660xs 18.25 Kg Supermicro SYS-511E-WR 15.46 Kg A.3.5 Environmental specifications TEMPERATURE NORMAL OPERATION: 10°C to 35°C, with no direct sunlight hitting the equip- ment.
