Danfoss VLT AQUA Drive FC 202 Operating Instructions Manual page 9

Introduction
1
22
21
19
18
16
1 Local control panel (LCP)
2 Active filter card (AFC)
3 Metal oxide varistor (MOV)
4 Soft charge resistors
5 AC capacitors discharge board
6 Mains contactor
7 LC inductor
8 AC capacitors
9 Mains bus bars to drive input
10 IGBT fuses
11 RFI
Illustration 1.3 Frame Size D13 Filter Enclosure
MG21B202
Operating Instructions
2
3
20
5
17
15
14
13
14
15
16
17
18
19
20
21
22
Danfoss A/S © Rev. 2014-01-22 All rights reserved.
4
6
8
10
11
12
13
Mains fuses
Mains disconnect
Mains terminals
Heat sink fan
DC capacitor bank
Current transformer
RFI differential mode filter
RFI common mode filter
HI inductor
Power card
7
9
7
1 1
