Fluke BT5300 Series User Manual

Fluke BT5300 Series User Manual

Battery tester
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
BT5300 Series
Battery Tester
User Manual
8/2021
© 2021 Fluke Corporation. All rights reserved. Specifications are subject to change without notice.
All product names are trademarks of their respective companies.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BT5300 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Fluke BT5300 Series

Summary of Contents for Fluke BT5300 Series

  • Page 1 BT5300 Series Battery Tester User Manual 8/2021 © 2021 Fluke Corporation. All rights reserved. Specifications are subject to change without notice. All product names are trademarks of their respective companies.
  • Page 3 Each Fluke product is warranted to be free from defects in material and workmanship under normal use and service. The warranty period for BT5300 series and SW1080 is three years, and one year for SW9010, and begins on the date of shipment. Parts, product repairs, and services are warranted for 90 days. This warranty...

  • Page 5: Table Of Contents

    Contents Title Page Introduction ..............................1 Product Overview ..........................1 How to Contact Fluke ..........................2 Safety Information ..........................2 Warning and Caution ........................2 Symbols ............................4 Model Comparison Table ........................4 Operation Features ..........................5 Front Panel ............................. 5 Display Screen..........................
  • Page 6 BT5300 Series User Manual Voltage and Resistance Measurement ....................26 Connect the Cell ........................... 26 Configure the Channel and Function .................... 26 Select Measurement Range ......................27 Set Sampling Rate ........................27 Read the Measured Voltage and Resistance ................27 Enclosure Potential Measurement .......................
  • Page 7 Battery Tester Contents Device Information ..........................63 Restore to Factory Defaults ......................... 64 Zero-Adjust ............................65 Clearing Zero-Adjustment ........................68 Memory Function ..........................68 Remote Control ............................69 Connect the Computer ......................... 69 Remote Control UI ..........................70 Remote Control Commands ........................ 70 System Status Diagram ........................
  • Page 8 BT5300 Series User Manual SW9010 Multiplexer Card ........................130 General Specifications ........................130 Appendix ..............................132 Appendix 1. AC Four-terminal Method ....................132 Appendix 2. Precautions for Making Custom Test Cables ..............133 Making Custom Test Leads for Multiplexer cards ............... 133 Configuring Battery Probe Tips ....................

  • Page 9: Title Page

    Table List Title Page Table 1. Symbols ..........................4 Table 2. Product features table ...................... 4 Table 3. Controls on the front panel ....................6 Table 4. Display screen ........................9 Table 5. Rear panel feaures ......................11 Table 6. Standard equipment .......................
  • Page 11 Figure List Title Page Figure 1. Front panel ........................6 Figure 2. Display screen ........................9 Figure 3. Rear panel ........................11 Figure 4. Standard equipment ....................... 14 Figure 5. Use the tilt stand ......................16 Figure 6. Mains power cord connection ..................17 Figure 7.
  • Page 12 BT5300 Series User Manual Figure 37. Self-Calibration ....................... 62 Figure 38. Device Info. screen ......................63 Figure 40. Zeroing process ......................66 Figure 41. Zeroed ..........................66 Figure 42. Zero adjustment failure prompt ..................67 Figure 43. Zeroing all ranges ......................67 Figure 44.

  • Page 13: Introduction

     High allowable total line resistance Even with the smallest range of 3 mΩ, the Fluke Battery Testers support allowable total line resistance up to 10 Ω, supporting longer and thinner test cables, which greatly reduces the occurrence of mismatches between the test range and the measured value.

  • Page 14: How To Contact Fluke

    Any channel of the Multiplexer Card can be configured to one of the two functions below. AC internal resistance and DC current Enclosure potential contact check How to Contact Fluke Fluke Corporation operates worldwide. For local contact information, go to our website: cn.fluke.com (Chinese) or www.fluke.com/en-us/support/manuals (English).
  • Page 15 Battery Tester Introduction  Do not use the Product around explosive gas, vapor, or in damp or wet environments.  Do not use the Product if it operates incorrectly.  Disable the Product if it is damaged.  Do not use the Product if it is altered or damaged. ...

  • Page 16: Symbols

    Switch Mainframe The following are recommended models for different applications.  Manually use the Instrument or integrate it into the test system but do not use the Fluke switch system 6.5-digit DC V — BT5310 7.5-digit DC V — BT5320...

  • Page 17: Operation Features

    Battery Tester Introduction  System integration application and use the Fluke switch system Recommended Channel count needed DC V tester model ≤ 64 6.5-digit BT5311 7.5-digit BT5321 65 to 256 6.5-digit BT5310 7.5-digit BT5320 257 to 320 6.5-digit BT5311 7.5-digit...
  • Page 18 BT5300 Series User Manual Figure 1. Front panel Table 3. Controls on the front panel Item Description Standby button Set the Product to the standby mode. In the standby mode, the display is off and the buttons do not work. The standby mode also disable remote operation. See the section...
  • Page 19 Battery Tester Introduction Item Description Navigation keys (up, down, left, and right) Press the keys to go through all selectable functions on the screen and select one of them, the currently selected function will be highlighted in yellow. USB port Reserved for future function extension.

  • Page 20: Display Screen

    BT5300 Series User Manual Item Description Trigger Execute the external triggering manually. See the section Trigger for details. Setup Enter the Instrument Setup which includes device information, instrument settings, communication settings. See the section Instrument Setup for details. Channel Enter the Channel Configuration. See the section Input and Channel Configuration for details.
  • Page 21 Battery Tester Introduction The Main Display area is for displaying measurements, compare results. The main display area displays different content depending on the current working mode and location, as detailed in the relevant sections below. The Softkey area is at the bottom of the screen. Some of 5 soft keys may have no label, which means that the key has no functions.
  • Page 22 BT5300 Series User Manual Item Description Measurement function indicator The selected measurement function is displayed when the Module Selection is enabled. See the section Measurement Function for more information about measurement functions. Compare results The judgment result of the comparator is displayed at the upper-left position of the measured value if the Comparator is ON.

  • Page 23: Rear Panel

    Battery Tester Introduction Rear Panel SLOT 1 Figure 3. Rear panel Table 5. Rear panel feaures Item Description Multiplexer cards - Multiplexer cards can be inserted into the Instrument. The Instrument has two built-in slots and up to 2 SW9010 Multiplexer Cards can be installed. See the section Install Multiplexer Cards Connect the Cell...
  • Page 24 BT5300 Series User Manual Item Description Earth Chassis earth. See the section Connect to Power and Ground for details. Control Output connector Connect to SW1080 Switch Mainframe. See the section Connection Between the Product and the Switch Mainframe. Locking screw Each Multiple Card is fastening to the Product or the SW1080 Switch Mainframe though the two screws on the left and right respectively.

  • Page 25: Preparation

    Fluke Technical Service Center or the Service Center in place of purchase. If you need to reship the Product, please use the original package. If the original package is not available, a new package can be ordered from Fluke according to the Product’s model and part number...
  • Page 26 BT5300 Series User Manual SW1080 BT5300 SW9010 Figure 4. Standard equipment Table 6. Standard equipment Item Description Part number BT5300 SW1080 SW9010 Battery Tester main unit BT5310: 5306406 BT5311: 5306414 BT5320: 5306423 BT5321: 5306438 Power cord, 10 A/250 V 2683906...

  • Page 27: Set The Handle Position

    Battery Tester Preparation Item Description Part number BT5300 SW1080 SW9010 1943483 Shield twist cables Connection cable for the Switch 1943483 Mainframe 5306450 Multiplexer cards Safety Information 5309262 shown GOING GREEN CARD 4253109 Table 7. Optional accessories Item Description Part number BTL310 test lead 5306461 Ethernet cable...
  • Page 28 BT5300 Series User Manual Viewing positon Alternate viewing position Carrying position Removal position (to remove, pull ends out) To removal, pull end from unit Boot intallation/removal Figure 5. Use the tilt stand...

  • Page 29: Connect To Power And Ground

    Battery Tester Preparation Connect to Power and Ground The Product is shipped with a mains power cord, 250 V/10 A. Once the power supply voltage is checked and it is properly grounded, use the mains power cord to connect to the Product to the power outlet.

  • Page 30: Power On And Standby

    BT5300 Series User Manual Power on and Standby As shown in Figure 7, the Product has a mains power switch located on the rear panel that supplies power to the unit, and a Standby key ( ) on the front panel that put the Product in the standby mode.

  • Page 31: Inspection Before Testing

    Before using the Product fo the first time, verify that it operates normally to ensure that no damage occurred during storage or shipping. If you find any damage, please contact the nearest Fluke Authorized service center or your Fluke representative. See the section How to Contact Fluke.

  • Page 32: Measuring With Test Leads

    BT5300 Series User Manual Measuring with Test Leads To measure with test leads: Connect the power cord Restore to factory defaults Connect the test leads Select measurement range Set sampling rate Zero-Adjustment Connect to the cell Read the measured voltage and...

  • Page 33: Connect The Power Cord

    Battery Tester Measuring with Test Leads Connect the Power Cord 1. Connect the power cord and power on the Product according to the description in the section Connect to Power and Ground. SLOT 1 Restore to Factory Defaults 2. Reset the Product to factory defaults according to the description in the section Restore to Factory Defaults.

  • Page 34: Select Measurement Range

    BT5300 Series User Manual Select Measurement Range 4. Select the appropriate measurement range according to the description in the section Changing Resistance Range. Set Sampling Rate 5. Select the appropriate sampling rate according to the description in the section Changing Measurement Speed.

  • Page 35: Zero-Adjustment

    Battery Tester Measuring with Test Leads Zero-Adjustment 6. Connect the test leads to the zero-adjust board, zero the Product according to the description in the section Zero-Adjust. Connect to the Cell 7. Connect the probes to the cell. Read the Measured Voltage and Resistance 8.

  • Page 36: Measuring Through Multiplexer Cards

    BT5300 Series User Manual Measuring Through Multiplexer Cards Multiplexer Cards are normally controlled remotely to perform measurements. See the section Input Channel Slection/Route Scan Programming Examples for more information. This example explains how to measure the voltage, internal resistance and enclosure potential of a cell using a single channel manually.

  • Page 37: Install Multiplexer Cards

    Battery Tester Measuring Through Multiplexer Cards Install Multiplexer Cards 1. To measure through Multiplexer Card, one or more Multiplexer cards must be installed into the Product and/or into the Switch Mainframe. Please see the section Built-in Multiplexer Cards External Multiplexer Cards, respectively.

  • Page 38: Connect The Power Cord

    BT5300 Series User Manual Connect the Power Cord 3. Connect the power cord and power on the Product according to th description in the section Connect to Power and Ground. SLOT 1 Voltage and Resistance Measurement Connect the Cell 4. Connect the test cables to a Multiplexer Card in the Product or Switch Mainframe, and to the cell...

  • Page 39: Select Measurement Range

    Battery Tester Measuring Through Multiplexer Cards Select Measurement Range 6. Select the appropriate measurement range according to the description in the section Changing Resistance Range. Set Sampling Rate 7. Select the appropriate sampling rate according to the description in the section Changing Measurement Speed.

  • Page 40: Enclosure Potential Measurement

    BT5300 Series User Manual Enclosure Potential Measurement Connect the Cell 9. Connect the test cables to a Multiplexer Card in the Product or Switch Mainframe, and to the cell under test according to the description in the section Wiring for Enclosure Potential Measurement.

  • Page 41: Positive To Enclosure Voltage

    Battery Tester Measuring Through Multiplexer Cards Read Measurement 12. Read the measured value of the enclosure potential contact check. See the section Display Screen. Reading of enclosure potential contact check Positive to Enclosure Voltage Configure the Channel and Function 13. Configure the channel as following according to the description in the section Configuring Channels: Module Selection: Internal or External...

  • Page 42: Negative To Enclosure Voltage

    BT5300 Series User Manual Read Measurement 15. Read the measured value of positive to enclosure voltage. See the section Display Screen. Positive to enclosure voltage Negative to Enclosure Voltage Configure the Channel and Function 16. Configure the channel as following according to the description in the section...
  • Page 43 Battery Tester Measuring Through Multiplexer Cards Read Measurement 18. Read the measured value of negative positive to enclosure voltage. See the section Display Screen. Negative to enclosure voltage...

  • Page 44: Input And Channel Configuration

    BT5300 Series User Manual Input and Channel Configuration In addition to a set of inputs on the front panel, the Product can also accommodate up to 2 built-in Multiplexer Cards and support up to 8 external Multiplexer Cards. Each Multiplexer Card provides 32 channels, so that the total count of channels reaches 320.

  • Page 45: Multiplexer Cards

    Battery Tester Input and Channel Configuration Figure 9. Connecting test leads Multiplexer cards Built-in Multiplexer Cards The BT5311/BT5321 Battery Tester provides 2 slots used to install up to 2 SW9010 Multiplexer Cards. Each Multiplexer Cards provides 32 channels, so that the total count of channel reaches 64. To install Multiplexer Cards and refer to Figure 1.

  • Page 46: External Multiplexer Cards

    The SW1080 Switch Mainframe provide the Product with the capacity of additional 8 Multiplexer Cards as the external channel. The Switch Mainframe connect from the front panel Control Input connector to the Control Ouput connector on the rear panel of the BT5300 Series Battery Tester. SW1080 Switch Mainframe...
  • Page 47 Battery Tester Input and Channel Configuration Figure 11. Front panel of the Switch Mainframe Figure 12. Rear pannel of the Switch Mainframe Table 9. Switch Mainframe Item Description Sense terminals Sense terminals for 4-wire measurement method used to measure induced voltage drop by AC excitation current.
  • Page 48 BT5300 Series User Manual Item Description Source terminals Source terminals for 4-wire measurement method, used to receive AC excitation current. These terminals are connected to the Source terminals on the front panel of the BT5300 Battery Tester. Ground/Guard terminals Guard connection can provide better shielding effect. These terminals are connected to the Ground/Guard terminals on the front panel of the BT5300 Battery Tester.
  • Page 49 Battery Tester Input and Channel Configuration Item Description Connecter label There are 2 DB-68 connector, Sense and Source, on each of Multiplexer Cards. See the section Connect the Cell for more details. Connection Between the Product and the Switch Mainframe To extend the measurement channel count through the SW1080 Switch Mainframe, please refer to Figure 13, connect the SW1080 to the BT5300 Battery Tester as the following:...

  • Page 50: Connect The Cell

    BT5300 Series User Manual Figure 13. Connecting the Switch Mainframe Connect the Cell The SW9010 Multiplexer Card is used to select from and switch between cells to be tested. Each Multiplexer Card provides total 32 channels (01-32) through two DB-68 connectors. These channels can be configured to measure cell’s voltage and resistance.
  • Page 51 Battery Tester Input and Channel Configuration To connect each channel to a cell, connect the SOURCE CH+ and SENSE CH+ to the positive electrode (+), and connect the SOURCE CH- and SENSE CH- to the negative electrode (-) of the cell. As shown in Figure The channel assignment on each connector of the Multiplexer Card is shown in...
  • Page 52 BT5300 Series User Manual Wiring for Enclosure Potential Measurement To connect each channel to a cell, connect the SOURCE CH+ and SOURCE CH- to the positive and negative electrodes of the cell respectively, connect the both corresponding SENSE CH+ and SOURCE CH- to battery enclosure.

  • Page 53: Channel Configuration

    Battery Tester Input and Channel Configuration Signal Description Signal Description … … … … … CH15+ Channel 15 + CH31+ Channel 31 + CH15- Channel 15 - CH31- Channel 31 - CH16+ Channel 16 + CH32+ Channel 32 + CH16- Channel 16 - CH32- Channel 32 -...
  • Page 54 BT5300 Series User Manual Module: Int.; Slot: 1; Ch.: 01-32 Module: Int.; Slot: 2; Ch.: 01-32 Rear View of the Tester SLOT 1 Ext. CH 108 Switch Mainframe Slot Channel Rear View of the Switch Mainframe (SW1080) Module: Ext.; Slot: 1; Ch.: 01-32 Module: Ext.;...
  • Page 55 Battery Tester Input and Channel Configuration Configuring Channels 1. The Instrument front panel —> 2. The UI for configuring channels is shown in Figure 18, and the meaning of each option is shown in Table Figure 18. Channel configuration 3. Press C (Edit) softkey, and then move the cursor to Module Selection option (the option is highlighted in yellow) using the up/down arrow buttons (MN ).
  • Page 56 BT5300 Series User Manual Table 11. Channel configuration Item Description Module Select whether to use Multiplexer Cards. Selection - Disable. Not to use any Multiplexer Card, and to measure directly use the connections on the front panel of the Product.

  • Page 57: Measurement Function

    Battery Tester Measurement Function Measurement Function As the Product powers on, it will enter the measurement screen by default, as shown in Figure Figure 19. Measurement screen The Product provides DCV and ACR measurement values. The Product measure through the internal or external Multiplexer Card if any channel is selected;...

  • Page 58: Enclosure Potential Contact Check

    BT5300 Series User Manual User selectable measurement range Range Reading Resolution Overflow 3 mΩ 0 to 5 mΩ 0.0001 mΩ >5 mΩ 30 mΩ 0 to 50 mΩ 0.001 mΩ >50 mΩ 300 mΩ 0 to 500 mΩ 0.01 mΩ...

  • Page 59: Positive To Enclosure Voltage

    Battery Tester Measurement Function Figure 20. Enclosure potential contact check Positive to Enclosure Voltage The measurement range/resolution is same with DCV measurement. “Positive to Enclosure Voltage” is displayed at the upper left of the screen, as shown in Figure See the section Enclosure Potential Measurement.

  • Page 60: Changing Measurement Speed

    BT5300 Series User Manual Figure 22. Negative to enclosure voltage Changing Measurement Speed In the measurement screen, press A (Speed) softkey to switch between different speeds: Ex- Fast, Fast, Medium, and Slow. Changing Resistance Range In the measurement screen, press C (Ω Range) softkey to switch between different ranges:...

  • Page 61: Instrument Setup

    Battery Tester Instrument Setup Instrument Setup The Instrument Setup screen contains general instrument settings, such as UI language, device information, factory reset, and the line frequency, test current, input impedance and trigger delay can be set; the communication settings of remote interfaces are also provided. This section explains in detail the functions and operation of the Instrument Setup menu, which will be used directly in the subsequent sections and will not be repeated.

  • Page 62: Language Settings

    BT5300 Series User Manual Language Settings Users can select the language supported by this unit. The Product now support English and Chinese UI language. To change UI language: 1. In the Instrument Setup screen, use the up and down arrow (M N) buttons on the front panel to move the cursor to the Language option (the option is highlighted in yellow).

  • Page 63: Comparator

    Battery Tester Instrument Setup Note If the 300 mA measurement current is used, the Instrument will be more sensitive to the eddy current of the measuring loop circuit. If the test can’t be completed with a large measurement current, you can reduce the effects of eddy current on test cables, or the system refer to Appendix 3.
  • Page 64 BT5300 Series User Manual 6. Use the up/down arrow (M N) buttons on the front panel to select DCV Lower Threshold option, then use the numeric keypad to enter a voltage, in V, in the DCV Lower Threshold editbox, which can include a decimal point.

  • Page 65: Average

    Battery Tester Instrument Setup 13. The Beeper Setting screen is shown in Figure 27, And the meaning of each option is listed in Table Figure 27. Beeper setting Table 12. Beeper setting Item Both DCV and ACR are within Any one of DCV and ACR are out of thresholds the threshold No beeps sound...
  • Page 66 BT5300 Series User Manual To set the average function: 1. In the Instrument Setup screen, use the up and down arrow (M N) buttons on the front panel to move the cursor to the Average option (the option is highlighted in yellow), then press D (Edit) on the front panel to enter the Average screen.

  • Page 67: Trigger

    Battery Tester Instrument Setup Figure 30. Setting average count 6. Press D (OK) to return to the previous screen. If you press E (Cancel), the Product discards all changes and returns to the previous screen. Note If the number entered is out of the range of 02 to 16, an error message is shown on the screen, as shown in the following figure.

  • Page 68: Trigger Delay

    BT5300 Series User Manual Trigger Delay A certain time value can be specified through the Trigger Delay setting, which allows the Instrument to delay the measurement by the specified time after receiving the trigger signal or a trigger command. Trigger delay range is from 0 ms to 9999 ms, with default of 0 ms. The trigger delay applies to internal trigger and external trigger.

  • Page 69: Input Impedance

    Battery Tester Instrument Setup Figure 32. Switch trigger delay ON or OFF 4. Use the up and down arrow (M N) buttons to select the Trigger Delay option (the option is highlighted in yellow), then press D (Edit). 5. Enter a number from 0 to 9999, in the Set trigger Delay to editbox using the numeric keypad on the front panel.

  • Page 70: Remote Interface

    BT5300 Series User Manual Figure 34. Selecting input impedance Note The default input impedance is 10 MΩ. It is recommended to use High-Z (>10GΩ) option for high impedance device under test, such as enclosure potential measurement. 3. Press D (OK) to confirm the selection and return to the Instrument Setup screen.
  • Page 71 Battery Tester Instrument Setup Figure 35. Remote interface setting Table 13. Remote interface parameters Item Options RS232 Type Ethernet CR (Carriage Return) LF (Line Feed) CRLF (Carriage Return & Line Feed)
  • Page 72 BT5300 Series User Manual Item Options DHCP Options include: - ON - OFF To communicate using the Ethernet interface, the user can choose to trun on the DHCP function. If set DHCP to be ON but failed due to network connection, DHCP will change to OFF automatically and all other parameters, such as IP address, subnet mask, default gateway, etc., will be set to the last static address.

  • Page 73: Power Frequency

    Battery Tester Instrument Setup Item Options RS-232 communication settings are as follows: Baud Rate Baud rate that the Instrument support: - 9600 - 19200 - 38400 - 57600 - 115200 Data Bits The number of data bits supported by the instrument includes: - 7 Bits - 8 Bits RS232 Setup...

  • Page 74: Self-Calibraion

    BT5300 Series User Manual Figure 36. Select power frequency 3. Press D (OK) to confirm the selection and return to the Instrument Setup screen. If you press E (Cancel), the Instrument returns to the Instrument Setup screen and not save any change.

  • Page 75: Device Information

    All information listed in the Device Info. screen is reference information and cannot be changed. This information is useful for troubleshooting and maintenance. Note Please have this information ready when contacting Fluke for technical support. Table 14. System Information Item...

  • Page 76: Restore To Factory Defaults

    BT5300 Series User Manual Item Description Switch Serial No. External The serial number of the external Switch Mainframe. Restore to Factory Defaults To reset the Instrument to the factory defaults: 1. In the Instrument Setup screen, press B (Factory Reset).

  • Page 77: Zero-Adjust

    Gateway Port 1500 RS232 Setup Baud Rate 9600 Data Bits Stop Bits Parity None Not shown in Customer defined FLUKE screen manufacturer Customer defined BUND model SCPI command header Memory INIT Continuous Zero-Adjust Execute zero adjustment before measuring to nullify any residual offset voltage from the instrument or measurement environment.
  • Page 78 BT5300 Series User Manual To do the zero adjustment: 1. Connect the testing leads to the zero-adjust board to create the close to 0 Ω status. See the section Appendix 4. Zero Adjustment. 2. Press on the font panel to enter measurement screen.
  • Page 79 Battery Tester Instrument Setup Figure 41. Zero adjustment failure prompt In the Auto range mode (see the section Changing Resistance Range), when the user presses the Instrument will try to zero all measurement ranges. As shown in Figure Figure 42. Zeroing all ranges Note Zero adjustment can only remove the offset of 1000 digits for ACR and 1 mV for DCV measurement.

  • Page 80: Clearing Zero-Adjustment

    BT5300 Series User Manual Clearing Zero-Adjustment In the Instrument Setup screen, press A (Clear Zero-adjust), the zero-adjust value will be cleared. The Clear Zero-adjust softkey is available only after that the Product is zeroed. After clearing, the screen will not display “Zero Adjusted” indicator.

  • Page 81: Remote Control

    To order a RS-232 to USB adapter cable, see Table 6 and the section How to Contact Fluke. To connect through the Ethernet interface: As shown in method B of Figure 44, connect a Ethernet cable from the Ethernet port (f in Figure on the rear panel of the Product to a Ethernet port on the computer.

  • Page 82: Remote Control Ui

    BT5300 Series User Manual Remote Control UI When the Instrument is connected to a computer and communicates, the Product will enter the remote state. The screen under remote control is as shown in Figure Figure 45. Remote control UI In the remote-control mode, all buttons except F5 and Trigger on the front panel are locked. The measurement screen of the Product will change according to the remote setting parameters.
  • Page 83 Battery Tester Remote Control Some commands require parameter data to specify values for one or more parameters. The command header is separated from the parameter data by a space (20 hex or 32 decimal). Multiple parameters are separated by a comma (,). The Instrument’s input buffer capacity is 512 bytes.

  • Page 84: System Status Diagram

    BT5300 Series User Manual System Status Diagram QUEStionable Status Error Queue NOT USED NOT USED NOT USED NOT USED NOT USED NOT USED NOT USED NOT USED NOT USED NOT USED NOT USED Memory Overflow SYST:ERR? NOT USED NOT USED...
  • Page 85 Battery Tester Remote Control Table 17. QUEStionable Status registor Bit No. Bit Name Description Bit 0 NOT USED Not used Bit 1 NOT USED Not used Bit 2 NOT USED Not used Bit 3 NOT USED Not used Bit 4 NOT USED Not used Bit 5...
  • Page 86 BT5300 Series User Manual Bit No. Bit Name Description Bit 11 Measure Done One measurement is done. Bit 12 Ready for Initiate Trigger Ready for Initiate Trigger (*TRG or Trigger key) when INIT:CONT OFF and TRIG:SOUR EXT. Bit 13 NOT USED...

  • Page 87: List Of Commands

    Battery Tester Remote Control List of Commands Table 21. List of commands Command Header Data Format Description [ ]: Omissible [ ]: Omissible ( ): Response data { }: Customized parameter definition* |: Or IEEE-488.2 Common Commands *CLS Clear the Status Byte Register and all event registers, and clear the Error Queue.
  • Page 88 BT5300 Series User Manual Command Header Data Format Description [ ]: Omissible [ ]: Omissible ( ): Response data { }: Customized parameter definition* |: Or Status Reporting Commands STATus:OPERation[:EVE (<NR1 (0 to 32767)>) Query and clear the Operation Nt]? Status register.
  • Page 89 Battery Tester Remote Control Command Header Data Format Description [ ]: Omissible [ ]: Omissible ( ): Response data { }: Customized parameter definition* |: Or Remote Interface Commands SYSTem:LOCal Cancel the communication (remote) state. Factory Reset Commands SYSTem:RESet Restore factory settings. Line Power Frequency Commands SYSTem:LFReqency {F50Hz | F60Hz}...
  • Page 90 BT5300 Series User Manual Command Header Data Format Description [ ]: Omissible [ ]: Omissible ( ): Response data { }: Customized parameter definition* |: Or VOLTage:RANGe? ({1.000000E+01 | 1.0000000E+01}) Query the voltage measurement range. SAMPle:RATE {EXFast | FAST | MEDium | SLOW} Set the sampling speed.
  • Page 91 Battery Tester Remote Control Command Header Data Format Description [ ]: Omissible [ ]: Omissible ( ): Response data { }: Customized parameter definition* |: Or CALCulate:LIMit:RESis ({HI | IN | LO | OFF | ERR}) Query the comparator resistance tance:RESult? judgment results.
  • Page 92 BT5300 Series User Manual Command Header Data Format Description [ ]: Omissible [ ]: Omissible ( ): Response data { }: Customized parameter definition* |: Or ROUTe:SCAN <channel_list> Set the channel scan list. SWITch:MODule {DISable | INTernal | EXTernal} Set the switch module selection.

  • Page 93: Message Reference Interpretation

    Battery Tester Remote Control Message Reference Interpretation IEEE-488.2 Common Commands *CLS Description Clear the Status Byte Register and all event registers, and clear the Error Queue. *CLS Examples *ESE Description Set the Standard Event Status Enable register. < NR1 (0 to 255)> Parameters Binary-weighted decimal value.
  • Page 94 BT5300 Series User Manual FLUKE,BUND,54010008WS,0 .06,0.04,1.8,0.02,0.02 *OPC Description Set the Bit 0 (Operation Complete) in the Standard Event Status register. *OPC Examples *OPC? Description Return a “1” to the instrument’s output buffer. *OPC? Examples A “1” is placed in the instrument output buffer.

  • Page 95: Status Reporting Commands

    Battery Tester Remote Control *TRG Description Trigger one measurement. *TRG Examples *TST? Perform self-test and return the result. Returns “0” if the test succeeds, “1” if the Description test fails. *TST? Examples *WAI Wait for previous operations to finish. Command required by IEEE-488.2 Description standard.
  • Page 96 BT5300 Series User Manual STATus:QUEStionable[:EVENt]? Description Query and clear the Questionable Status register. (<NR1 (0 to 32767)>) Refer to the System Status Diagram. Response SYST:QUES? Examples 2048 STATus:QUEStionable:ENABle Description Set the Questionable Status Enable register. (<NR1 (0 to 32767)>) Response Refer to the System Status Diagram.

  • Page 97: System-Related Commands

    Battery Tester Remote Control System-Related Commands SYSTem:CALibration Description Execute one self-calibration. SYST:CAL Examples SYSTem:CUSTom:MANufacturer Set the customized instrument manufacturer name. Max length of parameter is Description <Character> Parameters SYST:CUST:MAN Examples "CUSTFLUKE" SYSTem:CUSTom:MANufacturer? Description Query the customized instrument manufacturer name. <Character> Response SYST:CUST:MAN? Examples...
  • Page 98 BT5300 Series User Manual Parameters <Boolean> = OFF or 0 Disable the command header to be sent with response message. = ON or 1 Enable the command header to be sent with response message. SYST:HEAD ON Examples SYSTem:HEADer? Description Query the state whether the command header to be sent with response message.

  • Page 99: Remote Interface Commands

    Battery Tester Remote Control Remote Interface Commands SYSTem:LOCal Description Cancel the communication (remote) state, and return to the local control mode. SYST:LOC Examples Factory Reset Commands SYSTem:RESet Description Restore factory settings. The same as the “Factory Reset” in the instrument UI menu.

  • Page 100: Measurement Configuration Commands

    BT5300 Series User Manual Measurement Configuration Commands ADJust? Execute zero adjustment and return the result (success or fail). Valid when switch Description module selection is DISable. The acceptable range of zero adjustment for both resistance and voltage is ±1000 digits.
  • Page 101 Battery Tester Remote Control AUTorange? Description Query the resistance measurement auto range setting. <Boolean> Response AUT? Examples INPut:IMPedance:HIGH Description Enable or disable the input high impedance (>10 GΩ). <Boolean> Parameters = OFF or 0 Disable the input high impedance, and use 10 MΩ...
  • Page 102 BT5300 Series User Manual = RV Measurement function is ACR+DCV, READ? and FETCh? return readings including ACR and DCV. = RESistance Measurement function is ACR, READ? and FETCh? return readings including ACR. = VOLTage Measurement function is DCV, READ? and FETCh? return readings including DCV.
  • Page 103 Battery Tester Remote Control RESistance:CURRent:MAX Description Set the maximum measurement current. This parameter only applies to the 3 mΩ resistance range. { C100 | C200 | C300} Parameters = C100 The maximum measurement current is 100 mA. = C200 The maximum measurement current is 200 mA. = C300 The maximum measurement current is 300 mA.

  • Page 104: Calculate Commands

    BT5300 Series User Manual SAMPle:RATE Description Set the sampling speed. {EXFast | FAST | MEDium Parameters | SLOW} = EXFast The sample time is 10 ms. = FAST The sample time is 20 ms. = MEDium The sample time is 100 ms.
  • Page 105 Battery Tester Remote Control CALCulate:AVERage Description Set the number of samples to be averaged. <NR1 (2 to 16)> Parameters CALC:AVER 2 Examples CALCulate:AVERage? Description Query the number of samples to be averaged. <NR1 (2 to 16)> Response CALC:AVER? Examples Comparator CALCulate:LIMit:STATe Description Enable or disable the comparator function.
  • Page 106 BT5300 Series User Manual = BOTH1 The beeper sounds continuously upon IN judgments, and repeatedly upon Hi and Lo judgments. = BOTH2 The beeper sounds once (briefly) upon IN judgments, and repeatedly upon Hi and Lo judgments. CALC:LIM:BEEP HL Examples...
  • Page 107 Battery Tester Remote Control CALCulate:LIMit:VOLTage:UPPer? Description Query the comparator voltage upper threshold (in V). <NRf (0 to 11)> Response CALC:LIM:VOLT:UPP? Examples CALCulate:LIMit:RESistance:LOWer Description Set the comparator resistance lower threshold (in mΩ). <NRf (0 to 15000)> Parameters CALC:LIM:RES:LOW 3 Examples Select the comparator resistance lower threshold to be 3 mΩ.

  • Page 108: Memory Commands

    BT5300 Series User Manual = HI The measured value is higher than the upper threshold. = IN The measured value is between the upper and lower threshold. = LO The measured value is lower than the lower threshold. = OFF The Comparator function is disabled or SENSe:FUNCtion is PEVoltage/NEVoltage.
  • Page 109 Battery Tester Remote Control Note  The continuous measurement needs to be enabled to use the storage function.  Maximum memory storage capacity is 512 measurements. Be aware that attempting to store more data (by applying a trigger) results in nothing further being stored. ...
  • Page 110 BT5300 Series User Manual MEMory:COUNt? Description Query the count of memory data. <NR1 (0 to 512)> Response MEM:COUN? Examples MEMory:DATA? Description Query the memory data. Ended with the string “END”. For FUNCtion = Return pairs of value. In each pair of data, the...
  • Page 111 Battery Tester Remote Control For FUNCtion = Return pairs of value. In each pair of data, the RESistance: value is the resistance value (ACR), and the <NR1>,<NR3>,<NR3> value is the voltage value (DCV). … <NR1>,<NR3>,<NR3> For FUNCtion = VOLTage: Return pairs of value. In each pair of data, the <NR1>,<NR3>,<NR3>...

  • Page 112: Trigger Commands

    BT5300 Series User Manual Trigger Commands Table 22. Trigger mode table Measurement Continuous Measurement Command-Specific Settings flow INITiate:CONTinuous ON INITiate:CONTinuous OFF Free-Run state. Measurement continues Start measurement by INITiate (or automatically. READ?) command. Triggered by TRIG Key or *TRG command.
  • Page 113 Battery Tester Remote Control INITiate:CONTinuous Description Enable or disable the continuous measurement. Continuous measurement can only be set by Remote command. Continuous measurement is enabled when operation is returned to the Local state or power is ON. <Boolean> Parameters = OFF or 0 Disable continuous measurement.
  • Page 114 BT5300 Series User Manual TRIGger:SOURce? Description Query the trigger source. {IMMEDIATE | EXTERNAL} Response TRIG:SOUR? Examples IMMEDIATE TRIGger:DELay:STATe Description Enable or disable the trigger delay. <Boolean> Parameters = OFF or 0 = ON or 1 TRIG:DEL:STAT ON Examples TRIGger:DELay:STATe? Query the trigger delay state.

  • Page 115: Reading Measured Values Commands

    Battery Tester Remote Control Reading Measured Values Commands Measurement Value Formats • (in Ω) Resistance Resistance range Remote returned value Measurement fault 6.5-digit resolution 7.5-digit resolution 3 mΩ ±□□.E-03 ±□□□.E-03 Table 23. Measurement value formats (measurement 30 mΩ ±□□.E-02 ±□□□.E-02 fault).
  • Page 116 BT5300 Series User Manual For FUNCtion = Returns the voltage value (DCV). PEVoltage, <NR3>,…,<NR3> For FUNCtion = Returns the voltage value (DCV). NEVoltage, <NR3>,…,<NR3> For FUNCtion = RV: Returns pairs of value. In each pair of data, the <NR3>,<NR3>,…,<NR3>, value is the resistance value (ACR), and the <NR3>...

  • Page 117: Switch Relay Card Commands

    Battery Tester Remote Control Switch Relay Card Commands ABORt Description Scanning is aborted (forcibly terminated). ABORt Examples ROUTe:CLOSe Description Closes the specified channel. <channel_list (1 Parameters Only one channel can be closed at a time. channel)> ROUT:CLOS (@102) Examples Close channel 102 in internal/external switch module (depends on SWIT:MOD?).
  • Page 118 BT5300 Series User Manual Examples SWIT:MOD INT SWITch:MODule? Query the switch module selection. Description {DISABLE | INTERNAL | Response EXTERNAL} SWIT:MOD? Examples INTERNAL SWITch:MODule:STATe? Query the specified switch module’s slots state. Description {INTernal | EXTernal} Parameters For NTernal switch Response modules, <NR1 (0 or 1)>,<...

  • Page 119: Remote Command Examples

    Battery Tester Remote Control Remote Command Examples Compound Headers Using a Tree – Usage and Examples Figure 47 presents the instrument command structure that has implemented compound headers using a tree structure. Headers were chosen with short form mnemonic value. Figure 47.

  • Page 120: Input Channel Slection/Route Scan Programming Examples

    BT5300 Series User Manual The following examples would cause an error as described: • :CALC:AVER:STATE ON;MEM:STATE ON<PMT> The second <PROGRAM MESSAGE UNIT> would cause an error, since node “MEM” is not a sub-node of “CALC”. The parser attempts to execute the command “:CALC:AVER:MEM:STATE ON”, which is illegal.
  • Page 121 Battery Tester Remote Control Command Action STATus:OPERation? Query the Operation Status register until the Bit 11 (Measure Done) is set. FETCh? Return the latest reading (voltage and/or resistance). 3. Enable continuous initiation, FETCh one measurement Command Action SWITch:MODule DISable Configure the instrument to measure the signal from the front panel input post without using internal/external switch channels.
  • Page 122 BT5300 Series User Manual Command Action STATus:OPERation? Query the Operation Status register until the Bit 11 (Measure Done) is set. FETCh? Return the latest reading (voltage and/or resistance). 3. Enable continuous initiation, FETCh one measurement Command Action SWITch:MODule DISable Configure the instrument to measure the signal from the front panel input post without using internal/external switch channels.
  • Page 123 Battery Tester Remote Control Command Action INITiate Initiate one measurement. STATus:OPERation? Query the Operation Statues register until the Bit 11 (Measure Done) is set. FETCh? Return the latest reading (voltage and/or resistance). 3. Enable continuous initiation, FETCh one measurement Command Action SWITch:MODule INTernal Configure the instrument to use the internal switch channel as...
  • Page 124 BT5300 Series User Manual Command Action INITiate Initiate the instrument to Trigger Wait State. *TRG Trigger one measurement (Trigger Key signal can achieve the same result). STATus:OPERation? Query the Operation Statues register until the Bit 11 (Measure Done) is set.
  • Page 125 Battery Tester Remote Control Command Action measurement input channel. TRIGger:SOURce IMMediate Configure the trigger source to be internal. ROUTe:CLOSe (@102) Configure channel 102 to be measurement input channel. INITiate:CONTinuous OFF Disable continuous measurement. INITiate Initiate one measurement. STATus:OPERation? Query the Operation Statues register until the Bit 11 (Measure Done) is set.
  • Page 126 BT5300 Series User Manual 2. Disable continuous initiation, FETCh one measurement Command Action SWITch:MODule EXTernal Configure the instrument to use the external switch channel as measurement input channel. TRIGger:SOURce EXTernal Configure the trigger source to be external. ROUTe:CLOSe (@102) Configure channel 102 to be measurement input channel.
  • Page 127 Battery Tester Remote Control Command Action FUNCtion RVOLtage Configure to measure the ACR+DCV. INITiate:CONTinuous OFF Disable continuous measurement. INITiate Initiate scan. STATus:OPERation? Query the Operation Statues register until the Bit4 (Sweep Done) and Bit 8 (Scan Done) is set. FETCh? Return the latest reading (32 pairs of voltage and resistance).
  • Page 128 BT5300 Series User Manual Module External, One-Shot Scan, Internal Trigger In this scenario it is desired to scan and measure several external switch channels in a one-shot fashion under internal triggering. Command Action *RST Reset the instrument to the power-on state.

  • Page 129: Memory Programming Examples

    Battery Tester Remote Control Command Action *TRG Trigger one measurement (Trigger key signal can achieve the same result). STATus:OPERation? Repeat the last 2 steps until the Bit 4 (Sweep Done) and Bit 8 (Scan Done) of the Operation Status register is set. FETCh? Return the latest reading (32 pairs of voltage and resistance).
  • Page 130 BT5300 Series User Manual Command Action as measurement input channel. If the external triggering is used, the following steps are the same. FUNCtion RVOLtage Configure to measure the ACR+DCV. MEMory:STATe ON Enable memory function and clear stored memory data. ROUTe:CLOSe (@xxx) Configure channel xxx to be measurement input channel.

  • Page 131: List Of Error Message

    Battery Tester Remote Control List of Error Message Error Code Error Name No error -100 Command error -101 Invalid character -102 Syntax error -103 Invalid separator -104 Data type error -105 GET not allowed -108 Parameter not allowed -109 Missing parameter -110 Command header error -111...
  • Page 132 BT5300 Series User Manual Error Code Error Name -128 Numeric data not allowed -130 Suffix error -131 Invalid suffix -134 Suffix too long -138 Suffix not allowed -140 Character data error -141 Invalid character data -144 Character data too long...
  • Page 133 Battery Tester Remote Control Error Code Error Name -183 Invalid inside macro definition -184 Macro parameter error -200 Execution error -201 Invalid while in local -202 Settings lost due to rtl -203 Command protected -210 Trigger error -211 Trigger ignored -212 Arm ignored -213...
  • Page 134 BT5300 Series User Manual Error Code Error Name -231 Data questionable -232 Invalid format -233 Invalid version -240 Hardware error -241 Hardware missing -250 Mass storage error -251 Missing mass storage -252 Missing media -253 Corrupt media -254 Media full...
  • Page 135 Battery Tester Remote Control Error Code Error Name -274 Macro parameter error -275 Macro definition too long -276 Macro recursion error -277 Macro redefinition not allowed -278 Macro header not found -280 Program error -281 Cannot create program -282 Illegal program name -283 Illegal variable name -284...
  • Page 136 BT5300 Series User Manual Error Code Error Name -312 PUD memory lost -313 Calibration memory lost -314 Save/recall memory lost -315 Configuration memory lost -320 Storage fault -321 Out of memory -330 Self-test failed -340 Calibration failed -350 Queue overflow...
  • Page 137 Battery Tester Remote Control Error Code Error Name -600 User request -700 Request control -800 Operation complete...

  • Page 138: Maintenance

    It is only necessary to replace the fuse as needed. Change the Fuse Please refer to the Figure Figure 48. Change the Fuse W Caution To prevent damage to the instrument, use only the fuses specified by Fluke. Please see the section Table 7 How to Contact Fluke.

  • Page 139: Calibration

    Battery Tester Maintenance To change the fuse: 1. Turn off the Product, unplug the power cord from mains power connector, and disconnect all test leads. 2. Insert a flat screwdriver into the clip under the fuse box and gently pry it until it is possible to hold the fuse holder by hand and take it out.

  • Page 140: Specifications

    BT5300 Series User Manual Specifications BT5300 Battery Tester Measurement Items Measurement Items ACR, DCV, enclosure potential measurement Measurement method AC 4-wire method (1 kHz) Rated input DC ± 11 V Input impedance 10 MΩ or high-Z（>10 GΩ） ≤10 Ω @ 3 mΩ Range...

  • Page 141: Sw1080 Switch Mainframe

    BT5310/BT5311: Ex-Fast: ±50 µV; Fast: ±30 µV; Medium: ±10 µV BT5320/BT5321: Ex-Fast: ±50 µV; Fast: ±20 µV; Medium: ±5 µV SW1080 Switch Mainframe Number of slots Card supported SW9010 Multiplexer card Max. input voltage DC ±11V Power supply and control Powered and controlled by BT5300 Series Batter Tester.

  • Page 142: Sw9010 Multiplexer Card

    BT5300 Series User Manual SW9010 Multiplexer Card Wiring 4-wire connection Number of channels 32 channels On/Off time 3 ms, typical Channel switching Open before close Maximum allowed voltage DC ± 10 V Maximum allowed current 750 mA 1.5 Ω, typical...
  • Page 143 Class A: Equipment meets requirements for industrial electromagnetic wave equipment and the seller or user should take notice of it. This equipment is intended for use in business environments and not to be used in homes. Warranty BT5300 Series 3 years SW1080 3 years...

  • Page 144: Appendix

    BT5300 Series User Manual Appendix Appendix 1. AC Four-terminal Method The instrument uses the AC four-terminal method. Generally, when measuring small resistances, the four-wire resistance measurement method should be used as much as possible. This is because when measuring resistance using two-wire method, the resistance of test leads and contact resistance will introduce additional errors, which often have a greater influence when measuring a small resistance.

  • Page 145: Appendix 2. Precautions For Making Custom Test Cables

    Battery Tester Appendix Appendix 2. Precautions for Making Custom Test Cables Making Custom Test Leads for Multiplexer cards Multiplexer Cards use 68-pin D connectors to connect batteries to be test. For the pin definition of the connectors, see the section Multiplexer cards.
  • Page 146 BT5300 Series User Manual For separate tips, the SOURCE and SENSE test points are at different positions, measured internal resistance is closer to the internal resistance of the battery, and measurement result is usually smaller than that of the concentric tips. The further the distance of two test points, the smaller the effect of the resistance of battery tabs.

  • Page 147: Appendix 3. Effect Of Eddy Currents And Suggested Solution

    Figure 52. BTL310 test lead In the design of the Fluke test lead, the SENSE and SOUCE lines connected to the Instrument are separated. This design ensures that most area of the test lead are hardly affected by eddy currents...

  • Page 148: Suggested Scheme: Use Twisted Pair

    BT5300 Series User Manual Suggested Scheme: Use Twisted Pair Twisted pair segments: magnetic fields generated by currents cancel out each other Cell Loop areas: magnetic fields are generated by currents Figure 53. Schematic diagram of twisted pair test To reduce the error due to the eddy current, we recommended to use twisted pair for SOURCE and...

  • Page 149: Suggested Optimization Scheme: Reduce The Overlap Of Loops

    Battery Tester Appendix Suggested Optimization Scheme: Reduce the Overlap of Loops Cell Avoid overlapping of SOURCE and SENSE loop areas Cell Avoid overlapping of SOURCE and SENSE loop areas Figure 55. Reducing the effect of eddy current by reducing the overlap area of loops The loop wiring of the SOURCE and SENSE wire is designed to avoid overlap as much as possible, which can reduce the effect of eddy current.
  • Page 150 BT5300 Series User Manual Placing a magnetic field shielding material between the loop area and the conductor can also reduce the effect of eddy currents. As shown in Figure 56, the magnetic shielding material should be a material with high magnetic permeability and not easy to conduct electricity. The shielding material can restrain the magnetic field inside it, and the magnetic field on the nearby conductor metal is obviously weakened;...

  • Page 151: Appendix 4. Zero Adjustment

    Battery Tester Appendix Appendix 4. Zero Adjustment Zero adjustment is a function which adjusts the zero point by deducting the residual value obtained during 0 Ω measurement. For this reason, zero adjustment must be performed when connection is made to 0 Ω. However, connecting a sample with zero resistance is difficult and therefore is not practical.

  • Page 152: Zeroing Using A Zero-Adjust Board

    BT5300 Series User Manual , are usually less than 10 Ω or lower, land SENSE-HI Because the cable resistances, R and R and SENSE-LO are voltage measurement terminals with high input impedance, almost no current flows. Therefor I = 0. The voltage between SENSE-HI and SENSE-LO is almost 0 V.

  • Page 153: Zeroing Using Custom Zero-Adjust Board, Probes Or Clip Type Leads

    Battery Tester Appendix Using the zero-adjust board Using a metal board or similar object Equivalent circuit Constant current source Constant current source Voltmeter Voltmeter SOURCE-HI SENSE-HI SENSE-LO SOURCE-LO SOURCE-HI SENSE-HI SENSE-LO SOURCE-LO Short Short Resistance between Short SENSE-HI and SENSE- →...

  • Page 154: Appendix 5. Scan Mode To Improve Test Efficiency

    OCV test benches will bring additional cost. Adding battery testers to the same OCV system will bring the problem of mutual interference between instruments. The Fluke Battery Tester has built-in Multiplexer Cards, through a unique scan mode, it can not only ensure the high stability of the test results, but also maximize the test efficiency.

  • Page 155: Example Commands For Scan Mode

    Battery Tester Appendix Table 26. Comparison of channel switching and test process Channel switching Battery Tester Circuit Send a command Closes the Wait until Send a Send the FETCH? to close a specified the relay is Fetch? Measure result to Mode channel channel...
  • Page 156 BT5300 Series User Manual INITiate:CONTinuous OFF Disable continuous measurement INITiate Start scanning STATus:OPERation? Query scan state FETCh? Query readings, the following is the returned results. Voltage of CH1 Resistance of CH2 Resistance of CH1 Table 28 lists the typical values of the time to complete the voltage and internal resistance measurement of 256 channels at different sampling rate, that is, the time the PC takes from sending INITiate to obtaining all readings by sending FETCH?.

  • Page 157: Appendix 6. Use Bt5300 To Measure Internal Resistance, Open-Voltage, And Enclosure Potential

     6.5-digit DMM: enclosure potential measurement The BT5300 Series integrates a 6.5- or 7.5-digit voltmeter with high-z (>10 GΩ) inputs, a single instrument can complete these tests. The following takes the BT5321 as an example to introduce how to complete these tests through the input terminals on the front panel or built-in Multiplexer Card(s).
  • Page 158 BT5300 Series User Manual Figure 59. Schematic diagram of switching circuit - front panel Figure 59, SOURCE HI, SOURCE LO, SENSE HI and SENSE LO correspond to the front panel input terminals of BT5321; K1, K2, K3 and K4 are relays, numbers 1~6 represent probe tips, and line segments represent connected test cables.
  • Page 159 Battery Tester Appendix Command Action voltage measurement range of 10 V. RESistance:CURRent:MAX C300 Set the current range, such as 300 mA. If 300 mA test current cannot complete the test due to the test system, it can be adjusted to 200 mA (RESistance:CURRent:MAX C200) or 100 mA (RESistance:CURRent:MAX C100).

  • Page 160: Measuring Through Rear Panel Multiplexer Cards

    BT5300 Series User Manual Measure the voltage between the probe tips 2 and 6, or voltage between the probe tips 3 and Command Action *RST Reset the Instrument. FUNCtion VOLTage Set the function to DCV measurement. SAMPle:RATE FAST Set an appropriate test speed, such as “Fast”.
  • Page 161 Battery Tester Appendix Figure 61. Schematic diagram of switching circuit - rear panel See the section Connect the Cell for more details about wiring method. Remote Control Commands The following describes how to test 32 cells by using Scan Mode. See the section Appendix 5.
  • Page 162 BT5300 Series User Manual Command Action SAMPle:RATE SLOW Set the test speed, such as “Low”. SWITch:MODule:STATe? Query the state of the internal Multiplexer Cards. In this INTernal case, return “1, 1” if the states of both SW9010s in slot 1 and slot 2 are normal.
  • Page 163 Battery Tester Appendix Command Action STATus:OPERation? Query the Operation Status register until the Bit 4 (Sweep Done) and Bit 8 (Scan Done) is set. FETCh? After querying that the corresponding bit in the previous step is set or waiting until all channel switching and measurement are completed, send this command to obtain internal resistance readings (in Ω) of 32 channels.

  • Page 164: Appendix 7. Instrument Installation

    BT5300 Series User Manual Appendix 7. Instrument Installation Introduction This sheet explains how to use the rack-mount kit (the Kit) to mount the BT5300 Battery Tester (the Product) into a standard 19-inch rack panel. XW WARNING To prevent possible injury, do not restrict access to the Product power cord, which is the mains disconnecting device.

  • Page 165: Install A Dual Rack-Mount Kit

    Battery Tester Appendix 2. Attach the other rack bracket (②) to the left-front side of the Product with three #8-32 x ½ inch panhead screws (①). 3. With three M6 panhead hex screws (⑤), and three nuts, fasten the right-side of Rack Faceplate (③) to the left side of rackmount.
  • Page 166 BT5300 Series User Manual 5. Install the entire assembly from the rear of the rack, aligning the holes of the Rack Bracket (②) to the inside of the rack frame. At the front of the rack, use six M6 panhead hex screws (⑤) and nuts to fasten the Rack Screw Plate (④) through the rack and Rack Brackets (②).

  • Page 167: Overall Dimensions Of The Product

    Battery Tester Appendix Overall Dimensions of the Product 212,2 129,0 [8.35] [5.08] 64,5 [2.54] 66,3 [2.61] 318,0 [12.52] 382,5 [15.06] 42,3 [1.66] 44,1 44,5 [1.73] [1.75] 14,8 [0.58] 215,8 [8.50] 132,6 [5.22] Figure 65. Overall dimensions of the Product...

  • Page 168: Appendix 8. Sw1080 Appearance

    BT5300 Series User Manual Appendix 8. SW1080 Appearance Figure 66. SW1080 appearance...
