Specifications
Size/Type
P160-P315, 380-480 V
P355-P710, 380-480 V
Table 8.11 Fan Fuses
Size/Type
P500-P710, 380-480 V
2.5-4.0 A
P500-P710, 380-480 V
4.0-6.3 A
P500-P710, 380-480 V
6.3-10 A
P500-P710, 380-480 V
10-16 A
Table 8.12 Manual Motor Controller Fuses
Frame size
F
Table 8.13 30 A Fuse Protected Terminal Fuse
Frame size
D
E
F
Table 8.14 Control Transformer Fuse
Frame size
Bussmann PN
F
GMC-800MA
Table 8.15 NAMUR Fuse
Frame size
F
Table 8.16 Safety Relay Coil Fuse with PILZ Relay
1) 170M fuses from Bussmann shown use the -/80 visual indicator, -TN/80 Type T, -/110 or TN/110 Type T indicator fuses of the same size and
amperage may be substituted for external use
MG21B202
Operating Instructions
Bussmann PN
1)
KTK-4
Bussmann PN
LPJ-6 SP or SPI
LPJ-10 SP or SPI
LPJ-15 SP or SPI
LPJ-25 SP or SPI
1)
Bussmann PN
LPJ-30 SP or SPI
1)
Bussmann PN
LP-CC-8/10
LP-CC-1 1/2
LPJ-6 SP or SPI
1)
Rating
800 mA, 250 V
1)
Bussmann PN
LP-CC-6
Danfoss A/S © Rev. 2014-01-22 All rights reserved.
LittelFuse
KLK-15
1)
Rating
6 A, 600 V
10 A, 600 V
15 A, 600 V
25 A, 600 V
Rating
30 A, 600 V
Rating
0.8A, 600V
1.5A, 600V
6 A, 600 V
Rating
6 A, 600 V
Rating
4 A, 600 V
15A, 600 V
Alternative Fuses
Any listed Class J Dual
Element, Time Delay, 6A
Any listed Class J Dual
Element, Time Delay, 10 A
Any listed Class J Dual
Element, Time Delay, 15 A
Any listed Class J Dual
Element, Time Delay, 25 A
Alternative Fuses
Any listed Class J Dual Element,
Time Delay, 30 A
Alternative Fuses
Any listed Class CC, 0.8A
Any listed Class CC, 1.5A
Any listed Class J Dual Element,
Time Delay, 6 A
Alternative Fuses
Any listed Class CC, 6 A
91
