Mechanical Installation
3 3
1 Front View
2 Left Side View
3 Right Side View
4 Brake Terminals
Illustration 3.17 Frame Size F18 Inverter Cabinet
The gland plate is 42 mm below the 0 level. Shown are the left side view, front, and right.
26
Operating Instructions
1
6
Danfoss A/S © Rev. 2014-01-22 All rights reserved.
2
5 Motor output bus bar
6 Ground bar
7 Screen clamp
4
308.3 [12.1]
253.1 [10.0]
180.3 [7.1]
5
.0 [.0]
44.40 [1.75]
244.40 [9.62]
4
3
