Introduction
1 1

1.4 Enclosure Types and Power Ratings

Frame size
IP
Enclosure
protection
NEMA
High overload rated
power - 160% overload
torque
Drive Height
dimensions
Width
[mm/inch]
Depth
Drive Max Weight
dimensions
Shipping
[kg/lbs]
Weight
Table 1.1 Mechanical Dimensions and Rated Power, D, E and F Frames

1.5 Approvals and Certifications

1.5.1 Approvals

Table 1.2 Compliance Marks: CE, UL, and C-Tick

1.5.2 Compliance with ADN

For compliance with the European Agreement concerning
International Carriage of Dangerous Goods by Inland
Waterways (ADN), refer to ADN-compliant Installation in the
Design Guide.
14
Operating Instructions
D13
21/54
Type 1/Type 12
160-250 kW at 400 V
(380-480 V)
1780.570.1
1021.9 mm/40.23
377.8/14.87
390/860
454/1001
Danfoss A/S © Rev. 2014-01-22 All rights reserved.
E9
21/54*
Type 1/Type 12
315-450 kW at 400 V
(380-480 V)
2000.7/78.77
1200/47.24
493.5/19.43
676/1490
840/1851
F18
21/54
Type 1/Type 12
500-710 kW at 400 V
(380-480 V)
2278.4/89.70
2792/109.92
605.8/23.85
1900/4189
2345/5171
MG21B202
