Page 1 PM3370B - PM3380B - PM3390B PM3384B - PM3394B Autoranging CombiScope Instrument Service Manual 4822 872 05372 3/1-Dec-00 TRACE AUTO SET SETUPS UTILITY ANALOG ACQUIRE SAVE RECALL MEASURE MATH DISPLAY HARD COPY INTENSITY STATUS CURSORS TRIGGER MAGNIFY X POS ∆ TRACK HOLD OFF TEXT LOCAL...
Page 3: Table Of Contents
CONTENTS TABLE OF CONTENTS Page SAFETY INSTRUCTIONS ............1-1 INTRODUCTION.
Page 4 CONTENTS HOLD-OFF ..............2-15 PROCESSING .
Page 5 CONTENTS 2.19 ACCESSORIES ............2-32 2.20 OPTIONS &...
Page 6 CONTENTS MICROPROCESSOR A3 ........... . 5.3-1 5.3.1 Description A3 .
Page 7 CONTENTS PERFORMANCE TEST ............6-1 GENERAL INFORMATION .
Page 8 VIII CONTENTS CALIBRATION ADJUSTMENT PROCEDURE ........7-1 INTRODUCTION.
Page 9 CONTENTS REMOVING THE UNITS, MECHANICAL PARTS AND CRT ......8-4 8.5.1 Removing the rotary knobs ..........8-4 8.5.2 Detachment of ribbon cables .
Page 10 ® DECLARATION OF CONFORMITY Autoranging CombiScope Instrument PM3370B, PM3380B, PM3390B PM3384B, PM3394B Manufacturer Fluke Industrial B.V. Lelyweg 1 7602 EA Almelo The Netherlands Statement of Conformity Based on test results using appropriate standards, the product is in conformity with Electromagnetic Compatibility Directive 89/336/EEC...
Page 11: Safety Instructions
SAFETY INSTRUCTIONS 1 - 1 SAFETY INSTRUCTIONS Read these pages carefully before installation and use of the instrument. INTRODUCTION The following paragraphs contain information, cautions and warnings which must be followed to ensure safe operation and to keep the instrument in a safe condition. WARNING: Servicing described in this manual is to be done only by qualified service personnel.
Page 12 Components which are important for the safety of the instrument may only be replaced by components obtained through your local FLUKE organisation. (See also section 9). After repair and maintenance in the primary circuit, safety inspection and tests, as mentioned in...
Page 13: Characteristics
CHARACTERISTICS 2 - 1 CHARACTERISTICS Performance Characteristics Properties expressed in numerical values with tolerances, ranges, or limits stated, are guaranteed by the manufacturer. Properties expressed in numerical values without tolerances, ranges, or limits stated, represent the characteristics of an average instrument. This specification is valid if the temperature has not changed more than + or - 5 °C since the last AUTO CAL, the probe is of the same type as delivered with the instrument, and if the average factor is 8.
Page 14: Vertical
2 - 2 CHARACTERISTICS CHARACTERISTICS SPECIFICATIONS ADDITIONAL INFORMATION VERTICAL 2.1.1 Channels CHANNELS CH1; CH2; Form a channel set CH3; CH4 Form a channel set See Note 1 Note 1: CH1 and CH2 for PM3370B, PM3380B and PM3390B. 2.1.2 Deflection Modes (Analog Only) MODES CH1, CH2, CH3, CH4 See Note 1...
Page 15: Bandwidth
CHARACTERISTICS 2 - 3 CHARACTERISTICS SPECIFICATIONS ADDITIONAL INFORMATION 2.1.3 Bandwidth FREQUENCY RESPONSE At BNC Lower transition point of bandwidth input coupling in AC pos <10 Hz PM3394B/90B Upper transition point of bandwidth (Ambient 5 to 40 °C) >200 MHz See Note 1 (Ambient 0 to 50 °C) >175 MHz See Note 1...
Page 16: Input Characteristics
2 - 4 CHARACTERISTICS CHARACTERISTICS SPECIFICATIONS ADDITIONAL INFORMATION 2.1.5 Input Characteristics INPUT CONNECTOR See Note 1 INPUT IMPEDANCE Measured at freq. (in 1 MΩ pos.) <1MHz R parallel-value 1 MΩ ±1 % - tolerance C parallel-value 25 pF ±2 pF - tolerance INPUT INPEDANCE PM3390B on CH1 and CH2...
Page 17: Input Voltage Limits
CHARACTERISTICS 2 - 5 CHARACTERISTICS SPECIFICATIONS ADDITIONAL INFORMATION 2.1.10 Input Voltage Limits INPUT VOLTAGE LIMITS See Note 1 ± 400V In high Z position See Note 2 (dc + ac peak) In 50Ω position ± 5V ac rms See Note 3 ±...
Page 18: Signal Delay
2 - 6 CHARACTERISTICS CHARACTERISTICS SPECIFICATIONS ADDITIONAL INFORMATION 2.1.12 Signal Delay A: VISUAL SIGNAL DELAY 15 ns PM3390B94B 13 ns PM3370B/80B/84B DELAY BETWEEN CHANNELS CH1 and CH2 <250 ps PM3370B/80B/90B CH1..CH4 <250 ps PM3384B/94B 2.1.13 Vertical Accuracies ACCURACY deflection factor ±1.3 % A: Gain error (dc) Over central 6 divisions...
Page 19: Timebase
CHARACTERISTICS 2 - 7 CHARACTERISTICS SPECIFICATIONS ADDITIONAL INFORMATION TIMEBASE 2.2.1 Timebase (modes) TIMEBASE MODES MTB only MTB= Main Timebase MTB and DTB Alternating TB-mode DTB only DTB = Delayed Timebase Variable TB Auto TB MTB trigger modes AUTO Free run after 100 ms TRIGGERED SINGLE SHOT SINGLE SCAN...
Page 20: Timebase Settings (Digital Mode Only)
2 - 8 CHARACTERISTICS CHARACTERISTICS SPECIFICATIONS ADDITIONAL INFORMATION 2.2.4 Timebase Settings (Digital Mode Only) MTB Settings REAL TIME SAMPLING 200s/div to 250 ns/div See Note 1 and 4 ROLL 200s/div to 200 ms/div See Note 2 RANDOM SAMPLING PM3390B/94B 200 ns/div to 2 ns/div See Note 2 PM3370B/80B/84B 200 ns/div to 5 ns/div...
Page 21: Dtb Delay (Digital Mode Only)
CHARACTERISTICS 2 - 9 CHARACTERISTICS SPECIFICATIONS ADDITIONAL INFORMATION 2.2.6 DTB Delay (Digital Mode Only) TRIGGERED DELAY TIME 2 ns to 4.9 s Position range 0.1 div to 9.9 div Resolution 1 : 40000 STARTS DELAY TIME 0 to 10 div of MTB setting Position range 0 div to 10 div Resolution...
Page 22: Dtb Jitter In Starts (Digital Mode)
2 - 10 CHARACTERISTICS CHARACTERISTICS SPECIFICATIONS ADDITIONAL INFORMATION 2.2.11 DTB Jitter In Starts (Digital Mode) Jitter 120 ps 2.2.12 External Horizontal Deflection This paragraph is valid only for the analog mode. In the digital mode X versus Y is defined as a display mode.
Page 23: Triggering
CHARACTERISTICS 2 - 11 CHARACTERISTICS SPECIFICATIONS ADDITIONAL INFORMATION TRIGGERING 2.3.1 Source MTB trigger sources PM3384B/94B CH1 to CH4, Line PM3370B/80B/90B CH1, CH2, Line, EXT TRIG DTB trigger sources PM3384B/94B CH1 to CH4 PM3370B/80B/90B CH1, CH2 2.3.2 Modes MODES MTB triggering PM3384B/94B EDGE, TV, D:PATTERN,...
Page 24: Coupling
2 - 12 CHARACTERISTICS CHARACTERISTICS SPECIFICATIONS ADDITIONAL INFORMATION 2.3.4 Coupling BANDWIDTH EDGE TRIGGER MTB Vertical coupling in DC Lower transition point of BW BW = Bandwidth Trigger coupling: 10 Hz LF-reject 30 kHz HF-reject Upper transition point of BW BW = Bandwidth Trigger coupling: )See sensitivity LF-reject...
Page 25: Sensitivity
CHARACTERISTICS 2 - 13 CHARACTERISTICS SPECIFICATIONS ADDITIONAL INFORMATION 2.3.5 Sensitivity EDGE TRIGGER SENSITIVITY MTB and DTB of: See Notes 1, 3, 4 PM3390B/94B dc to 100 MHz 0.6 div dc to 200 MHz 1.2 div dc to 300 MHz 2.0 div See Note 2 PM3380B/84B dc to 50 MHz...
Page 26: Level
2 - 14 CHARACTERISTICS CHARACTERISTICS SPECIFICATIONS ADDITIONAL INFORMATION 2.3.7 Level LEVEL CONTROL RANGE MTB ≥±8 div EDGE Unless: In level p(eak)p(eak) See Note 1 Fixed D: PATTERN, STATE PM3370B/80B/90B: ±5 div and GLITCH glitch mode only LEVEL CONTROL RANGE DTB ≥±8 div EDGE Note 1: The control range of the trigger level is related to the peak-peak value and duty cycle of the...
Page 27: Trigger Accuracies
CHARACTERISTICS 2 - 15 CHARACTERISTICS SPECIFICATIONS ADDITIONAL INFORMATION 2.3.9 Trigger Accuracies TRIGGER LEVEL ≤0.2 div Accuracy edge At 1 MHz input signal ≤0.4 div Accuracy logic At 1 MHz input signal Trigger gap edge 0.4 div At 1 MHz input signal in noise trigger multiply by 2 FALSE TRIGGERS 1:100 000...
Page 28: Processing
2 - 16 CHARACTERISTICS CHARACTERISTICS SPECIFICATIONS ADDITIONAL INFORMATION PROCESSING 2.6.1 Preprocessing PREPROCESSING FUNCTIONS See Note 1 Invert CH2; CH4 CH1+CH2; CH3+CH4; See Note 2 Subtract CH1-CH2; CH3-CH4; See Note 2 Peak detection Real time only Average See Note 3 Envelope Note 1: These functions are performed before the acquisition data is stored in the acquisition registers.
Page 29: Trace Measurements (Digital Mode)
CHARACTERISTICS 2 - 17 CHARACTERISTICS SPECIFICATIONS ADDITIONAL INFORMATION TRACE MEASUREMENTS (DIGITAL MODE) TRACE MEASUREMENTS FUNCTIONS See Note 1 Horizontal Frequency Period PM3370B/80B/90B: Pulse width CH1, CH2 Rise / fall Vertical (with or without offset) Mean Maximum Minimum Peak/peak PM3370B/80B/90B: CH1, CH2 High Overshoot Preshoot...
Page 30: Cursor Readouts
2 - 18 CHARACTERISTICS CHARACTERISTICS SPECIFICATIONS ADDITIONAL INFORMATION 2.8.2 Cursor Readouts CURSOR READOUTS See Note 1 V to GND 1/dT See Note 1 dQ(Q1, Q2) See Note 2 T-trig See Note 3 READOUT RESOLUTION 3 digits Note 1: In the "MTB + DTB timebase" and "DTB", all waveform operations and measurements are performed on the DTB traces.
Page 31: Digital Acquisition
CHARACTERISTICS 2 - 19 CHARACTERISTICS SPECIFICATIONS ADDITIONAL INFORMATION DIGITAL ACQUISITION 2.9.1 Modes MODES Select one: Recurrent Single shot/scan Roll Stop on trigger continuous 2.9.2 Sample Rate Real time Max. Sample 250 ns/div to 200s/div rate 200MS/s See Note 1 Equivalent time: Random sampling See Note 1 PM3390B/94B...
Page 32: Trace Memory
2 - 20 CHARACTERISTICS CHARACTERISTICS SPECIFICATIONS ADDITIONAL INFORMATION 2.9.4 Trace Memory PM3384B/PM3394B This digitizer has a total acquisition memory size of 32K bytes. To apply this memory as efficiently as possible, it is shared by all channels connected to it. The following section summarizes the effects: Record length normal 1 to 4 channels selected 512 samples/channel...
Page 33: Acquisition Time
CHARACTERISTICS 2 - 21 CHARACTERISTICS SPECIFICATIONS ADDITIONAL INFORMATION 2.9.5 Acquisition Time The process time between acquisitions depends from the selected settings and the selected processing. Therefore it is not possible to catch the process time between acquisitions in a formula. The next table gives an indication of the performance of the processing capabilities.
Page 34: Register Manipulations
2 - 22 CHARACTERISTICS CHARACTERISTICS SPECIFICATIONS ADDITIONAL INFORMATION 2.9.8 Register Manipulations Clear The contents of the selected register is set to zero Save The contents of the acquisition register is stored in the selected register Copy The contents of a selected register is stored in another selected register Recall...
Page 35: Display
CHARACTERISTICS 2 - 23 CHARACTERISTICS SPECIFICATIONS ADDITIONAL INFORMATION 2.12 DISPLAY 2.12.1 CRT Deflection Electrostatic Vector Dimensions (hxw) 80 mm x 100 mm 8 x 10 divisions Phospor Standard Green GH (P31) GRATICULE Fixed 90 ° ±0.5 ° Y-AXIS ORTHOGONALITY ACCELERATING VOLTAGE 16.5 kV Writing speed >1.8cm/ns...
Page 36: Horizontal Display Manipulations (Digital Mode)
2 - 24 CHARACTERISTICS CHARACTERISTICS SPECIFICATIONS ADDITIONAL INFORMATION 2.12.4 Horizontal Display Manipulations (Digital Mode) TIMEBASE MAGNIFICATION 2, 4, 8, 16, 32 See Note 1 Note 1: For acquisition depth greater than 512 byte it is possible to make the magnification factor less than one (compress mode) to display the complete trace on the screen.
Page 37: Optional External Interfaces
CHARACTERISTICS 2 - 25 CHARACTERISTICS SPECIFICATIONS ADDITIONAL INFORMATION BAUDRATE 75,110,150,300 Receiving and 600,1200,2000, transmitting 2400,4800,9600 Default:1200 19200,38400 See Note 1 NUMBER OF STOP BITS PARITY odd,even,or no Default: no parity See Note 1 CHARACTER LENGTH 7 or 8 Default:8 See Note 1 ERROR RESPONSE See CPL, Chapter 6 in Users Manual...
Page 38: Printers And Plotters Support
2 - 26 CHARACTERISTICS CHARACTERISTICS SPECIFICATIONS ADDITIONAL INFORMATION 2.13.4 Printers and plotters support PRINTERS HP-thinktjet LQ1500 FX80 HP-LASER HP-540 PLOTTERS HPGL HP7440 HP7550 HP7475A HP7478A PM8277 PM8278 2.13.5 Real Time Clock (RTC) Select: Time of trigger Note 1 Time of pressing hardcopy button Note 2 Note1: These times may be the same when it is not possible to reconstruct the time of trigger.
Page 39: Power Supply And Battery Backup
CHARACTERISTICS 2 - 27 CHARACTERISTICS SPECIFICATIONS ADDITIONAL INFORMATION 2.15 POWER SUPPLY AND BATTERY BACKUP 2.15.1 Power Supply LINE VOLTAGE ac (rms) Operation 100V to 240V ±10% Tolerance LINE FREQUENCY Nominal 50 Hz to 400 Hz Limits of operation 45 Hz to 440 Hz LINE WAVEFORM At nominal source Max.
Page 40: Mechanical Characteristics
2 - 28 CHARACTERISTICS CHARACTERISTICS SPECIFICATIONS ADDITIONAL INFORMATION 2.16 MECHANICAL CHARACTERISTICS PORTABLE VERSION Dimensions: Handles excluded Length 481 mm (19 in) Add 5 mm (0.2 in) for cover Add 65 mm (2.5 in) for handle Width 341 mm (13,5 in) Add 50 mm (2 in) for handle Height 139 mm ( 5,5 in)
Page 41: Emi
CHARACTERISTICS 2 - 29 CHARACTERISTICS SPECIFICATIONS ADDITIONAL INFORMATION Note 1: In accordance with MIL-T-28800D par. 3.7.2.1.1. (FIGURE 2). Note 2: In accordance with MIL-T 28800D par. 3.7.3. Note 3: Maximum operating temperature derated to 3 °C for each km above sea level Note 4: In accordance with MIL-T-28800D par.
Page 42 2 - 30 CHARACTERISTICS CHARACTERISTICS SPECIFICATIONS ADDITIONAL INFORMATION 2.17.3.4 Additional EMI requirements The instrument is tested in accordance with IEC 351-1 par. 5.1.3.1. The maximum deflection factor is 7 mm/mT (0.7 mm/gauss). This value measured with the instrument in a homogeneous field (in any direction with respect to the instrument) with a flux intensity (peak to peak value) of 1.42 mT (14.2 gauss) and of symmetrical sine wave form with a frequency of 45 Hz to 66 Hz.
Page 43 CHARACTERISTICS 2 - 31 CHARACTERISTICS SPECIFICATIONS ADDITIONAL INFORMATION The PM3390B and PM3394B, including standard accessories, conform with the EEC Directive 89/336 for EMI immunity, as defined by IEC 801-3, with the addition of the following tables. Table 5. Susceptibility: no visible disturbance Frequency range: E = <...
Page 44: Safety
2 - 32 CHARACTERISTICS CHARACTERISTICS SPECIFICATIONS ADDITIONAL INFORMATION 2.18 SAFETY MEETS REQUIREMENTS OF IEC 348 Class I See Note 1 UL 1244 See Note 2 CSA C22.2 No231 See Note 2 VDE 0411 See Note 1 APPROVALS (applied for) CSAC22.2 No231 MAX.
Page 45: Options Analog
CHARACTERISTICS 2 - 33 CHARACTERISTICS SPECIFICATIONS ADDITIONAL INFORMATION 2.20.3 Options analog EXTERNAL INTERFACES Y-out, MTB gate, See Note 1, DTB-gate, ExtTrig. Factory installed only IEEE Factory installed only Note 1: Ext trig is a standard feature in PM3370B/80B/90B. For characteristics refer to chapter 1.3.5. 2.20.4 Specification optional outputs Y SIGNAL OUT Source...
Page 46: Specification External Trigger Option
2 - 34 CHARACTERISTICS CHARACTERISTICS SPECIFICATIONS ADDITIONAL INFORMATION 2.20.5 Specification External trigger option Valid for ext trig option in PM3384B/94B (External trigger input is a standard feature in PM3370B/80B/90B) SOURCE SOURCE(S) MTB-triggering CH1 ... CH4 External Line INPUT CHARACTERISTICS INPUT CONNECTOR At rear of instrument INPUT IMPEDANCE Measured at freg.
Page 47: Specification Ieee-Option
CHARACTERISTICS 2 - 35 2.20.6 Specification IEEE-OPTION TYPE OF INTERFACE ANSI/IEEE 488.2 SCPI (see SCPI programming manual) See Note 1 INTERFACE REPERTORY Source handshake Complete capability Acceptor handshake Complete capability Talker Basic talker: yes Serial poll : yes Talk only : yes Unaddress if MLA: yes Listener Basic listerner: yes...
Page 48 2 - 36 CHARACTERISTICS...
Page 49 DESCRIPTIONS 3 - 1 Figure 3.1 Blockdiagram, Digital part...
Page 50 3 - 2 DESCRIPTIONS Figure 3.2 Blockdiagram, Analog part 1...
Page 51 DESCRIPTIONS 3 - 3 Figure 3.3 Blockdiagram, Analog part 2...
Page 52 3 - 4 DESCRIPTIONS...
Page 53: Descriptions
DESCRIPTIONS 3 - 5 DESCRIPTIONS GENERAL DESCRIPTION 3.1.1 Introduction to oscilloscope family The family consists of seven digital general purpose oscilloscopes with model numbers PM3370B, PM3380B, PM3384B, PM3390B, and PM3394B. Differences between these models are the vertical bandwidth, the features of the vertical channels and the presence of switcheable 50Ω input impedance.
Page 54: Explanation Of Signal Names
3 - 6 DESCRIPTIONS 3.1.3 Explanation of signal names Throughout the circuit diagrams signal names are used. These names make it easier to trace a signal going from one circuit diagram to another. In many cases the signal name and also the component to which a certain node is connected are given in the circuit diagrams.
Page 55: Block Diagram Description
DESCRIPTIONS 3 - 7 Some important notes: To measure some signals, it is necessary to unlock units. Refer to chapter 8.5 for details on how to proceed. The given AC and DC signals are average values: your oscilloscope under test may deviate from the values given in the circuit diagrams.
Page 56: Vertical Channels
3 - 8 DESCRIPTIONS 3.2.2 Vertical channels There are 4 vertical channels that are mainly identical. A difference is that the 200 MHz oscilloscope versions have a switchable 50Ω input impedance while the 100 MHz and 60 MHztypes do not have this feature.
Page 57: Triggering And Time Bases
DESCRIPTIONS 3 - 9 3.2.3 Triggering and time bases The sections for Main Time Base (MTB) and Delayed Time Base (DTB) are for the greater part identical. Therefore the MTB part is extensively described and then the DTB part briefly. The EXTernal TRIGger input of the 2 channel versions is only different in the attenuator part, after that it is equal to and described as CH4.
Page 58: Final Amplifiers
3 - 10 DESCRIPTIONS An output signal from DTB TRIGGER FILTERS + AMPLIFIERS can be used for X DEFLection (MTB and DTB are off then) via the block TIME BASE / X DEFLECTION INPUT CIRCUIT. The function of DTB CURRENT SOURCE, DTB TIMING and DTB SAWTOOTH PICK OFF is identical to the corresponding blocks in the MTB section.
Page 59: Front Unit And Microprocessor
DESCRIPTIONS 3 - 11 Intensity and focusing. The FINAL Z INPUT STAGE receives input signal for trace intensity (ZS) from the Z CONTROL block in the time base section. A second input signal (ZD) determines the intensity (Z) component of the text information.
Page 60: Digitizer
3 - 12 DESCRIPTIONS The LINE IN voltage is applied to the LINE FILTER. This block prevents line interference from entering the supply unit. Also interference generated by the power supply does not enter the mains. An output signal of the filter is applied to the LINE TRIGGER PICK OFF in order to facilitate line triggering of the time bases.
Page 61 DESCRIPTIONS 3 - 13 3.2.7.1 Input stage Four input channel signals for channels 1, 2, 3, and 4 from the analog oscilloscope section are applied to the digitizer unit via eight coaxial cables. Each of these symmetrical input channel signals is splitted in two equal signals by a signal buffer and SPLITTER.
Page 62 3 - 14 DESCRIPTIONS With events selected, the trigger detection unit catches the first edge. With this edge it enables an event counter in the DATA ACQUISITION AND TRIGGER LOGIC. When it has finished counting the required number of events, a second stage in the trigger detection unit is enabled to catch the last event clock.
Page 63 DESCRIPTIONS 3 - 15 The SBUS (serial bus interface) is part of the DARLIC circuit. It is supporting a very limited number of capabilities. Its register is controlling two open collector I/O pins, SDA (serial data) and SCL (serial clock), and a select line SSEL. The buffer enables the DSP to read the status on the SDA and SCL lines.
Page 64 3 - 16 DESCRIPTIONS 3.2.7.8 Bus Arbiter and Trace Generator The major function of the BUS ARBITER AND TRACE GENERATOR (BATGE) is the arbitration between multiple processors, multiple memories and memory mapped I/O with a minimum of interference. Wait cycles for memory devices are programmable and active devices like the DARLIC circuit for example, generate a "not ready signal".
Page 65: Parts
PARTS 4 - 1 PARTS UNITS Item Ordering code Description 5322 214 91839 A1 Signal unit PM3370B 5322 214 91501 A1 Signal unit PM3380B 5322 214 90898 A1 Signal unit PM3384B 5322 214 91838 A1 Signal unit PM3390B 5322 214 90724 A1 Signal unit PM3394B 5322 216 04243 A2 XYZ amplifier unit 100 MHz...
Page 66: Interconnection Cables
4 - 2 PARTS INTERCONNECTION CABLES Figure 4.2 Units lay-out and Interconnections Item Ordering code Description 5322 321 21616 Line cord European type 5322 321 10446 Line cord USA type 5322 321 21617 Line cord British type 5322 321 21618 Line cord Swiss type 5322 321 30387 Line cord Australian type...
Page 67 PARTS 4 - 3 Figure 4.3 Cable locations, top side Figure 4.4 Cable locations, bottom side...
Page 68: Mechanical Parts
4 - 4 PARTS MECHANICAL PARTS Figure 4.5 Mechanical parts, front and side panel...
Page 69 5322 455 81178 Textstrip BNC’s PM3384B 5322 455 81207 Textstrip BNC’s PM3380B/70B 5322 447 70121 Front cover 5322 455 81181 Textstrip handle Fluke 5322 498 50326 Handle complete 5322 455 81141 Textstrip CRT controls 5322 462 41848 Handle cover 5322 498 50268...
Page 70 4 - 6 PARTS Figure 4.6 Mechanical parts, rear panel Item Ordering code Description 5322 219 82813 Mains input connector 4822 070 33152 Fuse 5x20 3,15 AT see interconnections Line cord 5322 492 70941 Contact spring single see chapter 2.10.2 Batteries 5322 456 90426 Battery compartment cover...
Page 71 PARTS 4 - 7 Figure 4.7 Mechanical parts inside instrument Item Ordering code Description 5322 464 90708 Chassis complete 5322 447 91923 Front frame 5322 381 11276 Bezel 5322 480 30181 Blue contrast filter 5322 414 20568 Power on/off knob 5322 361 10614 5322 255 41227 Heatsink...
Page 72 4 - 8 PARTS Figure 4.8 Mechanical parts behind front panel Note: for items not listed refer to chapter 4.1.2 and 4.2. Item Ordering code Description 5322 460 60404 CRT frontrubber 5322 462 40957 Light conductor 5322 134 41076 Lamp 28V 80mA (E 1001) 5322 492 71668 Earth contact @ top of front 5322 492 71669...
Page 73 PARTS 4 - 9 Figure 4.9 Mechanical parts, bottom view Item Ordering code Description 5322 267 10004 BNC connector Z-mod 5322 290 34022 Solder tag for Z-mod 5322 401 10954 Clamp for delay line (plastic) 5322 290 61045 Earth contact CRT shielding...
Page 74 4 - 10 PARTS Figure 4.10 Mechanical parts, screening of input circuit Item Ordering code Description 5322 466 30405 Top shielding 5322 466 30404 Bottom shielding 5322 256 91792 BNC holder 5322 267 10191 BNC coax connector 5322 462 41847 BNC insulator, plastic 5322 532 21188 BNC spacer...
Page 75: Signal Unit A1
UNIT DESCRIPTIONS 5.1 - 1 UNIT DESCRIPTIONS SIGNAL UNIT A1 5.1.1 Description A1 5.1.1.1 Introduction With the exception of the final stages, unit A1 incorporates the vertical channels, the triggering, the time bases and the intensity (Z) control. The unit A1 description is split into the following chapters: Input attenuators and calibrator.
Page 76 5.1 - 2 UNIT DESCRIPTIONS 5.1.1.2 Input attenuators and calibrator Diagram 1, 2, 3, 4 The attenuators of channels 1, 2, 3 and 4 are identical, therefore only channel 1 is explained. Every attenuator basically consists of four sections. These sections are: The input circuit with 50Ω...
Page 77 UNIT DESCRIPTIONS 5.1 - 3 The signal ATCAL is applied to /33 attenuator R1008/R1009. ATCAL can supply several accurate voltages that are used for vertical calibrations. Impedance converter This active stage consists of three sections with different frequency ranges. The sections partly make use of the same components: The HF section for frequencies above 5 kHz.
Page 78 5.1 - 4 UNIT DESCRIPTIONS Calibrator This circuit is used for probe adjustment. It is built up around triple analog multiplexer D1151. The sections D1151/1,2,10,15 and D1151/3,4,5,9 form a 2 kHz oscillator. The third section D1151/11,12,13,14 switches in the 2 kHz rate of the oscillator. The oscillation principle is now explained with the simplified diagram in the figure.
Page 79 UNIT DESCRIPTIONS 5.1 - 5 The amplifier D1201 can be switched to a number of attenuation/gain positions that are dependent on the channel 1 AMPL position. The gain x1 position is determined by R1205/R1206/C1205 that are present across pin 6 and 7. The x1 is switched by control signal PA1X1. The attenuation /2 is determined by R1207 and switched by PA1/2.
Page 80 5.1 - 6 UNIT DESCRIPTIONS The balanced output signals FNC1DPO0 and FNC1DPO1 at pin 9 and 10 can be used to provide signals for digital signal storage. The signals are routed via the coaxial sockets X1301 and X1302 to the sockets X8001 and X8002 on digitizer unit A8. This is present on all 4 channels. Biasing current for these outputs is provided via V1302, V1313 and R1307.
Page 81 UNIT DESCRIPTIONS 5.1 - 7 D5503 gives the necessary inversion of the main trigger path if channel 2 is in the inverted mode. The signal CNT4MTI-HT that is present at pin 4 of AND gate D5503 gives inversion of the main trigger path if channel 4 is in the inverted mode.
Page 82 5.1 - 8 UNIT DESCRIPTIONS DLEN0-HT (Data Latch ENable) and DLEN1-HT determine if D9001 or D9002 reacts on the SDA/SCL signals. The figure below indicates the relation between SDA and SCL. DATA LINE CHANGE STABLE: OF DATA DATA VALID ALLOWED ST6265 Figure 5.3 Relation of serial bus signals SDA and SCL...
Page 83 UNIT DESCRIPTIONS 5.1 - 9 5.1.1.5 Main and delayed time base triggering Diagram 12 The main time base triggering (MTR) is mainly formed by IC D6541. The other IC D6621 is the peak- peak detector for the trigger level. The balanced input signal for triggering on vertical channels 1, 2, 3 or 4 is applied to pin 7 and 8.
Page 84 5.1 - 10 UNIT DESCRIPTIONS The set/reset flipflops D6779 make the field 1 (MTRTVFLD1) and field 2 (MTRTVFLD2) pulses. As input signals are used the output signals at pin 7 and 3 of N6771. The multiplexers D6781 and D7771 select the TV and line trigger sources for MTR and DTR: The MTB TV trigger signal is MTRTVSYNC.
Page 85 UNIT DESCRIPTIONS 5.1 - 11 TBNOTTR-HT goes high if the MTB is not triggered. TBSEL selects MTB if high and DTB if low. TBSSG-HT goes high at the end of a single sweep. DSOM (pin 2) goes high if a MTB trigger occurs. The connected circuit with V8023/8024 generates signal DSOMOUT that is routed via coax socket X8011 to socket X8503 on digitizer unit A8.
Page 86 5.1 - 12 UNIT DESCRIPTIONS Diagram 16 This diagram indicates the timing circuits for the MTB. The principle of the time base is that a capacitor is charged with a constant current. This gives a time-linear voltage across the capacitor; the so- called sawtooth or sweep signal.
Page 87 UNIT DESCRIPTIONS 5.1 - 13 The table shows the active main time base sections as a function of time/div setting: main time base Time Current source Charge Timing caps Hold off caps /div MTBI2 .I10 Current C6012 C6013 C6415 C6017 V6005/c MTBC2 MTBC3...
Page 88: Signal Name List
5.1 - 14 UNIT DESCRIPTIONS output stage). The output voltage XCAL at the horizontal deflection plates of the CRT is measured and horizontal calibrations are performed. During normal oscilloscope functioning the multiplexer connects pin 3 + 4 and pin 13 + 11. This switches V7093 and V7094 on and the feedback paths for MTB and DTB are interrupted.
Page 89 UNIT DESCRIPTIONS 5.1 - 15 AT1/001 /1 ATTENUATOR SELECTION CH1 D9001:11 K1003:01 AT1/010 /10 ATTENUATOR SELECTION CH1 D9001:11 K1004:01 AT1/100 /100 ATTENUATOR SELECTION CH1 D9001:11 K1006:01 AT1/2.5 /2.5 ATTENUATOR SELECTION CH1 D9001:11 V1017:01 AT12REP COMMON FOR ALL RELAIS CH 1, 2 D9001:11 K1001...
Page 90 5.1 - 16 UNIT DESCRIPTIONS AT4PROBE PROBE DETECTION SIGNAL CH4 X4002:04 R4096:05 AT4PROT 50Ω PROTECTION CH4 R4011:04 N1101:05 AT4.50E 50Ω INPUT IMPEDANCE SELECTION CH4 D9002:11 K4001:04 AT4/001 /1 ATTENUATOR SELECTION CH4 D9002:11 K4003:04 AT4/010 /10 ATTENUATOR SELECTION CH4 D9002:11 K4004:04 AT4/100 /100 ATTENUATOR SELECTION CH4 D9002:11...
Page 91 UNIT DESCRIPTIONS 5.1 - 17 FNC2DTR0 DTB TRIGGER ON CH2 OUTPUT SIGNAL 0 D2301:08 R7524:14 FNC2DTR1 DTB TRIGGER ON CH2 OUTPUT SIGNAL 1 D2301:08 R7523:14 FNC2MTR0 MTB TRIGGER ON CH2 OUTPUT SIGNAL 0 D2301:08 R6524:12 FNC2MTR1 MTR TRIGGER ON CH2 OUTPUT SIGNAL 1 D2301:08 R6523:12 FNC2OUT0...
Page 92 5.1 - 18 UNIT DESCRIPTIONS PA1OUT1 OUTPUT SIGNAL 1 CH1 V1201:06 R1302:08 PA1X1 GAIN X1 CONTROL CH1 D9003:11 D1201:06 PA1X5 GAIN X5 CONTROL CH1 D9003:11 D1201:06 PAVREF PREAMPL REFERENCE VOLTAGE N1251:06 R1200:06 R2200:06 R3200:07 R4200:07 PA2/2 ATTENUATION /2 CONTROL CH2 D9003:11 D2201:06 PA2ICL...
Page 93 UNIT DESCRIPTIONS 5.1 - 19 SERIAL CLOCK X9001:18 D9009:10 D9001:11 D9002:11 D9003:11 D9004:11 D9006:16 D9007:17 D9008:15 D9011:12 D9012:14 N8005:15 N9001:11 N9002:11 N9003:11 R8403:16 SERIAL DATA X9001:18 D9009:10 D9001:11 D9002:11 D9003:11 D9004:11 D9006:16 D9011:12 N8005:15 N9001:11 N9002:11 N9003:11 R8404:16 STRCALD-HT RESET FLIPFLOP AUTOPOS Y-CURSOR X9001:18 V8065:15 V8007:15...
Page 94 5.1 - 20 UNIT DESCRIPTIONS TBSEL TIME BASE MTB/DTB SELECTION R5501:10 R6018:16 R7028:17 R8072:15 TBSTD-LX TIME BASE START OF DTB D6011:16 D8004:15 TBSSG-HT TIME BASE END OF SINGLE SWEEP D8004:15 D7005:17 TBSMART TIME BASE TEST SIGNALS C7054:17 X9001:18 TBXDEFL-LD X DEFLECTION CONTROL SIGNAL D9012:14 V8015:15 R7772:...
Page 95: Unit Lay-Outs
UNIT DESCRIPTIONS 5.1 - 21 5.1.3 Unit lay-outs Lay-out 1 - Large component side of signal unit A1...
Page 96 5.1 - 22 UNIT DESCRIPTIONS Lay-out 2 - Small component side of signal unit A1...
Page 97 UNIT DESCRIPTIONS 5.1 - 23 Lay-out 1a - Large component side detail of signal unit A1 for PM3384B...
Page 98 5.1 - 24 UNIT DESCRIPTIONS Lay-out 1b - Large component side detail of signal unit A1 for PM3382B/92B Lay-out 1c - Large component side detail of signal unit A1 for PM3370B/80B/90B...
Page 99: Location List Signal Unit A1
UNIT DESCRIPTIONS 5.1 - 25 5.1.4 Location list Signal Unit A1 ’-L’ means that the component is located on the side with the large components. Otherwise the component is located on the side with small components (SMD’s: surface mounted devices) C1000 F15-L C1087 F12-L C2004 D14-L...
Page 100 5.1 - 26 UNIT DESCRIPTIONS C3066 D13 C4056 A12 C5507 D10 C6113 A2 C3067 D13 C4057 B12 C5508 C10 C6114 A1 C3068 B14 C4058 A12 C5509 C10 C6115 A1 C3069 B14 C4059 B12 C5510 C10 C6116 A1 C3071 B15 C4060 A12 C5511 C10 C6117 A1 C3072 C14...
Page 101 UNIT DESCRIPTIONS 5.1 - 27 C7006 F2 C8003 D3 D3201 C11 L1001 F15 C7007 F2 C8004 D3 D3301 C8 L1301 F8 C7008 F2 C8005 E3 D4201 B11 L2001 D15 C7009 G2 C8006 E3 D4301 B8 L2301 D8 C7010 F3 C8007 D4 D5001 D5 L3001 C15 C7011 F2-L...
Page 102 5.1 - 28 UNIT DESCRIPTIONS R1016 F14-L R1095 G11 R1253 G9 R2003 D15 R1019 F15 R1096 G11 R1254 G9 R2006 D15-L R1021 F15-L R1097 H10 R1256 G9 R2007 D15-L R1022 F14 R1101 G10 R1257 F9 R2008 E14-L R1023 F15-L R1102 G10 R1258 G10 R2009 E14-L R1024 F14...
Page 103 UNIT DESCRIPTIONS 5.1 - 29 R2079 D12 R2311 D8 R3073 C12 R3304 C8 R2081 E12 R2313 D7 R3074 C12 R3307 B8 R2082 D12 R2314 D7 R3076 C12 R3308 D10 R2083 E12 R3001 C15 R3077 C12 R3309 D10 R2084 D12 R3002 C15 R3078 C12 R3310 C7 R2086 D12...
Page 104 5.1 - 30 UNIT DESCRIPTIONS R4064 B12 R4231 B10 R5058 D6 R5561 C10 R4065 A12 R4301 B9 R5060 D5 R5562 D9 R4071 B12 R4302 B9 R5061 D6 R5601 D9 R4072 B12 R4303 B8 R5064 E6 R5602 C9 R4073 A12 R4304 B8 R5065 E7 R5603 C9 R4074 A12...
Page 105 UNIT DESCRIPTIONS 5.1 - 31 R6053 C1 R6627 B5 R7014 H1-L R7154 G7 R6054 C2 R6629 B4 R7015 G1 R7155 G6 R6061 C2 R6632 A4 R7016 G1 R7156 G6 R6062 D2 R6633 B5 R7017 F2 R7160 G7 R6063 D1 R6634 B4 R7018 G3 R7161 G7 R6070 B3...
Page 106 5.1 - 32 UNIT DESCRIPTIONS R7713 E5 R8042 C3 R8098 E4 V2003 E12 R7716 D5 R8043 C3 R8099 E4 V2004 E13 R7753 G6 R8044 D4 R8100 F4 V2005 E13 R7754 G6 R8045 D4 R8101 D3 V2006 E13 R7809 G4 R8046 D4 R8102 E1 V2007 D12 R7901 G7...
Page 107 UNIT DESCRIPTIONS 5.1 - 33 V4006 B13 V6006 B2 V7012 G2 V8019 B4 V4007 A12 V6007 B2 V7016 G2 V8023 D4 V4008 B12 V6008 C3 V7017 G2 V8024 D4 V4009 B12 V6012 C2 V7018 F2 V8025 D4 V4012 B12 V6013 C2-L V7019 H2-L V8028 D4 V4013 B12...
Page 108 5.1 - 34 UNIT DESCRIPTIONS...
Page 109: Circuit Diagrams
UNIT DESCRIPTIONS 5.1 - 35 5.1.5 Circuit diagrams A1; Diagram 1 - Attenuator CH1 (PM3394B/90B)
Page 110 5.1 - 36 UNIT DESCRIPTIONS A1; Diagram 1a - Attenuator CH1 (PM3384B/80B/70B)
Page 111 UNIT DESCRIPTIONS 5.1 - 37 A1; Diagram 2 - Attenuator CH2 (PM3394B/90B)
Page 112 5.1 - 38 UNIT DESCRIPTIONS Diagram 3 - Attenuator CH3 (PM3394B)
Page 113 UNIT DESCRIPTIONS 5.1 - 39 Diagram 3a - Attenuator CH3 (PM3380B/70B)
Page 114 5.1 - 40 UNIT DESCRIPTIONS Diagram 4 - Attenuator CH4 (PM3394B)
Page 115 UNIT DESCRIPTIONS 5.1 - 41 Diagram 4a - Attenuator CH4 (PM3380B/70B)
Page 116 5.1 - 42 UNIT DESCRIPTIONS Diagram 5 - Attenuator control + CAL generator...
Page 117 UNIT DESCRIPTIONS 5.1 - 43 Diagram 6 - Preamplifier CH1 and CH2...
Page 118 5.1 - 44 UNIT DESCRIPTIONS Diagram 7 - Preamplifier CH3 and CH4...
Page 119 UNIT DESCRIPTIONS 5.1 - 45 Diagram 8 - Y-functions...
Page 120 5.1 - 46 UNIT DESCRIPTIONS Diagram 9 - Delay line driver (PM3394B/90B)
Page 121 UNIT DESCRIPTIONS 5.1 - 47 Diagram 9a - Delay line driver (PM3384B/80B)
Page 122 5.1 - 48 UNIT DESCRIPTIONS Diagram 9b - Delay line driver (Pm3370A)
Page 123 UNIT DESCRIPTIONS 5.1 - 49 Diagram 10 - Display and trigger control...
Page 124 5.1 - 50 UNIT DESCRIPTIONS Diagram 11 - Control circuits...
Page 125 UNIT DESCRIPTIONS 5.1 - 51 Diagram 12 - MTB trigger...
Page 126 5.1 - 52 UNIT DESCRIPTIONS Diagram 13 - TV/line trigger...
Page 127 UNIT DESCRIPTIONS 5.1 - 53 Diagram 14 - DTB trigger...
Page 128 5.1 - 54 UNIT DESCRIPTIONS Diagram 15 - Time base logic...
Page 129 UNIT DESCRIPTIONS 5.1 - 55 Diagram 16 - Main time base...
Page 130 5.1 - 56 UNIT DESCRIPTIONS Diagram 17 - Delayed time base...
Page 131 UNIT DESCRIPTIONS 5.1 - 57 Diagram 18 - Connectors...
Page 132 5.1 - 58 UNIT DESCRIPTIONS...
Page 133: Parts List
UNIT DESCRIPTIONS 5.1 - 59 Item Description Ordering code 5.1.6 Parts list MECHANICAL 0002 SPECIAL NUT FOR BNC 5322 506 41006 0003 RING BNC SPACER 5322 532 21188 0004 HOLDER BNC HOLDER 5322 256 91792 0005 PLATE SCREENING PARTITION 5322 466 83049 0006 CALIBRATION PIN 5322 535 93244...
Page 134 5.1 - 60 UNIT DESCRIPTIONS Item Description Ordering code C1056 CAP.CERAMIC AP 63V 5% 10PF 5322 122 32448 C1057 CAP.CHIP AP 63V 0.25PF 2.2PF 5322 122 33063 C1058 CAP.CHIP AP 63V 0.25PF 2.2PF 5322 122 33063 C1059 CAP.CHIP AP 63V 5% 100PF 5322 122 32531 C1060 CAP.CHIP...
Page 135 UNIT DESCRIPTIONS 5.1 - 61 Item Description Ordering code C1611 CAP.CHIP AP 63V 10% 100NF 4822 122 33496 C1651 CAP.ELECTROLYT. 25V 20% 47UF 5322 121 10472 C1652 CAP.CHIP AP 63V 10% 100NF 4822 122 33496 C1653 CAP.ELECTROLYT. 25V 20% 47UF 5322 121 10472 C1654 CAP.CHIP...
Page 136 5.1 - 62 UNIT DESCRIPTIONS Item Description Ordering code C2054 CAP.CHIP AP 63V 10% 10NF 5322 122 34098 C2055 CAP.CHIP AP 63V 0.25PF 2.7PF 5322 122 31873 C2056 CAP.CERAMIC AP 63V 5% 10PF 5322 122 32448 C2057 CAP.CHIP AP 63V 0.25PF 2.2PF 5322 122 33063 C2058 CAP.CHIP...
Page 137 UNIT DESCRIPTIONS 5.1 - 63 Item Description Ordering code C3014 CAP.CHIP AP 63V 0.5PF 5.6PF 5322 122 32967 C3018 CAP.CHIP AP 63V 10% 10NF 5322 122 34098 C3019 CAP.CHIP AP 63V 10% 10NF 5322 122 34098 C3020 CAP.CERAMIC 500V 0.25PF 2.2PF 5322 122 32774 C3021 CAP.CERAMIC...
Page 138 5.1 - 64 UNIT DESCRIPTIONS Item Description Ordering code C3209 CAP.CHIP AP 63V 10% 10NF 5322 122 34098 C3210 CAP.CERAMIC AP 63V 5% 47PF 5322 122 32452 C3211 CAP.CHIP AP 63V 10% 100NF 4822 122 33496 C3301 CAP.CERAMIC AP 63V 5% 47PF 5322 122 32452 C3302 CAP.CHIP...
Page 139 UNIT DESCRIPTIONS 5.1 - 65 Item Description Ordering code C4066 CAP.CHIP AP 63V 10% 10NF 5322 122 34098 C4067 CAP.CHIP AP 63V 10% 10NF 5322 122 34098 C4068 CAP.CHIP AP 63V 10% 10NF 5322 122 34098 C4069 CAP.CHIP AP 63V 10% 10NF 5322 122 34098 C4071 CAP.CHIP...
Page 140 5.1 - 66 UNIT DESCRIPTIONS Item Description Ordering code C5502 CAP.CHIP AP 63V 5% 100PF 5322 122 32531 C5503 CAP.CHIP AP 63V 10% 10NF 5322 122 34098 C5504 CAP.CHIP AP 63V 5% 22PF 5322 122 32658 C5505 CAP.CHIP AP 63V 5% 820PF 5322 126 10184 C5506 CAP.CHIP...
Page 141 UNIT DESCRIPTIONS 5.1 - 67 Item Description Ordering code C6098 CAP.CHIP AP 63V 10% 220NF 4822 122 32916 C6101 CAP.CHIP AP 63V 10% 100NF 4822 122 33496 C6102 CAP.CHIP AP 63V 10% 100NF 4822 122 33496 C6103 CAP.CHIP AP 63V 10% 100NF 4822 122 33496 C6104 CAP.CHIP...
Page 142 5.1 - 68 UNIT DESCRIPTIONS Item Description Ordering code C6902 CAP.ELECTROLYT. 25V 20% 47UF 5322 121 10472 C6903 CAP.CHIP AP 63V 10% 10NF 5322 122 34098 C6904 CAP.CHIP AP 63V 10% 10NF 5322 122 34098 C6912 CAP.ELECTROLYT. 25V 20% 47UF 5322 121 10472 C6913 CAP.CHIP...
Page 143 UNIT DESCRIPTIONS 5.1 - 69 Item Description Ordering code C7513 CAP.CHIP AP 63V 10% 10NF 5322 122 34098 C7549 CAP.CHIP AP 63V 10% 22NF 5322 122 32654 C7551 CAP.CHIP AP 63V 10% 22NF 5322 122 32654 C7557 CAP.CHIP AP 63V 10% 10NF 5322 122 34098 C7559 CAP.CHIP...
Page 144 5.1 - 70 UNIT DESCRIPTIONS Item Description Ordering code C8035 CAP.CHIP AP 63V 10% 22NF 5322 122 32654 C8036 CAP.CHIP AP 63V 10% 100NF 4822 122 33496 C8060 CAP.CERAMIC AP 63V 0.25PF 0.56PF 5322 122 33083 C8062 CAP.CHIP AP 63V 5% 100PF 5322 122 32531 C8063 CAP.CHIP...
Page 145 UNIT DESCRIPTIONS 5.1 - 71 Item Description Ordering code D5502 INTEGR.CIRCUIT CD4053BCM 5322 209 33502 D5503 INTEGR.CIRCUIT HEF4081BT PEL 5322 209 14483 D6001 INTEGR.CIRCUIT HEF4051BT PEL 5322 209 11446 D6002 INTEGR.CIRCUIT CD4053BCM 5322 209 33502 D6011 INTEGR.CIRCUIT OQ0228 SAWCHIP 5322 209 12466 D6541 INTEGR.CIRCUIT OQ0226 TRIGGER AMPL.
Page 146 5.1 - 72 UNIT DESCRIPTIONS Item Description Ordering code K4001 RELAY DPDT RELAIS RAL3W-K 5322 280 80745 K4002 RELAY DPDT RELAIS RAL3W-K 5322 280 80745 K4003 RELAY DPDT RELAIS RAL3W-K 5322 280 80745 K4004 RELAY DPDT RELAIS RAL3W-K 5322 280 80745 K4006 RELAY DPDT RELAIS RAL3W-K...
Page 147 UNIT DESCRIPTIONS 5.1 - 73 Item Description Ordering code N9002 INTEGR.CIRCUIT TDA8444AT/N4 PEL 5322 209 30233 N9003 INTEGR.CIRCUIT TDA8444AT/N4 PEL 5322 209 30233 N9004 INTEGR.CIRCUIT TDA8444AT/N4 PEL 5322 209 30233 RESISTORS R1001 RES.CHIP RMC1/8 1% 61E9 5322 111 92016 R1002 RES.CHIP HIP RC-02H 1% 1M 4822 051 10105...
Page 148 5.1 - 74 UNIT DESCRIPTIONS Item Description Ordering code R1052 RES.CHIP HIP RC-02H 1% 100E 4822 051 10101 R1053 RES.METAL FILM HIP RC-02H 1% 6K19 5322 117 10577 R1054 RES.CHIP HIP RC-02H 1% 10K 4822 051 10103 R1056 RES.METAL FILM HIP RC-02H 1% 619E 5322 117 10576 R1057...
Page 149 UNIT DESCRIPTIONS 5.1 - 75 Item Description Ordering code R1157 RES.METAL FILM PR24 1/4W 0.1% 9K4 5322 116 83712 R1158 RES.METAL FILM PR24 1/4W 0.1% 750E 5322 116 53173 R1159 RES.METAL FILM HIP RC-02H 1% 3K16 5322 117 10553 R1192 RES.METAL FILM PR24 1/4W 0.1% 1K25 5322 116 53177...
Page 150 5.1 - 76 UNIT DESCRIPTIONS Item Description Ordering code R1266 RES.CHIP HIP RC-01 5% 1E 4822 051 10108 R1301 RES.CHIP RMC1/8 1% 61E9 5322 111 92016 R1302 RES.CHIP RMC1/8 1% 61E9 5322 111 92016 R1303 RES.METAL FILM HIP RC-02H 1% 6K81 5322 117 10581 R1304 RES.CHIP...
Page 151 UNIT DESCRIPTIONS 5.1 - 77 Item Description Ordering code R2007 RES.METAL FILM ST MRS25 1% 100E 4822 050 21001 R2008 RES.METAL FILM PR24 1/4W 0.1% 9K4 5322 116 83712 R2009 RES.METAL FILM PR24 1/4W 0.1% 300E 5322 116 51814 R2010 RES.CHIP RMC1/8 1% 21E5 5322 111 92014...
Page 152 5.1 - 78 UNIT DESCRIPTIONS Item Description Ordering code R2065 RES.CHIP HIP RC-02H 1% 261E 4822 051 52611 R2071 RES.CHIP RMC1/8 1% 61E9 5322 111 92016 R2072 RES.METAL FILM HIP RC-02H 1% 147E 5322 117 10526 R2073 RES.CHIP HIP RC-02H 1% 100E 4822 051 10101 R2074 RES.CHIP...
Page 153 UNIT DESCRIPTIONS 5.1 - 79 Item Description Ordering code R2218 RES.CHIP RMC1/8 1% 51E1 5322 111 91893 R2220 RES.METAL FILM HIP RC-02H 1% 75K 5322 117 10584 R2222 RES.METAL FILM HIP RC-02H 1% 162E 5322 117 10529 R2223 RES.METAL FILM HIP RC-02H 1% 237E 5322 117 10544 R2224...
Page 154 5.1 - 80 UNIT DESCRIPTIONS Item Description Ordering code R3034 RES.CHIP HIP RC-01 5% 10M 4822 051 10106 R3035 RES.METAL FILM HIP RC-02H 1% 215K 5322 117 10543 R3036 RES.CHIP HIP RC-02H 1% 5K11 5322 117 10487 R3037 RES.METAL FILM HIP RC-02H 1% 3K83 5322 117 10561 R3038...
Page 155 UNIT DESCRIPTIONS 5.1 - 81 Item Description Ordering code R3103 RES.METAL FILM HIP RC-02H 1% 14K7 5322 117 10528 R3104 RES.CHIP HIP RC-02H 1% 10K 4822 051 10103 R3106 RES.CHIP HIP RC-02H 1% 10K 4822 051 10103 R3112 RES.METAL FILM HIP RC-02H 1% 61K9 5322 117 10578 R3113...
Page 156 5.1 - 82 UNIT DESCRIPTIONS Item Description Ordering code R4006 RES.METAL FILM ST MRS25 1% 100E 4822 050 21001 R4007 RES.METAL FILM ST MRS25 1% 100E 4822 050 21001 R4008 RES.METAL FILM PR24 1/4W 0.1% 9K4 5322 116 83712 R4009 RES.METAL FILM PR24 1/4W 0.1% 300E 5322 116 51814...
Page 157 UNIT DESCRIPTIONS 5.1 - 83 Item Description Ordering code R4064 RES.CHIP HIP RC-02H 1% 261E 4822 051 52611 R4065 RES.CHIP HIP RC-02H 1% 261E 4822 051 52611 R4071 RES.CHIP RMC1/8 1% 61E9 5322 111 92016 R4072 RES.METAL FILM HIP RC-02H 1% 147E 5322 117 10526 R4073 RES.CHIP...
Page 158 5.1 - 84 UNIT DESCRIPTIONS Item Description Ordering code R4217 RES.CHIP HIP RC-02H 1% 100E 4822 051 10101 R4218 RES.CHIP RMC1/8 1% 51E1 5322 111 91893 R4220 RES.METAL FILM HIP RC-02H 1% 75K 5322 117 10584 R4222 RES.METAL FILM HIP RC-02H 1% 162E 5322 117 10529 R4223 RES.METAL FILM...
Page 159 UNIT DESCRIPTIONS 5.1 - 85 Item Description Ordering code R5036 RES.METAL FILM HIP RC-02H 1% 178E 5322 117 10534 R5037 RES.METAL FILM HIP RC-02H 1% 178E 5322 117 10534 R5041 RES.METAL FILM HIP RC-02H 1% 21K5 5322 117 10542 R5042 RES.METAL FILM HIP RC-02H 1% 21K5 5322 117 10542...
Page 160 5.1 - 86 UNIT DESCRIPTIONS Item Description Ordering code R5514 RES.CHIP HIP RC-02H 1% 1K 4822 051 10102 R5516 RES.METAL FILM HIP RC-02H 1% 3K48 5322 117 10557 R5517 RES.METAL FILM HIP RC-02H 1% 1K21 5322 117 10521 R5518 RES.CHIP HIP RC-02H 1% 10K 4822 051 10103 R5519...
Page 161 UNIT DESCRIPTIONS 5.1 - 87 Item Description Ordering code R6011 RES.CHIP HIP RC-02H 1% 100E 4822 051 10101 R6012 RES.CHIP HIP RC-02H 1% 100K 4822 051 10104 R6013 RES.METAL FILM PR24 1/4W 0.1% 23K7 5322 116 53169 R6014 RES.METAL FILM PR24 1/4W 0.1% 2K37 5322 116 53171 R6015...
Page 162 5.1 - 88 UNIT DESCRIPTIONS Item Description Ordering code R6071 RES.METAL FILM HIP RC-02H 1% 19K6 5322 117 10541 R6072 RES.CHIP RMC1/8 1% 10E 4822 111 91885 R6073 RES.CHIP HIP RC-02H 1% 1K 4822 051 10102 R6074 RES.METAL FILM HIP RC-02H 1% 1K21 5322 117 10521 R6093 RES.CHIP...
Page 163 UNIT DESCRIPTIONS 5.1 - 89 Item Description Ordering code R6614 RES.METAL FILM HIP RC-02H 1% 511E 5322 117 10569 R6616 RES.METAL FILM HIP RC-02H 1% 511E 5322 117 10569 R6621 RES.CHIP HIP RC-02H 1% 5K11 5322 117 10487 R6622 RES.METAL FILM HIP RC-02H 1% 5K62 5322 117 10573 R6623...
Page 164 5.1 - 90 UNIT DESCRIPTIONS Item Description Ordering code R6941 RES.CHIP HIP RC-01 5% 4E7 4822 051 10478 R6951 RES.CHIP HIP RC-01 5% 4E7 4822 051 10478 R6961 RES.CHIP HIP RC-01 5% 4E7 4822 051 10478 R7001 RES.CHIP HIP RC-02H 1% 100E 4822 051 10101 R7002 RES.METAL FILM...
Page 165 UNIT DESCRIPTIONS 5.1 - 91 Item Description Ordering code R7054 RES.METAL FILM HIP RC-02H 1% 9K09 5322 117 10589 R7056 RES.METAL FILM HIP RC-02H 1% 19K6 5322 117 10541 R7057 RES.METAL FILM HIP RC-02H 1% 38K3 5322 117 10562 R7059 RES.METAL FILM HIP RC-02H 1% 75K 5322 117 10584...
Page 166 5.1 - 92 UNIT DESCRIPTIONS Item Description Ordering code R7526 RES.CHIP RMC1/8 1% 51E1 5322 111 91893 R7527 RES.CHIP RMC1/8 1% 51E1 5322 111 91893 R7528 RES.CHIP RMC1/8 1% 51E1 5322 111 91893 R7529 RES.CHIP RMC1/8 1% 51E1 5322 111 91893 R7531 RES.METAL FILM HIP RC-02H 1% 422E...
Page 167 UNIT DESCRIPTIONS 5.1 - 93 Item Description Ordering code R7956 RES.METAL FILM HIP RC-02H 1% 14K7 5322 117 10528 R7957 RES.CHIP HIP RC-02H 1% 10K 4822 051 10103 R7958 RES.CHIP HIP RC-02H 1% 10K 4822 051 10103 R7961 RES.CHIP HIP RC-01 5% 4E7 4822 051 10478 R8001 RES.METAL FILM...
Page 168 5.1 - 94 UNIT DESCRIPTIONS Item Description Ordering code R8045 RES.CHIP RMC1/8 1% 51E1 5322 111 91893 R8046 RES.METAL FILM HIP RC-02H 1% 1K47 5322 117 10527 R8047 RES.CHIP RMC1/8 1% 21E5 5322 111 92014 R8048 RES.METAL FILM HIP RC-02H 1% 3K48 5322 117 10557 R8049 RES.CHIP...
Page 169 UNIT DESCRIPTIONS 5.1 - 95 Item Description Ordering code R8092 RES.METAL FILM HIP RC-02H 1% 2K61 5322 117 10547 R8093 RES.METAL FILM HIP RC-02H 1% 2K61 5322 117 10547 R8094 RES.METAL FILM HIP RC-02H 1% 2K61 5322 117 10547 R8095 RES.CHIP RMC1/8 1% 21E5 5322 111 92014...
Page 170 5.1 - 96 UNIT DESCRIPTIONS Item Description Ordering code V1201 TRANSISTOR,CHIP BF579 TEL 5322 130 63453 V1202 TRANSISTOR,CHIP BF579 TEL 5322 130 63453 V1206 TRANSISTOR,CHIP BC858C PEL 4822 130 42513 V1207 TRANSISTOR,CHIP BC858C PEL 4822 130 42513 V1208 TRANSISTOR,CHIP BC858C PEL 4822 130 42513 V1209 TRANSISTOR,CHIP...
Page 171 UNIT DESCRIPTIONS 5.1 - 97 Item Description Ordering code V3006 TRANSISTOR,CHIP BF990A PEL 4822 130 62657 V3007 TRANSISTOR,CHIP BFS20 PEL 5322 130 42718 V3008 TRANSISTOR,CHIP BF579 TEL 5322 130 63453 V3009 TRANSISTOR,CHIP BFR53 PEL 5322 130 61244 V3012 TRANSISTOR,CHIP BSS83 PEL 5322 130 60502 V3013 TRANSISTOR,CHIP...
Page 172 5.1 - 98 UNIT DESCRIPTIONS Item Description Ordering code V4306 DIODE,REFERENCE BZX84-C2V4 PEL 4822 130 33703 V4307 DIODE,REFERENCE BZX84-C3V0 PEL 5322 130 32739 V5001 TRANSISTOR,CHIP BFS20 PEL 5322 130 42718 V5002 TRANSISTOR,CHIP BFS20 PEL 5322 130 42718 V5003 TRANSISTOR,CHIP BFR92 PEL 5322 130 42145 V5004 TRANSISTOR,CHIP...
Page 173 UNIT DESCRIPTIONS 5.1 - 99 Item Description Ordering code V6532 TRANSISTOR,CHIP BC858C PEL 4822 130 42513 V6553 TRANSISTOR,CHIP BC858C PEL 4822 130 42513 V6573 TRANSISTOR,CHIP BF824 PEL 4822 130 60383 V6574 TRANSISTOR,CHIP BF824 PEL 4822 130 60383 V6593 DIODE,CHIP BAS28 PEL 5322 130 80214 V6604 TRANSISTOR,CHIP...
Page 174 5.1 - 100 UNIT DESCRIPTIONS Item Description Ordering code V7573 TRANSISTOR,CHIP BF824 PEL 4822 130 60383 V7574 TRANSISTOR,CHIP BF824 PEL 4822 130 60383 V7686 TRANSISTOR,CHIP BC848C PEL 5322 130 42136 V7687 TRANSISTOR,CHIP BC848C PEL 5322 130 42136 V7691 TRANSISTOR,CHIP BC848C PEL 5322 130 42136 V7714 TRANSISTOR,CHIP...
Page 175 UNIT DESCRIPTIONS 5.1 - 101 Item Description Ordering code V8067 TRANSISTOR,CHIP BC858C PEL 4822 130 42513 V8068 TRANSISTOR,CHIP BC848C PEL 5322 130 42136 V8101 DIODE,CHIP BAS28 PEL 5322 130 80214 CONNECTORS X1301 SOCKET,MALE 50 OHM BUS 5322 265 10266 X1301 HOLD,OBJECTIVE CONTACTPIN 5322 268 14141...
Page 176 5.1 - 102 UNIT DESCRIPTIONS Item Description Ordering code...
Page 177: Final Xyz Amplifier A2
UNIT DESCRIPTIONS 5.2 - 1 FINAL XYZ AMPLIFIER A2 5.2.1 Description of A2-200 MHz version 5.2.1.1 Final Y amplifier Diagram 1 The output signal from the delay line is applied to the input pins 6 and 9 of amplifier IC D1001. Also the vertical output signals YTXT0 and YTXT1 from the digitizer unit A8 are applied to D1001 (pin 15 and 16).
Page 178 5.2 - 2 UNIT DESCRIPTIONS The other plate is driven by push-pull stage V1107/V1112. The driver transistors are V1101 and V1104. The input signal is YPREOUT0. The output voltage applied to the CRT deflection plates is controlled by the feedback networks R1101/R1141/R1143/C1101/V1113/R1140/C1121 and R1102/R1142/R1144/C1102/V1113/R1145/C1122.
Page 179 UNIT DESCRIPTIONS 5.2 - 3 The final X amplifier half that drives the left deflection plate is explained now. Its function is identical to that of the other amplifier half. The balanced input signals XDRIL1 and XDRIL0 are applied to input stage V2101.
Page 180 5.2 - 4 UNIT DESCRIPTIONS The intensity is influenced by the output signal INTEN-AA of the Z- amplifier and the signal INTEN- DA. INTEN-AA is determined via the front-panel INTENS TRACE, INTENS TEXT, MTBI and chopper blanking control signals. The HF component in the INTEN-AA signal is applied to G1 of the CRT via C4037.
Page 181: Signal Name List A2-200 Mhz Version
UNIT DESCRIPTIONS 5.2 - 5 5.2.2 Signal name list A2-200 MHz version Note: In the signal name list you find the itemnumber of the component that is source or destination. Behind this itemnumber (separated by ":") you find the number of the diagram where the source/destination can be found.
Page 182 5.2 - 6 UNIT DESCRIPTIONS XSCL SERIAL CLOCK X SECTION J2002:06 N2002:03 XSDA SERIAL DATA X SECTION J2001:06 N2002:03 XSW0 X SWITCH SIGNAL 0 TRACE/TEXT V1204:01 D2001:03 XSW1 X SWITCH SIGNAL 1 TRACE/TEXT V1203:01 D2001:03 XYSW0 X/Y SWITCH SIGNAL 0 TRACE/TEXT X2501:06 R1204:01 XYSW1...
Page 183: Unit Lay-Outs A2-200 Mhz Version
UNIT DESCRIPTIONS 5.2 - 7 5.2.3 Unit lay-outs A2-200 MHz version Lay-out 1 - Large component side of XYZ amplifier unit A2-200 MHz...
Page 184 5.2 - 8 UNIT DESCRIPTIONS Lay-out 2 - Small component side of XYZ amplifier unit A2-200 MHZ...
Page 185: Location List A2-200 Mhz Version
UNIT DESCRIPTIONS 5.2 - 9 5.2.4 Location list A2-200 MHz version ’-L’ means that the component is located on the side with the large components. Otherwise the component is located on the side with small components. C1001 C11 C2013 B7 C3013 B6 C5007 D10-L C1002 C11...
Page 186 5.2 - 10 UNIT DESCRIPTIONS N1002 C11 R1066 B10 R1150 B9 R2011 A7 N1003 A9 R1071 B11 R1151 C10 R2012 A7 N1004 D9 R1072 C10 R1152 C9 R2013 A7 N2002 A6 R1073 C10 R1153 D9 R2014 A7 N2003 D8 R1074 C10 R1154 D9 R2015 B7 N5131 A11...
Page 187 UNIT DESCRIPTIONS 5.2 - 11 R2238 C7 R3112 C5 R4009 D2 R5416 D9 R2251 D7 R3113 C5 R4031 D2 V1009 B11 R2261 C7 R3131 C4 R4032 D2 V1011 B11 R2271 B7-L R3132 C4 R4033 D2 V1014 A10 R2272 B7 R3133 C5 R4034 D2 V1016 A10 R2276 B7...
Page 188 5.2 - 12 UNIT DESCRIPTIONS V2233 C7 V3132 C4 V3236 D5 V4037 D2 V2234 C7-L V3133 C4 V3237 D5 V4038 D3 V2301 D7 V3134 C5-L V3281 D6 V4039 D3 V2403 D7 V3136 D5 V3282 D6 V4040 D3 V2418 D7 V3137 D5 V3301 D4 V4041 D3 V3001 A4...
Page 189: Circuit Diagrams A2-200 Mhz Version
UNIT DESCRIPTIONS 5.2 - 13 5.2.5 Circuit diagrams A2-200 MHz version A2 (200 MHz) - Diagram 1 ; Final Y preamplifier and control...
Page 190 5.2 - 14 UNIT DESCRIPTIONS A2 (200 MHz) - Diagram 2 ; Final Y output stage...
Page 191 UNIT DESCRIPTIONS 5.2 - 15 A2 (200 MHz) - Diagram 3 ; Final X amplifier and control...
Page 192 5.2 - 16 UNIT DESCRIPTIONS A2 (200 MHz) - Diagram 4 ; Final Z amplifier...
Page 193 UNIT DESCRIPTIONS 5.2 - 17 A2 (200 MHz) - Diagram 5 ; Modulator/demodulator and focus control...
Page 194 5.2 - 18 UNIT DESCRIPTIONS A2 (200 MHz) - Diagram 6 ; Supply circuits...
Page 195: Parts List A2-200 Mhz Version
UNIT DESCRIPTIONS 5.2 - 19 Item Description Ordering code 5.2.6 Parts list A2-200 MHz version MECHANICAL 0001 CABLE,CONNECT. ASSY CABLE CRT 5322 321 62202 0003 CABLE,CONNECT. ASSY CABLE CRT 5322 321 62198 0004 CABLE,CONNECT. ASSY CABLE CRT 5322 321 62199 CAPACITORS C1001 CAP.CHIP...
Page 196 5.2 - 20 UNIT DESCRIPTIONS Item Description Ordering code C1302 CAP.CHIP AP 63V 5% 220PF 4822 122 33575 C2001 CAP.CHIP AP 63V 10% 10NF 5322 122 34098 C2002 CAP.CHIP AP 63V 10% 220NF 4822 122 32916 C2003 CAP.CHIP AP 63V 10% 10NF 5322 122 34098 C2004 CAP.CERAMIC...
Page 197 UNIT DESCRIPTIONS 5.2 - 21 Item Description Ordering code C2402 CAP.CHIP AP 63V 10% 10NF 5322 122 34098 C2403 CAP.CHIP AP 63V 10% 10NF 5322 122 34098 C2404 CAP.CHIP AP 63V 10% 10NF 5322 122 34098 C2406 CAP.CHIP AP 63V 10% 10NF 5322 122 34098 C2407 CAP.CHIP...
Page 198 5.2 - 22 UNIT DESCRIPTIONS Item Description Ordering code C3407 CAP.CHIP AP 63V 10% 10NF 5322 122 34098 C3418 CAP.CHIP AP 63V 10% 100NF 4822 122 33496 C4001 CAP.CHIP AP 63V 10% 10NF 5322 122 34098 C4002 CAP.CERAMIC AP 63V 5% 10PF 5322 122 32448 C4003 CAP.CHIP...
Page 199 UNIT DESCRIPTIONS 5.2 - 23 Item Description Ordering code C5321 CAP.CHIP AP 63V 10% 10NF 5322 122 34098 C5322 CAP.CHIP AP 63V 10% 10NF 5322 122 34098 C5326 CAP.CHIP AP 63V 10% 10NF 5322 122 34098 C5331 CAP.ELECTROLYT. 100V 20% 27UF 5322 124 42193 C5332 CAP.CHIP...
Page 200 5.2 - 24 UNIT DESCRIPTIONS Item Description Ordering code R1014 RES.CHIP HIP RC-02H 1% 261E 4822 051 52611 R1015 RES.CHIP HIP RC-02H 1% 4K64 4822 051 54642 R1016 RES.CHIP RMC1/8 1% 31E6 5322 117 11732 R1017 RES.CHIP HIP RC-02H 1% 1K1 4822 051 51102 R1018 RES.MET.GLAZED...
Page 201 UNIT DESCRIPTIONS 5.2 - 25 Item Description Ordering code R1082 RES.CHIP HIP RC-02H 1% 10K 4822 051 10103 R1083 RES.CHIP HIP RC-02H 1% 10K 4822 051 10103 R1084 RES.METAL FILM HIP RC-02H 1% 147E 5322 117 10526 R1086 RES.METAL FILM HIP RC-02H 1% 147E 5322 117 10526 R1101...
Page 202 5.2 - 26 UNIT DESCRIPTIONS Item Description Ordering code R1152 RES.CHIP RMC1/8 1% 28E7 5322 111 92015 R1153 RES.CHIP RMC1/8 1% 28E7 5322 111 92015 R1154 RES.CHIP HIP RC-01 5% 4E7 4822 051 10478 R1155 RES.METAL FILM HIP RC-02H 1% 511E 5322 117 10569 R1156 RES.METAL FILM...
Page 203 UNIT DESCRIPTIONS 5.2 - 27 Item Description Ordering code R2002 RES.METAL FILM HIP RC-02H 1% 12K1 5322 117 10522 R2003 RES.CHIP HIP RC-02H 1% 1K 4822 051 10102 R2004 RES.CHIP RMC1/8 1% 51E1 5322 111 91893 R2006 RES.CHIP RMC1/8 1% 51E1 5322 111 91893 R2007 RES.METAL FILM...
Page 204 5.2 - 28 UNIT DESCRIPTIONS Item Description Ordering code R2177 RES.METAL FILM HIP RC-02H 1% 215K 5322 117 10543 R2201 RES.CHIP RMC1/8 1% 51E1 5322 111 91893 R2202 RES.CHIP RMC1/8 1% 21E5 5322 111 92014 R2203 RES.CHIP RMC1/8 1% 51E1 5322 111 91893 R2204 RES.METAL FILM...
Page 205 UNIT DESCRIPTIONS 5.2 - 29 Item Description Ordering code R3006 RES.CHIP HIP RC-02H 1% 100E 4822 051 10101 R3007 RES.CHIP HIP RC-02H 1% 100E 4822 051 10101 R3008 RES.CHIP HIP RC-02H 1% 100E 4822 051 10101 R3009 RES.CHIP HIP RC-02H 1% 1K 4822 051 10102 R3011 RES.CHIP...
Page 206 5.2 - 30 UNIT DESCRIPTIONS Item Description Ordering code R3232 RES.CHIP HIP RC-02H 1% 5K11 5322 117 10487 R3233 RES.METAL FILM HIP RC-02H 1% 14K7 5322 117 10528 R3234 RES.METAL FILM HIP RC-02H 1% 14K7 5322 117 10528 R3236 RES.METAL FILM HIP RC-02H 1% 1K78 5322 117 10535 R3237...
Page 207 UNIT DESCRIPTIONS 5.2 - 31 Item Description Ordering code R4044 RES.CHIP HIP RC-02H 1% 1M 4822 051 10105 R4045 RES.METAL FILM HIP RC-02H 1% 215K 5322 117 10543 R4051 RES.HI-TENSION RST VR25 5% 3M3 4822 053 20335 R5001 RES.CHIP HIP RC-01 5% 1E 4822 051 10108 R5002 RES.CHIP...
Page 208 5.2 - 32 UNIT DESCRIPTIONS Item Description Ordering code SEMICONDUCTORS V1009 DIODE,CHIP BBY39 PEL 5322 130 82199 V1011 DIODE,CHIP BBY39 PEL 5322 130 82199 V1014 TRANSISTOR,CHIP BC858C PEL 4822 130 42513 V1016 TRANSISTOR,CHIP BC858C PEL 4822 130 42513 V1018 TRANSISTOR,CHIP BC858C PEL 4822 130 42513 V1019...
Page 209 UNIT DESCRIPTIONS 5.2 - 33 Item Description Ordering code V2201 TRANSISTOR,CHIP BF824 PEL 4822 130 60383 V2202 DIODE BZX84-B12 PEL 4822 130 83566 V2203 DIODE BZX84-B12 PEL 4822 130 83566 V2204 TRANSISTOR,CHIP BC858C PEL 4822 130 42513 V2205 DIODE BZX84-B12 PEL 4822 130 83566 V2211 TRANSISTOR,CHIP...
Page 210 5.2 - 34 UNIT DESCRIPTIONS Item Description Ordering code V3301 TRANSISTOR,CHIP BF820 PEL 5322 130 62802 V3311 TRANSISTOR,CHIP BC858C PEL 4822 130 42513 V3312 DIODE,CHIP BAV99 PEL 5322 130 34337 V3418 DIODE,REFERENCE BZX84-C8V2 PEL 5322 130 80255 V4001 DIODE,CHIP BAV99 PEL 5322 130 34337 V4002 TRANSISTOR,CHIP...
Page 211: Description Of A2-100 Mhz Version
UNIT DESCRIPTIONS 5.2 - 35 5.2.7 Description of A2-100 MHz version 5.2.7.1 Final Y amplifier Diagram 1 The output signal from the delay line is applied to the input pins 6 and 9 of amplifier IC D1001. This IC and surrounding components comprise the MF and HF square wave compensations. Also the vertical CRT text signal is applied to D1001 (pin 15 and 16).
Page 212 5.2 - 36 UNIT DESCRIPTIONS Diagram 2 This diagram shows the Y-output amplifier. The amplifier is located at the small printed circuit board at the CRT socket. The input signal is a current and is applied to V4101 and V4102. The output signal is voltage and is applied to the vertical deflection plates of the CRT.
Page 213 UNIT DESCRIPTIONS 5.2 - 37 Diagram 4 This diagram shows the final intensity (Z) and focusing amplifiers. These amplifiers drive the intensity electrode G1 and the focusing electrode G3 of the CRT. The input circuit is formed by IC D3001. Input pin 5 and 6 of D3001 receive the Z-pulses ZLTRA0 and ZLTRA1 that determine the intensity during signal display.
Page 214 5.2 - 38 UNIT DESCRIPTIONS The HF component from the focusing amplifier output signal FOCUS-AA is applied to G3 via C4004 and voltage divider R4008/R4009/C4002/C4003. This assures optimal tracking between focus and intensity. The signal FOCUS-DA is determined via the FOCUS control at the instruments front panel. The signal FOCUS-DA is then mixed with the LF component of FOCUS-AA before its level is adapted to the nominal G3 voltage via transistors V4002/V4003/V4004.
Page 215: Signal Name List A2-100 Mhz Version
UNIT DESCRIPTIONS 5.2 - 39 5.2.8 Signal name list A2-100 MHz version Note: In the signal name list you find the itemnumber of the component that is source or destination. Behind this itemnumber (separated by ":") you find the number of the diagram where the source/destination can be found NAME MEANING...
Page 216 5.2 - 40 UNIT DESCRIPTIONS NAME MEANING SOURCE DESTINATION XOUT1 X OUTPUT 1 V2234:03 R2271:03 V2213:03 R2301:03 XPLATE0 X OUTPUT 0 TO CRT LEFT PLATE R2161:03 X2411:02 XPLATE1 X OUTPUT 1 TO CRT RIGHT PLATE R2261:03 X2411:02 XPLATEC0 X OUTPUT 0 TO CRT LEFT PLATE R4261:02 X2403:02 XPLATEC1...
Page 217: Unit Lay-Outs A2-100 Mhz Version
UNIT DESCRIPTIONS 5.2 - 41 5.2.9 Unit lay-outs A2-100 MHz version Lay-out 1 - Large component side of XYZ amplifier unit A2-100 MHz...
Page 218 5.2 - 42 UNIT DESCRIPTIONS Lay-out 2 - Small component side of XYZ amplifier unit A2-100 MHZ...
Page 219: Location List A2-100 Mhz Version
UNIT DESCRIPTIONS 5.2 - 43 5.2.10 Location list A2-100 MHz version ’-L’ means that the component is located on the side with the large components. Otherwise the component is located on the side with small components. C1001 C11 C2132 C7 C3133 C5 C4163 D2 C1002 C11...
Page 220 5.2 - 44 UNIT DESCRIPTIONS D3001 B5-L R1048 A10 R2015 B7 R2277 B7 L4101 B2 R1049 A10 R2016 B8 R2301 C7 L4102 B2 R1051 B10 R2017 B8 R2302 C7 L4103 B2 R1052 A9 R2018 B7 R2303 C8 L5231 D7 R1053 A10 R2020 B7 R2304 C8 L5236 D6...
Page 221 UNIT DESCRIPTIONS 5.2 - 45 R3137 C5 R4040 D2 R4163 C2 R5411 D9 R3138 C5 R4041 D3 R4164 C1 R5416 D9 R3151 C5 R4042 C2 R4166 B1 R5501 C11 R3161 C5 R4043 C3 R4167 B1-L V1009 B11 R3171 B5-L R4044 C2 R4168 B1-L V1011 C11 R3176 B5...
Page 222 5.2 - 46 UNIT DESCRIPTIONS V3113 C5-L V3237 D5 V4029 C3 V4104 C1 V3131 C4 V3301 B8 V4031 D3 V4106 B1 V3132 B4 V3311 B8 V4032 D3 V4107 B1 V3133 C4 V3312 B8 V4033 D3 V4108 C1 V3134 C5-L V3413 C5 V4034 C2 V4109 C1 V3136 C5...
Page 223: Circuit Diagrams A2-100 Mhz Version
UNIT DESCRIPTIONS 5.2 - 47 5.2.11 Circuit diagrams A2-100 MHz version A2 (100 MHz) - Diagram 1a ; Final Y preamplifier and control...
Page 224 5.2 - 48 UNIT DESCRIPTIONS A2 (100 MHz) - Diagram 2a ; Final Y output stage...
Page 225 UNIT DESCRIPTIONS 5.2 - 49 A2 (100 MHz) - Diagram 3a ; Final X amplifier and control...
Page 226 5.2 - 50 UNIT DESCRIPTIONS A2 (100 MHz) - Diagram 4a ; Final Z amplifier...
Page 227 UNIT DESCRIPTIONS 5.2 - 51 A2 (100 MHz) - Diagram 5a ; Modulator/demodulator and focus control...
Page 228 5.2 - 52 UNIT DESCRIPTIONS A2 (100 MHz) - Diagram 6a ; Supply circuits...
Page 229: Parts List A2-100 Mhz Version
UNIT DESCRIPTIONS 5.2 - 53 Item Description Ordering code 5.2.12 Parts list A2-100 MHz version CAPACITORS C 1001 CAP.CHIP 63V 10% 10NF 5322 122 34098 C 1002 CAP.CHIP 63V 10% 10NF 5322 122 34098 C 1003 CAP.CHIP 63V 0.25PF 2.2PF 5322 122 33063 C 1005 CAP.CHIP...
Page 230 5.2 - 54 UNIT DESCRIPTIONS Item Description Ordering code C 2133 CAP.CHIP 63V 10% 100NF 4822 122 33496 C 2134 CAP.CHIP 63V 10% 22NF 5322 122 32654 C 2151 CAP.CHIP 63V 5% 1NF 5322 126 10511 C 2171 CAP.CHIP 63V 0.25PF 1PF 5322 122 32447 C 2172 CAP.CHIP...
Page 231 UNIT DESCRIPTIONS 5.2 - 55 Item Description Ordering code C 3103 CAP.CHIP 63V 10% 100NF 4822 122 33496 C 3131 CAP.CHIP 63V 10% 22NF 5322 122 32654 C 3132 CAP.CHIP 63V 10% 100NF 4822 122 33496 C 3133 CAP.CHIP 63V 10% 100NF 4822 122 33496 C 3134 CAP.CHIP...
Page 232 5.2 - 56 UNIT DESCRIPTIONS Item Description Ordering code C 4118 CAP.CHIP 63V 5% 1NF 5322 126 10511 C 4119 CAP.CHIP 63V 5% 1NF 5322 126 10511 C 4121 CAP.CHIP 63V 10% 100NF 4822 122 33496 C 4122 CAP.CHIP 63V 5% 1NF 5322 126 10511 C 4123 CAP.CHIP...
Page 233 UNIT DESCRIPTIONS 5.2 - 57 Item Description Ordering code C 5322 CAP.CHIP 63V 10% 10NF 5322 122 34098 C 5326 CAP.CHIP 63V 10% 10NF 5322 122 34098 C 5331 CAP.ELECTROLYT. 100V 20% 27UF 5322 124 42193 C 5332 CAP.CHIP 63V 10% 10NF 5322 122 34098 C 5336 CAP.ELECTROLYT.
Page 234 5.2 - 58 UNIT DESCRIPTIONS Item Description Ordering code R 1021 RES.CHIP RC-02H 1% 100E 4822 051 10101 R 1022 RES.CHIP RMC1/8 1% 42E2 5322 117 11753 R 1023 RES.CHIP RC-02H 1% 196E 5322 117 10538 R 1024 RES.CHIP RC-02H 1% 100E 4822 051 51001 R 1027 RES.CHIP...
Page 235 UNIT DESCRIPTIONS 5.2 - 59 Item Description Ordering code R 1203 RES.CHIP RC-02H 1% 100K 4822 051 51004 R 1204 RES.CHIP RMC1/8 1% 51E1 5322 111 91893 R 1206 RES.CHIP RC-02H 1% 2K37 4822 051 52372 R 1207 RES.CHIP RC-02H 1% 2K37 4822 051 52372 R 1208 RES.CHIP...
Page 236 5.2 - 60 UNIT DESCRIPTIONS Item Description Ordering code R 2111 RES.CHIP RMC1/8 1% 21E5 5322 111 92014 R 2112 RES.CHIP RC-02H 1% 383E 4822 051 53831 R 2114 RES.CHIP RC-01 1% 6E8 4822 051 10688 R 2131 RES.CHIP RMC1/8 1% 21E5 5322 111 92014 R 2132 RES.CHIP...
Page 237 UNIT DESCRIPTIONS 5.2 - 61 Item Description Ordering code R 2313 RES.CHIP RC-02H 1% 750E 4822 051 57501 R 2411 RES.CHIP RC-02H 1% 750E 4822 051 57501 R 2412 RES.CHIP RC-02H 1% 750E 4822 051 57501 R 2416 RES.CHIP RMC1/8 1% 42E2 4822 111 91887 R 2418 RES.CHIP...
Page 238 5.2 - 62 UNIT DESCRIPTIONS Item Description Ordering code R 3151 RES.CHIP RMC1/8 1% 10E 4822 111 91885 R 3161 RES.CHIP RMC1/8 1% 42K2 4822 111 91887 R 3171 RES.METAL FILM MRS25 1% 9K53 4822 050 29532 R 3176 RES.CHIP RC-02H 1% 51K1 4822 051 55113 R 3201...
Page 239 UNIT DESCRIPTIONS 5.2 - 63 Item Description Ordering code R 4032 RES.CHIP RC-02H 1% 31K6 4822 051 53163 R 4033 RES.CHIP RC-02H 1% 1K 4822 051 51002 R 4034 RES.CHIP RMC1/8 1% 10E 4822 111 91885 R 4036 RES.CHIP RC-02H 1% 316E 4822 051 53161 R 4037 RES.CHIP...
Page 240 5.2 - 64 UNIT DESCRIPTIONS Item Description Ordering code R 4150 RES.CHIP RC-01 5% 4E7 4822 051 10478 R 4151 RES.CHIP RC-01 5% 10E 4822 111 91885 R 4152 RES.CHIP RMC1/8 1% 42E2 4822 111 91887 R 4153 RES.CHIP RMC1/8 1% 42E2 4822 111 91887 R 4154 RES.CHIP...
Page 241 UNIT DESCRIPTIONS 5.2 - 65 Item Description Ordering code R 5133 RES.CHIP RC-02H 1% 10K 4822 051 51003 R 5134 RES.CHIP RC-02H 1% 10K 4822 051 51003 R 5136 RES.CHIP RC-02H 1% 10K 4822 051 51003 R 5137 RES.CHIP RC-02H 1% 3K83 4822 051 53832 R 5138 RES.CHIP...
Page 242 5.2 - 66 UNIT DESCRIPTIONS Item Description Ordering code V 2101 TRANSISTOR,CHIP BF824 PEL 4822 130 60383 V 2102 DIODE,CHIP BZX84-B12 PEL 4822 130 83566 V 2103 DIODE,CHIP BZX84-B12 PEL 4822 130 83566 V 2105 DIODE,CHIP BZX84-B12 PEL 4822 130 83566 V 2111 TRANSISTOR,CHIP BF824 PEL...
Page 243 UNIT DESCRIPTIONS 5.2 - 67 Item Description Ordering code V 3232 TRANSISTOR,CHIP BF840 PEL 4822 130 60887 V 3233 TRANSISTOR,CHIP BF824 PEL 4822 130 60383 V 3234 TRANSISTOR BFQ231 PEL 5322 130 63034 V 3236 DIODE,CHIP BAS21 PEL 4822 130 33702 V 3237 DIODE,CHIP BAS21 PEL...
Page 244 5.2 - 68 UNIT DESCRIPTIONS Item Description Ordering code V 4114 TRANSISTOR,CHIP BC858C PEL 4822 130 42513 V 5001 DIODE,CHIP BAS21 PEL 4822 130 33702 V 5002 DIODE,CHIP BAS21 PEL 4822 130 33702 CONNECTORS AND SOCKETS X 2101 CONNECTOR 4-P SNG RT.ANG 5322 265 30907 X 2301 CONNECTOR...
Page 245 UNIT DESCRIPTIONS 5.3 - 1 MICROPROCESSOR A3 5.3.1 Description A3 Introduction The unit can be seen as the heart of the oscilloscope. It controls all oscilloscope functions and receives input signals from the following sources: the rotary and push button knobs present at front unit A4 and CRT controls unit A5. commands from an external computer that are applied to the RS232 interface that is part of microprocessor D1001.
Page 246 5.3 - 2 UNIT DESCRIPTIONS Diagram 3 The resistance value of the indication ring in the probe at channels 1, 2, 3 and 4 is present between ground and the ADC input pins 16,18,20 and 24 of the processor. The analog probe resistance value results in a certain DC voltage that is converted by the ADC input of the processor D1001.
Page 247 UNIT DESCRIPTIONS 5.3 - 3 DACPWR-LT WRITE SIGNAL FOR DACPOT CIRCUIT D1016:01 D1112:03 DLEN0-HT DATA LATCH ENABLE 0 R1063:01 X1101:04 DLEN1-HT DATA LATCH ENABLE 1 R1064:01 X1101:04 DLEN2-HT DATA LATCH ENABLE 2 R1066:01 X1101:04 FOCUS-DA DC PART FOCUSING SIGNAL R1136:03 X1101:04 HOLDOFF HOLD OFF CONTROL SIGNAL...
Page 248 5.3 - 4 UNIT DESCRIPTIONS 5.3.3 Location list '-L' means that the component is located on the 'Large component side'. Others are components located on the 'small component side'. C1002 C11 C1833 C2 D1111 D3 R1066 B9 C1003 C11 C1861 B4-L D1112 A5 R1067 B9 C1004 D11...
Page 249 UNIT DESCRIPTIONS 5.3 - 5 5.3.4 Unit lay-outs Lay-out 1 - Large component side of microprocessor unit A3...
Page 250 5.3 - 6 UNIT DESCRIPTIONS Lay-out 2 - Small component side of microprocessor unit A3...
Page 251 UNIT DESCRIPTIONS 5.3 - 7 5.3.5 Circuit diagrams A3 - Diagram 1; Central processor unit...
Page 252 5.3 - 8 UNIT DESCRIPTIONS A3 - Diagram 2; Processor memory...
Page 253 UNIT DESCRIPTIONS 5.3 - 9 A3 - Diagram 3; Auxiliary circuits...
Page 254 5.3 - 10 UNIT DESCRIPTIONS A3 - Diagram 4; Potentiometer DAC and IEEE-option...
Page 255 UNIT DESCRIPTIONS 5.3 - 11 A3 - Diagram 5; Text and cursor circuit...
Page 256 5.3 - 12 UNIT DESCRIPTIONS...
Page 257 UNIT DESCRIPTIONS 5.3 - 13 Item Description Ordering code 5.3.6 Parts list CAPACITORS C1002 CAP.CERAMIC AP 63V 5% 39PF 5322 122 32966 C1003 CAP.CERAMIC AP 63V 5% 39PF 5322 122 32966 C1004 CAP.CHIP AP 63V 10% 100NF 4822 122 33496 C1006 CAP.CHIP AP 63V 10% 100NF...
Page 258 5.3 - 14 UNIT DESCRIPTIONS Item Description Ordering code C1806 CAP.CHIP AP 63V 10% 10NF 5322 122 34098 C1807 CAP.CHIP AP 63V 10% 100NF 4822 122 33496 C1809 CAP.CHIP AP 63V 10% 10NF 5322 122 34098 C1811 CAP.CHIP AP 63V 10% 10NF 5322 122 34098 C1812 CAP.CHIP...
Page 259 UNIT DESCRIPTIONS 5.3 - 15 Item Description Ordering code INTEGRATED CIRCUITS D1001 MICROPROCESSOR INT0001N1 UPROC 5322 209 12591 D1004 INTEGR.CIRCUIT SN74LS32DR2 MOT 5322 209 52442 D1006 INTEGR.CIRCUIT PAL PROGR CHIP SEL 5322 209 33501 D1007 INTEGR.CIRCUIT PC74HCT14T PEL 5322 209 71568 D1010 INTEGR.CIRCUIT N74F08D PEL...
Page 260 5.3 - 16 UNIT DESCRIPTIONS Item Description Ordering code R1023 RES.CHIP HIP RC-01 5% 1E 4822 051 10108 R1024 RES.CHIP HIP RC-01 5% 1E 4822 051 10108 R1026 RES.CHIP HIP RC-02H 1% 100E 4822 051 10101 R1028 RES.CHIP HIP RC-02H 1% 10K 4822 051 10103 R1029 RES.CHIP...
Page 261 UNIT DESCRIPTIONS 5.3 - 17 Item Description Ordering code R1122 RES.CHIP HIP RC-02H 1% 100E 4822 051 10101 R1123 RES.CHIP HIP RC-02H 1% 100E 4822 051 10101 R1124 RES.CHIP HIP RC-02H 1% 100E 4822 051 10101 R1125 RES.CHIP HIP RC-02H 1% 100E 4822 051 10101 R1126 RES.CHIP...
Page 262 5.3 - 18 UNIT DESCRIPTIONS Item Description Ordering code MISCELLANEOUS G1001 CRYSTAL XTAL 12.0MHZ PEL 4822 242 71663 G1111 RESONATOR XTAL 16MHZ MUR 5322 242 72193 H1001 BUZZER PKM17EPP-4001 MUR 4822 280 10198 L1111 COIL 470UH TDK 5322 157 52362...
Page 263 UNIT DESCRIPTIONS 5.4 - 1 FRONT UNIT A4 5.4.1 Description Diagram 1 The front unit incorporates several keys and a number of rotary knobs that are read by a microcomputer D5001. This microcomputer can communicate with the instrument’s main microprocessor on unit A3 via connector X5002. The communication from front unit A4 to unit A3 occurs via buffer D5003.
Page 264 5.4 - 2 UNIT DESCRIPTIONS 5.4.3 Key switches Test code is obtained via the UTIL MAINTENANCE menu. Refer to section 8.11.4.2 for detailed information. SWITCH PM33x4A PM33x2A PM33x0A TEST CODE S5001 DISPLAY DISPLAY DISPLAY S5002 MATH MATH MATH S5003 MEASURE MEASURE MEASURE S5004...
Page 265 UNIT DESCRIPTIONS 5.4 - 3 SWITCH PM33x4A PM33x2A PM33x0A TEST CODE S5051 ON CH4 ON CH4 TRIG VIEW S5052 AUTORANGE CH4 AMPL AMPL S5053 TRIG CH3 TRIG CH3 S5054 TRIG CH2 TRIG CH2 TRIG CH2 S5056 TRIG CH1 TRIG CH1 TRIG CH1 S5057 ON CH1...
Page 266 5.4 - 4 UNIT DESCRIPTIONS...
Page 267 UNIT DESCRIPTIONS 5.4 - 5 5.4.4 Unit lay-outs Lay-out 1 - Large component side of front unit A4...
Page 268 5.4 - 6 UNIT DESCRIPTIONS Lay-out 2 - Small component side of front unit A4...
Page 269 UNIT DESCRIPTIONS 5.4 - 7 5.4.5 Circuit diagrams A4 - Diagram 1; front processor...
Page 270 5.4 - 8 UNIT DESCRIPTIONS A4 - Diagram 2; Key matrix...
Page 271 UNIT DESCRIPTIONS 5.4 - 9 Item Description Ordering code 5.4.6 Parts list CAPACITORS C5001 CAP.CERAMIC AP 63V 5% 39PF 5322 122 32966 C5002 CAP.CERAMIC AP 63V 5% 39PF 5322 122 32966 C5150 CAP.CHIP AP 63V 5% 100PF 5322 122 32531 C5151 CAP.CHIP AP 63V 5% 100PF...
Page 272 5.4 - 10 UNIT DESCRIPTIONS Item Description Ordering code R5128 RES.METAL FILM HIP RC-02H 1% 56K2 5322 117 10574 R5129 RES.METAL FILM HIP RC-02H 1% 56K2 5322 117 10574 R5150 RES.CHIP HIP RC-02H 1% 100E 4822 051 10101 R5151 RES.CHIP HIP RC-02H 1% 100E 4822 051 10101 R5152...
Page 273 UNIT DESCRIPTIONS 5.4 - 11 Item Description Ordering code V5032 DIODE,CHIP BAS16 PEL 5322 130 31928 V5033 DIODE,CHIP BAS16 PEL 5322 130 31928 V5034 DIODE,CHIP BAS16 PEL 5322 130 31928 V5036 DIODE,CHIP BAS16 PEL 5322 130 31928 V5037 DIODE,CHIP BAS16 PEL 5322 130 31928 V5038 DIODE,CHIP...
Page 274 5.4 - 12 UNIT DESCRIPTIONS Item Description Ordering code...
Page 275 UNIT DESCRIPTIONS 5.5 - 1 CRT CONTROLS UNIT A5 5.5.1 Description Each rotary can occupy 4 different states. A rotary incorporates a rotor contact that can make contact with one of the two stator contacts. It is also possible that the rotor makes no contact. The last possibility is that the rotor makes contact with both stator contacts.
Page 276 5.5 - 2 UNIT DESCRIPTIONS 5.5.2 Unit Lay-outs Lay-out 1; Smal component side of Lay-out 2; Large component side of CRT controls unit A5 CRT controls unit A5...
Page 277 UNIT DESCRIPTIONS 5.5 - 3 5.5.3 Circiuit diagram A5 - Diagram 1; CRT controls unit...
Page 278 5.5 - 4 UNIT DESCRIPTIONS 5.5.4 Parts list SEMICONDUCTORS V 5201 DIODE,CHIP BAV99 PEL 5322 130 34337 V 5202 DIODE,CHIP BAV99 PEL 5322 130 34337 V 5203 DIODE,CHIP BAV99 PEL 5322 130 34337 V 5204 DIODE,CHIP BAV99 PEL 5322 130 34337 V 5206 DIODE,CHIP BAV99 PEL...
Page 279 UNIT DESCRIPTIONS 5.6 - 1 POWER SUPPLY A6 5.6.1 Description A6 Diagram 1 Diagram 1 comprises the following circuit parts: input circuit converter circuit line trigger circuit Input circuit Input to the circuit is the mains voltage. The following voltages are allowed: AC voltage between 90 and 250 V Theoretically a DC voltage between 100 and 380 V can be applied.
Page 280 5.6 - 2 UNIT DESCRIPTIONS To reduce the switching losses in V1019, a dV/dt limiter, often called LINE IN: 110 VAC LINE IN: 220 VAC "snubber", is used. C1021 decreases the dV/dt of the collector voltage of FLYBACK FLYBACK V1019 during switching off, as the current to the transistor can pass during a certain time through C1021.
Page 281 UNIT DESCRIPTIONS 5.6 - 3 Illumination control The illumination of the graticule must be variable. For this reason the illumination voltage can be varied between about 2 and 28 V. Control of the illumination amplifier V1148 takes place by means of the signal DAC2, level about 1.7 to 4 V.
Page 282 5.6 - 4 UNIT DESCRIPTIONS Secondary output circuitry The secondary output circuits consist of rectifier diodes and buffer capacitors, followed by chokes and capacitors for ripple suppression. The output circuits are protected against overload by the under voltage protection. Over and under-voltage protection To protect the oscilloscope circuitry against over-voltage and the supply circuits against overload, the power supply is provided with a protection circuit.
Page 283 UNIT DESCRIPTIONS 5.6 - 5 5.6.2 Signal name list A6 Note: In the signal name list you find the itemnumber of the component that is source or destination. Behind this itemnumber (separated by ":") you find the number of the diagram where the source/destination can be found.
Page 284 5.6 - 6 UNIT DESCRIPTIONS...
Page 285 UNIT DESCRIPTIONS 5.6 - 7 5.6.3 Unit lay-outs Lay-out 1 - Large component side of Power Supply unit A6...
Page 286 5.6 - 8 UNIT DESCRIPTIONS Lay-out 2 - Small component side of Power Supply unit A6...
Page 287 UNIT DESCRIPTIONS 5.6 - 9 5.6.4 Circuit diagrams A6 - Diagram 1; Converter circuit...
Page 288 5.6 - 10 UNIT DESCRIPTIONS A6 - Diagram 2; EHT converter and auxiliary circuits...
Page 289 UNIT DESCRIPTIONS 5.6 - 11 A6 - Diagram 3; Output circuit and protection circuits...
Page 290 5.6 - 12 UNIT DESCRIPTIONS...
Page 291 UNIT DESCRIPTIONS 5.6 - 13 Item Description Ordering code 5.6.5 Parts list CAPACITORS C1001 CAP.FOIL 250V 20% 220NF 5322 121 44372 C1002 CAP.FOIL -20+20% 1NF 5322 121 43656 C1003 CAP.CHIP AP 63V 10% 100NF 4822 122 33496 C1004 CAP.CHIP AP 63V 10% 100NF 4822 122 33496 C1006 CAP.FOIL...
Page 292 5.6 - 14 UNIT DESCRIPTIONS Item Description Ordering code C1211 CAP. 25V -20+20% 1000UF 5322 124 23276 C1212 CAP.FOIL 25V 20% 470UF 5322 121 43885 C1213 CAP.FOIL 25V 20% 470UF 5322 121 43885 C1214 CAP.FOIL 25V 20% 470UF 5322 121 43885 C1216 CAP.ELECTROLYT.
Page 293 UNIT DESCRIPTIONS 5.6 - 15 Item Description Ordering code COILS L1001 COIL ECH30 180UH TDK 5322 157 63378 L1004 COIL 5.6UH 4822 157 52259 L1006 COIL PG1 RM6S T&M OSC. 5322 157 70858 L1101 COIL 82UH 4822 158 10563 L1131 COIL 0.015H TDK 5322 157 63383...
Page 294 5.6 - 16 UNIT DESCRIPTIONS Item Description Ordering code R1057 RES.CHIP RMC1/8 1% 10E 4822 111 91885 R1058 RES.METAL FILM HIP RC-02H 1% 7K5 5322 117 10583 R1061 RES.CHIP HIP RC-02H 1% 100K 4822 051 10104 R1062 RES.CHIP HIP RC-02H 1% 100K 4822 051 10104 R1063 RES.CHIP...
Page 295 UNIT DESCRIPTIONS 5.6 - 17 Item Description Ordering code R1235 RES.CHIP HIP RC-02H 1% 1K 4822 051 10102 R1236 RES.CHIP HIP RC-02H 1% 215E 5322 117 10484 R1238 RES.CHIP HIP RC-02H 1% 5K11 5322 117 10487 R1239 RES.METAL FILM HIP RC-02H 1% 2K37 5322 117 10545 R1241 RES.METAL FILM...
Page 296 5.6 - 18 UNIT DESCRIPTIONS Item Description Ordering code V1022 RECTIFIER BYV26C PEL 4822 130 32343 V1023 DIODE,REFERENCE BZX79-C3V0 PEL 4822 130 31881 V1046 DIODE,REFERENCE BZX84-C5V1 PEL 5322 130 32835 V1100 DIODE,REFERENCE BZX84-C11 PEL 4822 130 81338 V1102 TRANSISTOR,CHIP BC858C PEL 4822 130 42513 V1103 DIODE,REFERENCE...
Page 297 UNIT DESCRIPTIONS 5.6 - 19 Item Description Ordering code V1279 DIODE,CHIP BAT17 PEL 5322 130 31544 V1281 DIODE,CHIP BAS21 PEL 4822 130 33702 V1283 DIODE,REFERENCE BZX84-C15 PEL 5322 130 33662 V1284 TRANSISTOR,CHIP BF820 PEL 5322 130 62802 V9016 TRANSISTOR 2SK119 TOS 5322 130 63358 V9018 RECTIFIER...
Page 298 5.6 - 20 UNIT DESCRIPTIONS Item Description Ordering code...
Page 299 UNIT DESCRIPTIONS 5.7 - 1 RESERVED FOR FUTURE EXTENSIONS...
Page 300 5.7 - 2 UNIT DESCRIPTIONS...
Page 301 UNIT DESCRIPTIONS 5.8 - 1 DIGITIZER A8 5.8.1 Descriptions 5.8.1.1 Diagram 1 5.8.1.2 Diagram 2 Vertical channel inputs Four input channel signals are derived from the analog oscilloscope section unit A1. Channel 1 : X1301/X1302 Channel 2 : X2301/X2302 Channel 3 : X3301/X3302 Channel 4 : X4301/X4302 The d.c.
Page 302 5.8 - 2 UNIT DESCRIPTIONS For the correct functioning of the limiter circuits, dc feedback loops are required, using external transistors V8021 and V8019. The output currents of the two limiter circuits are applied to amplifier and splitter stages in a multiplexed way.
Page 303 UNIT DESCRIPTIONS 5.8 - 3 5.8.1.3 Diagram 3 Control, reference and adjustment voltages: Digital to Analog Converter DACPOT The sixteen channel 12 bit Digital to Analog Converter POTentiometer DACPOT N8006 derives 14 different analog output signals from the four input bits GLOD04 ... GLOD07 from the GLOBAL data bus.
Page 304 5.8 - 4 UNIT DESCRIPTIONS 5.8.1.4 Diagram 4 Clock oscillator The 200 MHz crystal G8025 forms, together with WHISTLER circuit D8005, a 200 MHz clock generator with ECL level output clocksignals MCAA/MCNAA MCBB MCNBB of 100 MHz each for the Analog to Digital Converters on diagram 5, and MCAAR/MCNAAR for the RAndom Trigger Engine Logic (RATEL) circuit on diagram 8.
Page 305 UNIT DESCRIPTIONS 5.8 - 5 Clock switches The clock switches N8067 and N8068 are controlled by signals DSAMPAHT/ DSAMPBHT and TRCKMDHT which are generated via the SBUS (serial bus) shown in diagram 14. Only clock switch N8067 is now described: One of the following modes can be selected.
Page 306 5.8 - 6 UNIT DESCRIPTIONS This results in the databus signals SDA<7:0> and SDB<7:0> on TTL level which can be handled by the DARLIC circuit on diagram 9 The same is done for the sample-clock signals resulting in TTL level SCLKA/SCLKAN and SCLKB/SCLKBN signals which can also be handled by the DARLIC circuit.
Page 307 UNIT DESCRIPTIONS 5.8 - 7 PATTERN triggering With PATTERN selected, triggering is possible on a preselected combination of "H", "L" and "X" (don’t care) values of the input signals from channel 1 to channel 4. Triggering on "ENTER" (start of selected pattern) as well as "EXIT" (end of selected pattern) is possible on user request.
Page 308 5.8 - 8 UNIT DESCRIPTIONS The user selected times t1 and t2 are stored in two counters in the DARLIC circuit on diagram 9. These counters will start counting down after a positive edge of the signal DPATN from the COMPASS circuit, and are presetted on the negative edge of this signal.
Page 309 UNIT DESCRIPTIONS 5.8 - 9 STATE triggering With STATE triggering selected, edge-triggering with pattern- condition is possible. Polarity as well as source are to be selected by the user. Not only a pattern has to be preselected, but also the trigger channel which completes the pattern. The edge can be selected positive as well as negative.
Page 310 5.8 - 10 UNIT DESCRIPTIONS 5.8.1.7 Diagram 7 DELTA-T circuit A DELTA-T circuit is introduced to measure the time between the moment of triggering and the real sample moment. This is needed to know for which memory location converted digital codes have to be stored.
Page 311 UNIT DESCRIPTIONS 5.8 - 11 At the moment that an active trigger signal appears, signal RUNDT switches to logic "1" and transistor V8126 is blocked. Transistor V8124 starts conducting. Capacitor C8271 is then charged very fast by a current of 30 mA from the charge current source to a voltage which depends on the time between the trigger pulse and the second positive going edge of the 100 MHz clock signal MCAA.
Page 312 5.8 - 12 UNIT DESCRIPTIONS 5.8.1.8 Diagram 8 The RAndom Trigger Engine Logic circuit (RATEL) is a very fast (300MHz) circuit for selection of the source on which triggering takes place. It synchronizes the selected trigger with the 100 MHz system clock.
Page 313 UNIT DESCRIPTIONS 5.8 - 13 Event trigger mode Signal ENEV (enable event) is also used for event counting in Event trigger mode. The clockpulse for the Event mode is signal ECLK. In the Event mode, the source is DSOD selected by the signals SLEONE ("1") and SLETWO ("0"). Switching between normal and event triggering is done with signal EVENT-HT.
Page 314 5.8 - 14 UNIT DESCRIPTIONS 5.8.1.9 Diagram 9 Data Acquisition and tRigger Logic IC (DARLIC) The output datawords SDA<7:0> and SDB<7:0> from the two Analog to Digital Converters on diagram 5 are applied to the DARLIC circuit D8027. The DARLIC circuit is programmed by memory mapped I/O commands.
Page 315 UNIT DESCRIPTIONS 5.8 - 15 DATA DATA MIN/MAX JUNCTION OUTPUT INPUT Address generation DATA FLAG SELECT INPUT ST6806 With the Data Input block a selection between the converted sample data from the two ADCs and data obtained from the Digital Signal Processor (DSP) is made. Both channels use the clock used by the corresponding ADC.
Page 316 5.8 - 16 UNIT DESCRIPTIONS Edge selector: Edges can be used for triggering in general but are a prerequisite for random sampling. The following "edges" are available for the trigger engine: DSOM and DSOD signals which come directly from the analog oscilloscope section. DTBGATE comes directly from the analog oscilloscope section.
Page 317 UNIT DESCRIPTIONS 5.8 - 17 SBUS system: The SBUS (serial bus) interface is built-in in the Data Acquisition and tRigger Logic IC (DARLIC) circuit D8027. It is used as an output bus. The lines are open collector I/O pins, SDA (SerialDAta) and SCL (SerialCLock), and a select line SSEL.
Page 318 5.8 - 18 UNIT DESCRIPTIONS 5.8.1.11 Diagram 11 Bus Arbiter and Trace Generator The main function of the Bus Arbiter and Trace Generator (BATGE) D8048 is the arbitration between multiple processors, multiple memories and memory mapped I/O with a minimum of interference. This circuit is running on a 40MHz clockfrequency from the circuit G8053, signal CK40M on diagram 10.
Page 319 UNIT DESCRIPTIONS 5.8 - 19 Data flow between BATGE and unit A3: ALE-HT Adress latch enable ALE-HT = "0" data on CPAD<07:00> ALE-HT = "1" address on CPAD<07:00> BATRDYHT Batge ready signal for the wait state logic BATINTHT Batge interrupt signal In digital mode, each 16 ms a pulse is generated as indication that text on the CRT display has to be refreshed.
Page 320 5.8 - 20 UNIT DESCRIPTIONS DSPRW-LT DSP read/write signal DSPRW-LT = "0" write cycle DSPRW-LT = "1" read cycle GLOA<16:0> 17 bits global address bus GLOD<15:0> 16 bits bidirectional global data bus PRAMCSLT Active low chip select signal for PRAM PRAMOELT Active low output enable signal for PRAM PRAMRWLT...
Page 321 UNIT DESCRIPTIONS 5.8 - 21 Intensity control circuit All conditions under which the Z-control circuit has to switch the CRT beam ON and OFF are combined in the intensity control circuit. The intensity information comes via the SBUS (serial BUS) to the six channel DAC N8070.
Page 322 5.8 - 22 UNIT DESCRIPTIONS Vector circuit: YDAC0 and YDAC1 as well as XDAC0 and XDAC1 are applied to the vector circuit (dot join circuit) N8061 as symmetrical signals. The VECTOR circuit is provided with a 2 mA reference current via transistor V8037 and R8384 (signal VECBIAS is not used).
Page 323 UNIT DESCRIPTIONS 5.8 - 23 D8032 ENST13HT to diagram 1 PCCDMDLT to diagram 1 and 2 CPST13HT to diagram 1 DSAMPBHT to diagram 4 ENST24HT to diagram 2 DSAMPAHT to diagram 4 CPST24HT to diagram 2 TRCKMDHT to diagram 4 HEFOUT to X1008 on unit A10 Power distribution...
Page 324 5.8 - 24 UNIT DESCRIPTIONS COMP 3N Logic input channel 3 N8024:1 R8291:6 COMP 3P Logic input channel 3 N8024:1 R8288:6 COMP 4N Logic input channel 4 N8021:2 R8309:6 COMP 4P Logic input channel 4 N8021:2 R8316:6 CPA<13:08> CPU address bus X8101:11 D8048:11 CPAD<07:00>...
Page 325 UNIT DESCRIPTIONS 5.8 - 25 FA<14:00> FAM adress bus D8027:9 FAM:9 FAMWRLT FAM write (2K) J8001:9 FAM:9 FD<63:00> FAM data bus D8027:9 FAM:9 FRDN FAM read cycle D8027:9 FAM:9 FSCN<7:0> FAM chip select D8027:9 FAM:9 FWRN FAM write cycle D8027:9 J8001:9 GAINMPUA Gain MASPU A...
Page 326 5.8 - 26 UNIT DESCRIPTIONS OFFSADCA Offset ADC A R8783:3 R8111:3 OFFSADCB Offset ADC B R8776:3 R8114:3 OFFSCMP1 Logic trigger level control CH. 1 R8782:3 R8762:6 OFFSCMP2 Logic trigger level control CH. 2 R8780:3 R8761:6 OFFSCMP3 Logic trigger level control CH. 3 R8784:3 R8763:6 OFFSCMP4...
Page 327 UNIT DESCRIPTIONS 5.8 - 27 SCLKA Sample clock A (100 MHz, TTL) D8004:5 D8027:9 SCLKB Sample clock B (100 MHz, TTL) D8003:5 D8027:9 SCLKAN Sample clock A (100 MHz, TTL) D8004:5 D8027:9 SCLKBN Sample clock B (100 MHz, TTL) D8003:5 C8513:9 Serial data D8027:9...
Page 328 5.8 - 28 UNIT DESCRIPTIONS XTXT1 X digital text and trace output N8061:13 X8101:13 XYSW0 AN/DIG trace switch V8041:12 X8101:12 XYSW1 AN/DIG trace switch V8036:12 X8101:12 YDAC0 Y DAC output N8058:12 N8061:13 V8203:13 YDAC1 Y DAC output N8058:12 N8061:13 V8204:13 YOFFS Y offset N8009:13...
Page 329 UNIT DESCRIPTIONS 5.8 - 29 5.8.3 Unit lay-outs Lay-out 1 - A8 Digitizer, large component side (extension -L)
Page 330 5.8 - 30 UNIT DESCRIPTIONS Lay-out 2 - A8 Digitizer, small component side...
Page 331 UNIT DESCRIPTIONS 5.8 - 31 5.8.4 Location list Extention -L = Large component side lay-out No extention = Small component side lay-out C8001 C5 C8094 A2 C8173 D3 C8236 C13 C8002 B5 C8096 A2 C8175 D3 C8237 C13 C8003 C5-L C8097 C2-L C8176 C2 C8238 C13...
Page 332 5.8 - 32 UNIT DESCRIPTIONS C8501 C6 C8747 A4-L C8809 B14 D8006 B7-L C8502 C6 C8748 A3-L C8810 B13-L D8027 C7-L C8503 D1-L C8749 A13 C8811 B13-L D8030 A5 C8504 C1-L C8750 A13 C8812 B13 D8032 D6 C8506 C1-L C8753 D1 C8813 C1 D8033 A5 C8507 D1-L...
Page 333 UNIT DESCRIPTIONS 5.8 - 33 N8019 D1 R8074 C3 R8148 C5 R8218 D1-L N8021 B3 R8077 D1-L R8149 C5 R8219 D2-L N8022 C3 R8078 D1-L R8151 C4-L R8221 D3 N8023 D3 R8079 D1-L R8152 C4-L R8222 D2 N8024 C3 R8081 D1-L R8153 C4 R8223 D2-L N8026 D3-L...
Page 334 5.8 - 34 UNIT DESCRIPTIONS R8297 D6 R8367 B13 R8439 B10 R8517 B5-L R8298 D6 R8368 D13 R8441 A6-L R8518 D12 R8299 B2-L R8369 D13 R8442 A5-L R8519 C3-L R8301 A2-L R8372 D13 R8443 A6 R8521 C3-L R8302 A2-L R8373 B10 R8444 A5 R8522 B4 R8304 B2...
Page 335 UNIT DESCRIPTIONS 5.8 - 35 R8576 C5 R8751 A4-L R8809 A6 R8865 B13 R8577 C5 R8752 A4-L R8810 A6 R8866 D4 R8581 D3 R8753 A4-L R8811 A6 R8867 C4 R8583 C3 R8754 A3 R8812 A5 R8868 C1-L R8586 C3 R8755 A4-L R8813 A5 R8869 C1-L R8588 B3...
Page 336 5.8 - 36 UNIT DESCRIPTIONS R8934 B3-L V8050 D13 V8112 A12 V8193 D1 R8936 D3-L V8051 D4 V8113 D13 V8194 C1 R8937 B3-L V8053 C4-L V8114 A5 V8195 D1 R8938 C3-L V8054 C3 V8117 B13-L V8196 C1 R8939 B3-L V8057 C4-L V8122 A5 V8197 D1 V8001 B1...
Page 337 UNIT DESCRIPTIONS 5.8 - 37 5.8.5 Circuit diagrams A8 - Diagram 1a; Channel 1 and 3 (200 MHz version)
Page 338 5.8 - 38 UNIT DESCRIPTIONS A8 - Diagram 1b; Channel 1 and 3 (100 MHz version)
Page 339 UNIT DESCRIPTIONS 5.8 - 39 A8 - Diagram 2a; Channel 2 and 4 (200 MHz version)
Page 340 5.8 - 40 UNIT DESCRIPTIONS A8 - Diagram 2b; Channel 2 and 4 (100 MHz version)
Page 341 UNIT DESCRIPTIONS 5.8 - 41 A8 - Diagram 3; Ref. and adj. voltages...
Page 342 5.8 - 42 UNIT DESCRIPTIONS A8 - Diagram 4; Clock...
Page 343 UNIT DESCRIPTIONS 5.8 - 43 A8 - Diagram 5; ADC and ECL-TTL...
Page 344 5.8 - 44 UNIT DESCRIPTIONS A8 - Diagram 6; COMPASS...
Page 345 UNIT DESCRIPTIONS 5.8 - 45 A8 - Diagram 7; Delta T circuit...
Page 346 5.8 - 46 UNIT DESCRIPTIONS A8 - Diagram 8; Trigger logic...
Page 347 UNIT DESCRIPTIONS 5.8 - 47 A8 - Diagram 9a; DARLIC and FAM...
Page 348 5.8 - 48 UNIT DESCRIPTIONS A8 - Diagram 9b; DARLIC and extended FAM...
Page 349 UNIT DESCRIPTIONS 5.8 - 49 A8 - Diagram 10; Digital Signal Processor...
Page 350 5.8 - 50 UNIT DESCRIPTIONS A8 - Diagram 11a; BATGE and MAM...
Page 351 UNIT DESCRIPTIONS 5.8 - 51 A8 - Diagram 11b; BATGE and extended MAM...
Page 352 5.8 - 52 UNIT DESCRIPTIONS A8 - Diagram 12; CURCON and XYZ Control...
Page 353 UNIT DESCRIPTIONS 5.8 - 53 A8 - Diagram 13; Display interface...
Page 354 5.8 - 54 UNIT DESCRIPTIONS A8 - Diagram 14; Power distribution...
Page 355 UNIT DESCRIPTIONS 5.8 - 55 Item Description Ordering code 5.8.6 Parts list CAPACITORS C8001 CAP.CHIP 63V 10% 100NF 4822 122 33496 C8002 CAP.CHIP 63V 10% 100NF 4822 122 33496 C8003 CAP.CHIP 63V 10% 100NF 4822 122 33496 C8004 CAP.CHIP 63V 10% 100NF 4822 122 33496 C8006 CAP.CHIP...
Page 356 5.8 - 56 UNIT DESCRIPTIONS Item Description Ordering code C8087 CAP.CHIP 63V 10% 100NF 4822 122 33496 C8088 CAP.CHIP 63V 10% 100NF 4822 122 33496 C8089 CAP.CHIP 63V 10% 1.5NF 5322 122 31865 C8091 CAP.CHIP 63V 10% 100NF 4822 122 33496 C8092 CAP.CHIP 63V 10% 1.5NF...
Page 357 UNIT DESCRIPTIONS 5.8 - 57 Item Description Ordering code C8147 CAP.FOIL 63V 10% 680NF 5322 121 42498 C8148 CAP.CHIP 63V 10% 100NF 4822 122 33496 C8151 CAP.CHIP 63V 10% 10NF 5322 122 34098 C8153 CAP.CHIP 63V 10% 10NF 5322 122 34098 C8154 CAP.CHIP 63V 10% 10NF...
Page 358 5.8 - 58 UNIT DESCRIPTIONS Item Description Ordering code C8219 CAP.CERAMIC 63V 0.25PF 1.8PF 5322 126 10343 C8220 CAP.CHIP 63V 5% 15PF 5322 122 33869 C8221 CAP.CHIP 63V 10% 100NF 4822 122 33496 C8222 CAP.CHIP 63V 10% 100NF 4822 122 33496 C8223 CAP.CHIP 63V 5% 15PF...
Page 359 UNIT DESCRIPTIONS 5.8 - 59 Item Description Ordering code C8270 CAP.ELECTROLYT. 25V 20% 47UF 5322 121 10472 C8271 CAP.FOIL 400V 5% 150PF 5322 121 51644 C8273 CAP.ELECTROLYT. 25V 20% 180UF 5322 124 42228 C8274 CAP.ELECTROLYT. 25V 20% 180UF 5322 124 42228 C8276 CAP.ELECTROLYT.
Page 360 5.8 - 60 UNIT DESCRIPTIONS Item Description Ordering code C8592 CAP.CHIP 63V 10% 10NF 5322 122 34098 C8593 CAP.CHIP 63V 10% 10NF 5322 122 34098 C8594 CAP.CHIP 63V 10% 10NF 5322 122 34098 C8596 CAP.CHIP 63V 5% 100PF 5322 122 32531 C8597 CAP.CHIP 63V 5% 100PF...
Page 361 UNIT DESCRIPTIONS 5.8 - 61 Item Description Ordering code C8760 CAP.CHIP 63V 10% 10NF 5322 122 34098 C8762 CAP.CERAMIC 63V 0.25PF 1PF 5322 122 32447 C8764 CAP.CHIP 63V 10% 22NF 5322 122 32654 C8765 CAP.CHIP 63V 10% 22NF 5322 122 32654 C8766 CAP.CHIP 63V 10% 10NF...
Page 362 5.8 - 62 UNIT DESCRIPTIONS Item Description Ordering code C8809 CAP.CHIP 63V 10% 10NF 5322 122 34098 C8810 CAP.CHIP 63V 5% 1NF 5322 126 10511 C8811 CAP.CHIP 63V 5% 1NF 5322 126 10511 C8812 CAP.CHIP 63V 10% 10NF 5322 122 34098 C8813 CAP.CHIP 63V 10% 100NF...
Page 363 UNIT DESCRIPTIONS 5.8 - 63 Item Description Ordering code C8853 CAP.CHIP 63V 10% 10NF 5322 122 34098 C8854 CAP.CHIP 63V 10% 10NF 5322 122 34098 C8855 CAP.FOIL 10V 20% 100UF 5322 124 41383 C8860 CAP.CHIP 63V 5% 12PF 4822 122 33926 C8861 CAP.CHIP 63V 10% 220NF...
Page 364 5.8 - 64 UNIT DESCRIPTIONS Item Description Ordering code D8050 INTEGR.CIRCUIT N74F86D PEL 5322 209 60265 D8051 INTEGR.CIRCUIT HM6264ALFP-12T HIT 5322 209 30265 D8052 INTEGR.CIRCUIT CY7C199-25SC CYP 5322 209 32771 D8054 INTEGR.CIRCUIT HM628128LFP-7T HIT 5322 209 52733 D8054 INTEGR.CIRCUIT HM62256LFP-10TZU HIT 5322 209 30228 D8055 INTEGR.CIRCUIT...
Page 365 UNIT DESCRIPTIONS 5.8 - 65 Item Description Ordering code MISCELLANEOUS G8024 RESONATOR XTAL 12MHZ KYO 5322 242 71444 G8025 CRYSTAL XTAL UNIT 200MHZ 5322 242 81589 G8053 CRYSTAL SRQ-0-50-40M S.R 5322 242 72575 COILS L8001 COIL 0.12UH 5% TDK 5322 157 63916 L8002 COIL 0.12UH 5% TDK...
Page 366 5.8 - 66 UNIT DESCRIPTIONS Item Description Ordering code R8057 RES.CHIP RMC1/8 1% 42E2 4822 111 91887 R8058 RES.CHIP RMC1/8 1% 42E2 4822 111 91887 R8059 RES.CHIP RMC1/8 1% 42E2 4822 111 91887 R8061 RES.CHIP RMC1/8 1% 42E2 4822 111 91887 R8062 RES.CHIP RC-02H 1% 4K64...
Page 367 UNIT DESCRIPTIONS 5.8 - 67 Item Description Ordering code R8128 RES.METAL FILM RMC1/8 1% 38E3 5322 116 83728 R8129 RES.MET.GLAZED RMC1/8 1% 31E6 5322 116 82895 R8129 RES.CHIP RC-02H 1% 75E 5322 117 11741 R8130 RES.CHIP RMC1/8 1% 42E2 4822 111 91887 R8130 RES.CHIP RC-02H 1% 31E6...
Page 368 5.8 - 68 UNIT DESCRIPTIONS Item Description Ordering code R8182 RES.MET.GLAZED RMC1/8 1% 31E6 5322 116 82895 R8182 RES.CHIP RC-02H 1% 75E 5322 117 11741 R8183 RES.METAL FILM RMC1/8 1% 38E3 5322 116 83728 R8184 RES.METAL FILM MRS25 1% 1E 4822 050 21008 R8186 RES.METAL FILM...
Page 369 UNIT DESCRIPTIONS 5.8 - 69 Item Description Ordering code R8229 RES.CHIP RC-02H 1% 4K64 4822 051 54642 R8231 RES.METAL FILM RC-02H 1% 1K21 5322 117 10521 R8232 RES.CHIP RC-02H 1% 100E 4822 051 10101 R8233 RES.CHIP RC-02H 1% 2K15 5322 117 10485 R8234 RES.METAL FILM RC-02H 1% 383E...
Page 370 5.8 - 70 UNIT DESCRIPTIONS Item Description Ordering code R8296 RES.CHIP RMC1/8 1% 42E2 4822 111 91887 R8297 RES.METAL FILM RC-02H 1% 1K21 5322 117 10521 R8298 RES.METAL FILM RC-02H 1% 1K21 5322 117 10521 R8299 RES.METAL FILM RC-02H 1% 909E 5322 117 10588 R8301 RES.
Page 371 UNIT DESCRIPTIONS 5.8 - 71 Item Description Ordering code R8357 RES.CHIP RC-01 5% 1E 4822 051 10108 R8358 RES.CHIP RC-02H 1% 5K11 5322 117 10487 R8359 RES.CHIP RC-02H 1% 5K11 5322 117 10487 R8360 RES.CHIP RC-02H 1% 5K11 5322 117 10487 R8361 RES.CHIP RC-02H 1% 1K...
Page 372 5.8 - 72 UNIT DESCRIPTIONS Item Description Ordering code R8410 RES.METAL FILM RC-02H 1% 215K 5322 117 10543 R8411 RES.METAL FILM RC-02H 1% 8K25 5322 117 10586 R8412 RES.METAL FILM RC-02H 1% 12K1 5322 117 10522 R8413 RES.CHIP RC-02H 1% 215E 5322 117 10484 R8414 RES.CHIP...
Page 373 UNIT DESCRIPTIONS 5.8 - 73 Item Description Ordering code R8471 RES.METAL FILM MRS25 1% 1E 4822 050 21008 R8472 RES.METAL FILM MRS25 1% 10E 4822 050 21009 R8473 RES.METAL FILM MRS25 1% 1E 4822 050 21008 R8474 RES.METAL FILM MRS25 1% 10E 4822 050 21009 R8476 RES.METAL FILM...
Page 374 5.8 - 74 UNIT DESCRIPTIONS Item Description Ordering code R8539 RES.METAL FILM RC-02H 1% 162E 5322 117 10529 R8540 RES.METAL FILM RC-02H 1% 1K21 5322 117 10521 R8541 RES.CHIP RMC1/8 1% 42E2 4822 111 91887 R8542 RES.CHIP RMC1/8 1% 42E2 4822 111 91887 R8543 RES.METAL FILM...
Page 375 UNIT DESCRIPTIONS 5.8 - 75 Item Description Ordering code R8591 RES.CHIP RMC1/8 1% 10E 4822 111 91885 R8592 RES.CHIP RMC1/8 1% 10E 4822 111 91885 R8593 RES.CHIP RMC1/8 1% 10E 4822 111 91885 R8594 RES.CHIP RMC1/8 1% 10E 4822 111 91885 R8596 RES.METAL FILM RC-02H 1% 464K...
Page 376 5.8 - 76 UNIT DESCRIPTIONS Item Description Ordering code R8746 RES.CHIP RMC1/8 1% 42E2 4822 111 91887 R8747 RES.CHIP RC-02H 1% 2K15 5322 117 10485 R8748 RES.CHIP RMC1/8 1% 42E2 4822 111 91887 R8749 RES.METAL FILM RC-02H 1% 1K62 5322 117 10531 R8750 RES.MET.GLAZED RMC1/8 1% 31E6...
Page 377 UNIT DESCRIPTIONS 5.8 - 77 Item Description Ordering code R8795 RES.METAL FILM RC-02H 1% 7K5 5322 117 10583 R8796 RES.CHIP RC-02H 1% 10K 4822 051 10103 R8797 RES.CHIP RC-02H 1% 51K1 4822 051 55113 R8798 RES.METAL FILM RC-02H 1% 7K5 5322 117 10583 R8799 RES.CHIP...
Page 378 5.8 - 78 UNIT DESCRIPTIONS Item Description Ordering code R8842 RES.CHIP RC-01 5% 1E 4822 051 10108 R8843 RES.METAL FILM RC-02H 1% 1K62 5322 117 10531 R8844 RES.METAL FILM RC-02H 1% 1K47 5322 117 10527 R8845 RES.METAL FILM RC-02H 1% 3K83 5322 117 10561 R8846 RES.METAL FILM...
Page 379 UNIT DESCRIPTIONS 5.8 - 79 Item Description Ordering code R8890 RES.CHIP RC-02H 1% 1K47 4822 051 51472 R8891 RES.METAL FILM RC-02H 1% 1K96 5322 117 10539 R8891 RES.CHIP RC-02H 1% 1K47 4822 051 51472 R8892 RES.METAL FILM RC-02H 1% 1K96 5322 117 10539 R8892 RES.CHIP...
Page 380 5.8 - 80 UNIT DESCRIPTIONS Item Description Ordering code SEMICONDUCTORS V8001 TRANSISTOR,CHIP BC848C PEL 5322 130 42136 V8002 TRANSISTOR,CHIP BC848C PEL 5322 130 42136 V8003 TRANSISTOR,CHIP BC848C PEL 5322 130 42136 V8004 TRANSISTOR,CHIP BC848C PEL 5322 130 42136 V8006 TRANSISTOR,CHIP BC858C PEL 4822 130 42513 V8007...
Page 381 UNIT DESCRIPTIONS 5.8 - 81 Item Description Ordering code V8066 TRANSISTOR,CHIP BF579 TEL 5322 130 63453 V8067 TRANSISTOR,CHIP BF579 TEL 5322 130 63453 V8068 TRANSISTOR,CHIP BF579 TEL 5322 130 63453 V8069 TRANSISTOR,CHIP BF579 TEL 5322 130 63453 V8071 TRANSISTOR,CHIP BF579 TEL 5322 130 63453 V8074 TRANSISTOR,CHIP...
Page 382 5.8 - 82 UNIT DESCRIPTIONS Item Description Ordering code V8135 TRANSISTOR,CHIP BSS83 PEL 5322 130 60502 V8136 TRANSISTOR,CHIP BF512 PEL 5322 130 44875 V8137 INTEGR.CIRCUIT NPDS5911 NSC 5322 209 31301 V8138 TRANSISTOR,CHIP BF579 TEL 5322 130 63453 V8139 TRANSISTOR,CHIP BF579 TEL 5322 130 63453 V8140 TRANSISTOR,CHIP...
Page 383 UNIT DESCRIPTIONS 5.8 - 83 Item Description Ordering code V8221 DIODE,CHIP BAT17 PEL 5322 130 31544 V8222 DIODE,CHIP BAT17 PEL 5322 130 31544 V8223 DIODE,CHIP BAT17 PEL 5322 130 31544 V8224 DIODE,CHIP BAT17 PEL 5322 130 31544 X8001 HOLD,OBJECTIVE CONTACTPIN 5322 268 14141 X8001 SOCKET,MALE...
Page 384 5.8 - 84 UNIT DESCRIPTIONS Item Description Ordering code...
Page 385 UNIT DESCRIPTIONS 5.9 - 1 RESERVED FOR FUTURE EXTENSIONS...
Page 386 5.9 - 2 UNIT DESCRIPTIONS...
Page 387 UNIT DESCRIPTIONS 5.10 - 1 5.10 CONNECTOR BOARD A10 5.10.1 Unit lay-out Lay-out 1 - lay-out of connector board A10...
Page 388 5.10 - 2 UNIT DESCRIPTIONS...
Page 389 UNIT DESCRIPTIONS 5.10 - 3 5.10.2 Circuit diagrams A10 - Diagram 1; Connectors to unit A1, A2 A3 and A6...
Page 390 5.10 - 4 UNIT DESCRIPTIONS A10 - Diagram 2; Connectors to unit A4, A9, trace rotation and illumination...
Page 391 UNIT DECRIPTIONS 5.10 - 5 Item Description Ordering code 5.10.3 Parts list CONNECTORS X 1001 CONNECTOR 50-P DBL STRGHT 5322 265 61242 X 1002 CONNECTOR 50-P DBL STRGHT 5322 265 61242 X 1003 CONNECTOR 96-P 2.54MM 5322 267 51108 X 1004 CONNECTOR P 1.25MM STR 5322 267 60311...
Page 392 5.10 - 6 UNIT DECRIPTIONS Item Description Ordering code...
Page 393 UNIT DESCRIPTION 5.11 - 1 5.11 FACTORY INSTALLED OPTIONS 5.11.1 IEEE-OPTION This option enables the oscilloscope to be controlled by an IEEE-system using the SCPI protocol (SCPI = Standard Commands for Programmable Instruments). The IEEE connector is located at the rear panel of the oscilloscope.
Page 394 5.11 - 2 UNIT DESCRIPTION Item Description Service ord code R 1001 12k1/1% 4822 051 51213 R 1002 1k1/1% 4822 051 51102 R 1003 1k/1% 4822 051 51002 R 1004 51E1/1% 5322 111 91893 R 1005 1L/1% 4822 051 10102 R 1006 5k11/1% 4822 051 55112...
Page 395 UNIT DESCRIPTION 5.11 - 3 Fig. 1. Location of options Y-out and external trigger...
Page 396 5.11 - 4 UNIT DESCRIPTION Fig. 2. Printed circuit board lay-out of Y-out unit...
Page 397 UNIT DESCRIPTIONS 5.11 - 5 Fig. 3. Circuit diagram of Y-out unit...
Page 398 5.11 - 6 UNIT DESCRIPTIONS...
Page 399 UNIT DESCRIPTION 5.11 - 7 5.11.3 EXTERNAL TRIGGER OPTION Introduction The External Trigger Input option provides an extra input at the rear of the oscilloscope. This input can be used as the trigger source for the Main Time Base (MTB). The option is factory-installable only. The external trigger requires a small printed circuit board, a rear panel BNC socket and a coaxial interconnection cable.
Page 400 5.11 - 8 UNIT DESCRIPTION Item Description Service ord code Parts list C 1001 33pF/500V 4822 122 31202 C 2082 47uF/25V 4822 124 20699 C 2091 47uF/25V 4822 124 20699 C 2001 68pF/63V 4822 126 13694 C 2003 100nF/63V 4822 122 33496 C 2004 100nF/63V 4822 122 33496...
Page 401 UNIT DESCRIPTIONS 5.11 - 9 Fig. 4. Printed circuit board lay-out of external trigger unit...
Page 402 5.11 - 10 UNIT DESCRIPTIONS Fig. 5. Printed circuit board lay-out of external trigger unit...
Page 403: Performance Test
PERFORMANCE TEST 6 - 1 PERFORMANCE TEST GENERAL INFORMATION WARNING: Before turning on the instrument, ensure that it has been installed in accordance with the Installation Instructions, outlined in Section 2 of the Operation Guide. This procedure is intended to: Check the instrument’s specification.
Page 404: Recommended Test Equipment
PERFORMANCE TEST RECOMMENDED TEST EQUIPMENT Note: The FLUKE 5500A has to be equipped with the SCOPE option and is always used in SCOPE mode (SCOPE button active). Note: The digital multimeter and oscilloscope are not required for this test. they are used for corrective maintenance.
Page 405: Power Supply
PERFORMANCE TEST 6 - 3 TEST PROCEDURE 6.3.1 Preliminary settings Test equipment: None Settings/procedure and requirements: If not present install 2 penlight (LR6) back up batteries in the holder at the rear panel of the oscilloscope. Turn on the oscilloscope under test. Press the STATUS and TEXT OFF keys simultaneously.
Page 406: Auto Set
Auto set This test checks the correct working of the AUTOSET function. Test equipment: Fluke 5500A mode levsine (Alternative: Constant amplitude sine wave generator SG 503). Test set-up: Settings/procedure: Apply a 10 MHz sine wave signal of 600 mV (pp into 50Ω) to input CH1;.
Page 407: Orthogonality
Orthogonality This test checks the angle between the horizontal and vertical deflection plates (orthogonality). Test equipment: Fluke 5500A mode wavegen, wave sine (Alternative: function generator PM5136). Test set up: Settings/procedure: Press the CAL key for a few seconds to start the autocal procedure. This takes approximately 4 minutes.
Page 408: Trace Distortion
Verify that the deviation from the ideal straight line does not exceed 0.03 divisions in the center of screen and 0.1 divisions elsewhere. Test equipment: Fluke 5500A mode: wavegen, wave sine (Alternative: function generator PM5136). Test set-up: Settings/procedure: Apply a 50 Hz sine wave signal of 8V (pp) to input CH1;...
Page 409: Vertical Deflection; Deflection Coefficients
PM3370B/80B/90B: the channels CH1, CH2 and TRIG VIEW via input EXT TRIG are checked. Test equipment: Fluke 5500A mode: volt (Alternative: Square-wave calibration generator PG 506). Test set up: Settings/procedure: Apply a 1 kHz square-wave signal of 30 mV to input CH1. Set the generator in ’volt’ mode. The generator must not be terminated with 50Ω...
Page 410: Vertical Deflection; Variable Gain Control Range (Continuation Of 6.3.6)
6 - 8 PERFORMANCE TEST table II. Input voltage Setting Requirements Requirements (pp) analog mode digital mode 0.6V 0.1V 5.82...6.18 div (±3%) 5.82...6.18 (±3%) 5.82...6.18 div (±3%) 5.82...6.18 (±3%) Press the ANALOG key (’DIGITAL MODE’ is displayed briefly), and repeat the tests in this chapter for the digital mode.
Page 411: Vertical Cursor Accuracy (Continuation Of 6.3.8.)
6.3.10 Vertical deflection; high-frequency response This test verifies the upper transition point of the vertical bandwidth. Test equipment: Fluke 5500A mode: levsine (Alternative: constant amplitude sine wave generator SG 503). Test set-up: Settings/procedure: Apply a 50 kHz sine wave signal of 600 mV (pp into 50Ω) to input CH1, and press the AUTOSET key.
Page 412: Vertical Deflection; Low-Frequency Response
6.3.11 Vertical deflection; low-frequency response This test verifies the lower transition point of the vertical bandwidth. Test equipment: Fluke 5500A mode: wavegen, wave sine (Alternative: function generator PM5136). Test set up: Settings/procedure: Apply a 5 kHz sine wave signal of 600 mV (pp into 50Ω) to input CH1, and press the AUTOSET key.
Page 413: Vertical Deflection; Dynamic Range At 15/25/50 Mhz
24 divisions must be displayed with no distortion. Test equipment: Fluke 5500A mode: levsine (Alternative: constant amplitude sine wave generator SG 503). Test set up: Settings/procedure: Apply a 50 MHz (PM3390B/94B), 25 MHz (PM3380B/84B) or 15 MHz (PM3370B) sine wave signal of 2.4 V(pp into 50Ω) to input CH1 and press the AUTOSET key.
Page 414: Vertical Deflection; Position Range
6.3.15 Vertical deflection; crosstalk between channels at 60/100/200 MHz At higher frequencies there exists some crosstalk between any two channels. In the following test, crosstalk is verified at a high frequency. Test equipment: Fluke 5500A mode: levsine (Alternative constant amplitude sine wave generator SG 503).
Page 415: Vertical Deflection; Common Mode Rejection Ratio At 1 Mhz
6.3.16 Vertical deflection; common mode rejection ratio at 1 MHz The common mode rejection ratio (CMRR) is a measure of susceptibility to common mode signals. This susceptibility is verified in this test. Test equipment: Fluke 5500A mode: levsine (Alternative: HF constant amplitude sine wave generator SG 503) Power splitter...
Page 416 6 - 14 PERFORMANCE TEST Test set up: Settings/procedure: Use a power splitter and two cables of equal length to CH1 and CH2. Apply a 2 MHz sine-wave signal of 1.6 V(pp into 50Ω) to inputs CH1 and CH2. Press the AUTOSET key. Use 50Ω...
Page 417: Vertical Deflection; Lf Linearity
The linearity of the vertical amplifier is checked by moving a signal with a fixed amplitude vertically over the entire screen area. Test equipment Fluke 5500A mode: wavegen, wagve square (Alternative: function generator PM5136). Test set up: Settings/procedure Apply a 50 kHz square-wave signal of 200 mV(pp into 50Ω)to input CH1.
Page 418 6 - 16 PERFORMANCE TEST Test set-up: Settings/procedure: Apply a signal with a fast rise time of less than 1 ns and an amplitude of 0.5V (into 50Ω), and a frequency of 1 MHz, to input CH1. Press the AUTOSET button and set CH1 to 0.1V/div. Use a 50Ω...
Page 419: Vertical Deflection; Base Line Instability
For PM3390B, PM3380B and PM3370B no further steps required. 6.3.21 Delay difference between vertical channels The delay difference between CH1, CH2, CH3, and CH4 is checked here. Test equipment: Fluke 5500A mode: edge (Alternative: Square wave calibration generator PG 506). Power splitter Test set up:...
Page 420 6 - 18 PERFORMANCE TEST Settings/procedure: Apply a square-wave signal with a fast rise time of less than 1 ns, and an amplitude of 1V (into 50Ω), with a frequency of 1 MHz, to inputs CH1 and CH2. Use a power splitter and two cables of equal length to CH1 and CH2. Press the AUTOSET key.
Page 421: Horizontal Deflection; Display Modes And Trace Separation
The correct working of main timebase (MAIN TB), delayed timebase (DELAYED TIME BASE) and the trace separation is checked. Test equipment: Fluke 5500A mode: wavegen, wave sine (Alternative: function generator, PM5136). Test set-up: Settings/procedure and requirements: Apply a 2 kHz sine-wave signal of 400 mV(pp into 50Ω) to input CH1.
Page 422: Horizontal Deflection; X Deflection
6.3.23 Horizontal deflection; X deflection The correct working of the X Y mode (X-DEFL ’on’) is tested. Test equipment: Fluke 5500A mode: wavegen, wave sine (Alternative: function generator, PM5136) Test set-up: Settings/procedure: Apply a 2 kHz sine-wave signal of 800 mV (pp) to input CH1.
Page 423: Horizontal Deflection; Main Tb Deflection Coefficients
The deflection coefficients of the main timebase generator (MAIN TB) are verified by means of a calibration signal. Test equipment: Fluke 5500A mode: marker (Alternative: time marker generator TG 501). Test set-up: Settings/procedure: Apply a 50.0 ns time marker signal to input CH1.
Page 424: Horizontal Deflection; Variable Mode Accuracy Main Tb
The horizontal MAIN TB deflection coefficients can be varied in steps such as done in 6.3.24. A range of much finer steps can also be selected. Here, the accuracy of this range is checked. Test equipment: Fluke 5500A mode: marker (Alternative time marker generator TG 501).
Page 425: Time Cursor Accuracy (Continuation Of 6.3.25)
PERFORMANCE TEST 6 - 23 Test set-up: Settings/procedure: Apply a 5 us time marker signal to input CH1. Press the AUTOSET key. Use a 50Ω termination. For instruments with switchable 50Ω input impedance it is recommended to make use of this feature. Press the TRIGGER menu key.
Page 426: Horizontal Deflection; Delayed Time Base Deflection Coefficients
The deflection coefficients of the delayed timebase generator (DEL’D TB) are verified by means of a calibration signal. Test equipment: Fluke 5500A mode: marker (Alternative: time marker generator TG 501). Test set-up: Settings/procedure: Apply a 0.5 ms time marker signal to input CH1.
Page 427: Horizontal Deflection; Delay Time Multiplier
PERFORMANCE TEST 6 - 25 Requirements for analog mode MAGNIFY off ( DEL’D TB setting MAIN TB setting Marker pulse Max. error 500 µs 500 µs 0.5 ms 1.8% 20.0 µs 20.0 µs 20 µs 1.8% 5.00 µs 5.00 µs 5 µs 1.8% 1.00 µs...
Page 428: Horizontal Deflection; Delayed Timebase Jitter
Verify that the jitter of the DEL’D TB is not more than 0.4 divisions (1 part per 25000). 6.3.30 Horizontal deflection; X deflection coefficient via CH1 The amplification of the horizontal amplifier via the vertical input amplifier is checked. Test equipment: Fluke 5500A mode: volt (Alternative: Square-wave calibration generator PG 506).
Page 429: Horizontal Deflection; X Deflection Coefficient Via 'Line'
PERFORMANCE TEST 6 - 27 Test set-up: Settings/procedure: Apply a 1 kHz square-wave signal of 0.1V to input CH1. Output not terminated into 50Ω (’LZ’ must not appear in lower part of viewing area). Press the AUTOSET key. Set CH1 to 20 mV and DC coupled input. Press the DISPLAY menu key.
Page 430: Horizontal Deflection; High Frequency Response
6.3.32 Horizontal deflection; high frequency response In this test, the bandwidth of the horizontal amplifier is checked. Test equipment: Fluke 5500A mode: levsine (Alternative: constant amplitude sine wave generator SG 503). Test set-up: Settings/procedure: Apply a 50 kHz sine-wave signal of 30 mV(pp into 50Ω) to input CH1.
Page 431 PERFORMANCE TEST 6 - 29 Test set-up: Settings/procedure: Apply a 2 kHz sine-wave signal of 1.2 V(pp into 50Ω) to CH1. Press the AUTOSET key and set CH1 to 0.2V/div. Adjust the generator to a trace height of exactly 6 divisions. Press the DISPLAY menu key and then press the X-DEFL softkey.
Page 432: Trigger Sensitivity Via Ch1, Ch2, Ch3 And Ch4 (Ext)
CH1, CH2, CH3 and CH4 inputs is checked. For the PM3390B, this is checked for CH1, CH2 and EXTernal TRIGger input. Test equipment: Fluke 5500A mode: levsine (Alternative: constant amplitude sine wave generators SG 503 + SG 504). Test set-up: Settings/procedure and requirements: Apply a 100 MHz sine-wave signal of 1 V(pp into 50Ω) from the SG 503 to input CH1.
Page 433: Trigger Sensitivity Via Ch1, Ch2, Ch3 And Ch4 (Ext)
PM3380B, this is checked for CH1, CH2 and the EXTernal TRIGger input. For PM3370B; frequency setting between (). Test equipment. Fluke 5500A mode: levsine (Alternative: constant amplitude sine wave generator (SG 503) Test set-up: Settings/procedure and requirements: Apply a 50 MHz (30 MHz) sine-wave signal of 1 V(pp into 50Ω) to input CH1.
Page 434: Main Tb/Del'd Tb Triggering; Trigger Sensitivity Tvl-Tvf
CH1, CH2, CH3 and CH4 inputs is checked. For the PM3390B, this is checked for CH1, CH2 and the EXTernal TRIGger input. Test equipment: Fluke 5500A mode: levsine (Alternative: constant amplitude sine wave generators SG 503 + SG 504).
Page 435 PERFORMANCE TEST 6 - 33 Test set-up: Settings/procedure and requirements: Apply a 100 MHz sine-wave signal of 1 V(pp into 50Ω) from the SG 503 to input CH1. Press the AUTOSET key and set CH1 to 0.5V/div. Use a 50Ω termination. For instruments with switchable 50Ω input impedance it is recommended to make use of this feature (via VERT MENU KEY).
Page 436: Trigger Sensitivity Via Ch1, Ch2, Ch3 And Ch4 (Ext)
PM3370B/80B, this is checked for CH1, CH2 and the EXTernal TRIGger input. For PM3370B; frequency setting between (). Test equipment: Fluke 5500A mode: levsine (Alternative: constant amplitude sine wave generator SG 503) Test set-up: Settings/procedure and requirements: Apply a 50 MHz (30 MHz) sine-wave signal of 1 V(pp into 50Ω) from the SG 503 to input CH1.
Page 437: Trigger Sensitivity In Logic Mode Pm3394B
In this test, the trigger sensitivity is tested with a sine wave via the CH1, CH2, CH3, and CH4 inputs. Test equipment: Fluke 5500A mode: levsine (Alternative: constant amplitude sine wave generator SG 503). Test setup: Press the ANALOG key (’DIGITAL MODE’ is displayed briefly) to activate the digital mode.
Page 438: Trigger Sensitivity In Logic Mode Pm3384B
In this test, the trigger sensitivity is tested with a sine wave via the CH1, CH2, CH3, and CH4 inputs. Test equipment: Fluke 5500A mode: levsine: (Alternative: constant amplitude sine wave generator SG 503). Test setup: Press the ANALOG key (’DIGITAL MODE’ is displayed briefly) to activate the digital mode.
Page 439: Z-Mod Sensitivity
6 - 37 6.3.41 Z-MOD sensitivity This test checks the sensitivity of the Z modulation facility. Test equipment: Fluke 5500A mode: wavegen, wave square (Alternative: function generator PM 5136). T-piece. Test set-up: Settings/procedure and requirements: Apply a 1 kHz square-wave signal, duty cycle 50%, amplitude between 0 to +2.5V, to input CH1.
Page 440: Probe Adjust Signal; Frequency And Output Voltage
6 - 38 PERFORMANCE TEST 6.3.42 Probe Adjust signal; frequency and output voltage The Probe Adjust signal is a calibration signal with fixed frequency and voltage. In this test, the values of frequency and voltage are checked. Test equipment: None Test set-up: OSCILLOSCOPE UNDER TEST Probe...
Page 441: Auto Range Functions
The AUTO RANGE function of the main time base (MAIN TB) adjusts the time base automatically so that approximately 2 to 6 waveform periods are displayed. Test equipment: Fluke 5500A mode: wavegen, wave sine (Alternative: function generator, PM5136) Settings/procedure: Apply a 50kHz sine-wave signal of 2 V(pp) to CH1.
Page 442: Testing The Optional Auxiliary Outputs
6 - 40 PERFORMANCE TEST 6.3.44 Testing the optional auxiliary outputs MTB-GATE and DTB-GATE outputs. Test equipment: measuring oscilloscope. Test set up: Settings/procedure: Oscilloscope under test: Take care that no input signal is applied to the oscilloscope inputs. Press the STATUS and TEXT OFF keys simultaneously. This assures that the oscilloscope occupies its default position.
Page 443 PERFORMANCE TEST 6 - 41 Y-OUTput signal. Test equipment: Fluke 5500A mode: levsine (Alternative: constant amplitude sine-wave generator SG503). Test set up: Settings/procedure: Apply a 50 kHz sine-wave signal of 600 mV (pp into 50Ω) to input CH1 and press the green AUTOSET key.
Page 444 6 - 42 PERFORMANCE TEST EXT TRIGger input. Test equipment: Fluke 5500A mode: levsine (Alternative: constant amplitude sine-wave generator SG503). Power splitter. Test set up: Settings/procedure: Use a power splitter and two coaxial 50Ω cables to apply the generator output signal to input CH1 and the rear panel input ‘EXT TRIG’.
Page 445: Calibration Adjustment Procedure
CALIBRATION ADJUSTMENT PROCEDURE 7 - 1 CALIBRATION ADJUSTMENT PROCEDURE INTRODUCTION The calibration adjustment procedure can be split up in two: Manual adjustment Automatic calibration (AUTOCAL). All calibration is done with the oscilloscope’s cabinet closed. This eliminates calibration inaccuracies due to temperature changes. Manual calibration data are protected by a keyword and a seal and must be changed by qualified personnel only.
Page 446: Trace Rotation
7 - 2 CALIBRATION ADJUSTMENT PROCEDURE TRACE ROTATION Press the ANALOG key (message ANALOG MODE appears briefly) and the oscilloscope switches to analog mode. Adjust the INTENS TRACE rotary for a well-visible horizontal on the screen. Align the CH1 trace exactly in parallel with the horizontal graticule lines using screw-driver operated TRACE ROT rotary.
Page 447: Horizontal Gain And Offset (Vector)
CALIBRATION ADJUSTMENT PROCEDURE 7 - 3 HORIZONTAL GAIN AND OFFSET (VECTOR) Push the second softkey again to obtain ’x-gain’ (menu header is changed into UTIL SCREEN CALIBR VECTOR). Adjust the TRACK rotary to minimal over- or undershoot in horizontal direction. Select ’x-offs’...
Page 448: Lf Square-Wave Response Ch1
7 - 4 CALIBRATION ADJUSTMENT PROCEDURE 7.11 LF SQUARE-WAVE RESPONSE CH1 Press the STATUS and TEXT OFF keys simultaneously: this gives a defined position of the instrument settings. Select the key sequence UTILITY > MAINTENANCE > MANUAL CALIBR. Select ’lf ch1’ with the TRACK rotary. Select ’lfx100’...
Page 449: Lf Square-Wave Response Ch2
CALIBRATION ADJUSTMENT PROCEDURE 7 - 5 7.12 LF SQUARE-WAVE RESPONSE CH2 Select ’lf ch2’ with the TRACK rotary. Select ’lfx100’ with the softkeys: the ∆ sign is displayed behind ’lfx100’. Switch CH2 to ON and CH1 off. Press the TRIG 2 key. Put CH2 in 1 V/div with DC coupled input.
Page 450: Lf Square-Wave Response Ch4 And Ext Trig
7 - 6 CALIBRATION ADJUSTMENT PROCEDURE 7.14 LF SQUARE-WAVE RESPONSE CH4 and EXT TRIG For PM3370A, PM3380A, PM3382A, PM3390A and PM3392A only the step ’lfx10’ has to be adjusted. Select ’lf ch4’ with the TRACK rotary. Select ’lfx100’ with the softkeys: the ∆ sign is displayed behind ’lfx100’. Switch CH4 to ON and CH3 off.
Page 451: Hf Square-Wave Response Final Y Amplifier
CALIBRATION ADJUSTMENT PROCEDURE 7 - 7 7.15 HF SQUARE-WAVE RESPONSE FINAL Y AMPLIFIER Apply a 1V/1 MHz square-wave signal with a rise-time faster than 1 nsec to CH1. This signal is delivered in the ’edge’ mode of the calibrator. As an alternative you may use the fast-rise output of the square-wave calibration generator.
Page 452: Hf Response Dso Mode
7 - 8 CALIBRATION ADJUSTMENT PROCEDURE 7.16 HF RESPONSE DSO MODE Press the ANALOG key (message DIGITAL MODE appears briefly) and the oscilloscope switches to digital mode. Apply a 1V/1 MHz square-wave signal with a rise-time faster than 1 nsec to CH1. This signal is delivered in the ’edge’mode of the calibrator.
Page 453: Trigger Delay Adjustment
CALIBRATION ADJUSTMENT PROCEDURE 7 - 9 7.17 TRIGGER DELAY ADJUSTMENT For PM3390A, PM3380A and PM3370A the ’logic’ and ’state’ adjustment can be skipped. Apply a 1V/1 MHz square-wave signal with a rise-time faster than 1 nsec to CH1. This signal is delivered in the ’edge’mode of the calibrator.
Page 454: Saving The Calibration Data
7 - 10 CALIBRATION ADJUSTMENT PROCEDURE 7.18 SAVING THE CALIBRATION DATA If you are sure that the instrument is well calibrated, the calibration data must be saved. For this proceed as follows: Press softkey RETURN. If present, remove the calibration sticker from the pin hole. Press softkey ’save calibr data’.
Page 455: Corrective Maintenance Procedures
CORRECTIVE MAINTENANCE PROCEDURES 8 - 1 CORRECTIVE MAINTENANCE PROCEDURES DISMANTLING THE INSTRUMENT 8.1.1 General information This section contains the dismantling procedures required for the removal and testing of components during repair. All circuit boards removed from the instrument must be adequately protected against damage, and all normal precautions regarding the use of tools must be observed.
Page 456 8.2.1 Standard parts Electrical and mechanical replacement parts can be obtained through your local PHILIPS/FLUKE organization or representative. However, many of the standard electronic components can be obtained from other local suppliers. Before purchasing or ordering replacement parts, check the parts list for value, tolerance, rating and description.
Page 457: Soldering Techniques
CORRECTIVE MAINTENANCE PROCEDURES 8 - 3 SOLDERING TECHNIQUES 8.4.1 General soldering techniques Working method: Carefully unsolder the soldering tags of a semi-conductor one after the other. Remove all superfluous soldering material. Use desolder braided wire; ordering code: 4822 321 40042. Check that the leads of the replacement part are clean and pre-tinned on the soldering places.
Page 458: Removing The Units, Mechanical Parts And Crt
8 - 4 CORRECTIVE MAINTENANCE PROCEDURES REMOVING THE UNITS, MECHANICAL PARTS AND CRT NOTE: For installation, reverse the sequence. 8.5.1 Removing the rotary knobs Rotary knobs can be removed by simply pulling them off. The knobs have an integrated shaft and fixing device.
Page 459: Removal Of Signal Unit A1
CORRECTIVE MAINTENANCE PROCEDURES 8 - 5 8.5.3 Removal of signal unit A1 Remove 3 screws with washers that fix the printed circuit board to the chassis plate. Remove 1 long screw that fixes (and grounds) the screen of the input attenuators to the chassis plate.
Page 460: Removal Of Final Xyz Amplifier Unit A2
8 - 6 CORRECTIVE MAINTENANCE PROCEDURES 8.5.4 Removal of Final XYZ amplifier unit A2 ATTENTION: On the XYZ unit there are parts that carry high voltages. If working on the unit under live condition cannot be avoided, it must be done by a qualified technician who is aware of the dangers involved.
Page 461: Removal Of Unit At Socket Of Crt
CORRECTIVE MAINTENANCE PROCEDURES 8 - 7 8.5.5 Removal of unit at socket of CRT WARNING: On this unit there are parts that carry dangerous high voltages (-2.2 kV). Some of these voltages remain some time after disconnecting the instrument from the mains.
Page 462: Removal Of The Units In The Front Frame (A4, A5)
8 - 8 CORRECTIVE MAINTENANCE PROCEDURES 8.5.8 Removal of the units in the front frame (A4, A5) The plastic front frame incorporates the Front unit A4 and the CRT controls unit A5. The frame can be removed from the chassis by bending out four clamping lips. Before doing so unlock the ribbon cable at the connector board.
Page 463: Removal Of Digitizer Unit A8
CORRECTIVE MAINTENANCE PROCEDURES 8 - 9 NOTE: The power supply unit can be measured under working conditions, by using the extension board with ordering code 5322 218 61479. On this board there is a jumper that can be removed to switch off the EHT- converter. For safety reasons it is strongly recommended to use this feature.
Page 464: Troubleshooting The Power Supply
8 - 10 CORRECTIVE MAINTENANCE PROCEDURES TROUBLESHOOTING THE POWER SUPPLY WARNING: On the power supply there are many parts that carry dangerous high voltages. Some of these voltages remain some time after disconnecting the unit from the mains. Therefore, it is recommended to wait at least five minutes after having disconnected the unit from the mains, before removing the unit.
Page 465: Special Tools
CORRECTIVE MAINTENANCE PROCEDURES 8 - 11 SPECIAL TOOLS 8.9.1 Extension board For test and repair purposes the units A3 and A6 can be plugged in their connectors via an extension board. This board is available under ordering number 5322 218 61479. On this board there is a jumper that can be removed to switch off the EHT-converter.
Page 466: Tests Built Into The Instrument
8 - 12 CORRECTIVE MAINTENANCE PROCEDURES 8.11 TESTS BUILT INTO THE INSTRUMENT. 8.11.1 Power-up test. After turning the oscilloscope on, power-up tests start automatically. The tests take less than a second. A message appears on the screen when errors are found. With no message displayed, the oscilloscope is ready for use.
Page 467 CORRECTIVE MAINTENANCE PROCEDURES 8 - 13 Figure 8.3. Configuration of control part under direct control of microprocessor...
Page 468 8 - 14 CORRECTIVE MAINTENANCE PROCEDURES...
Page 469: Selftests
CORRECTIVE MAINTENANCE PROCEDURES 8 - 15 8.11.3 SELFTESTS Under the softkey ’SELFTEST’ it is possible to run tests for the microprocessor and digitizer units. With a toggle softkey, selection is possible between ’test-all’ and ’specific’. A test is started with softkey ’start’. A test that is being executed can be interrupted with softkey ’abort’.
Page 470 8 - 16 CORRECTIVE MAINTENANCE PROCEDURES DARLIC (Data Acquisition and tRigger Logic IC) Main function(s) of DARLIC (D8027) are data path (speed conversion, transfer from FAM to MAM) and trigger engine (start/stop acquisition, pre/posttriggering, delta-t counter, timed pattern mode). During the DARLIC test 2 bitpatterns (FF hex and 00 hex) are send to a register inside D8027. Then they are read and verified.
Page 471: Repair Tools
CORRECTIVE MAINTENANCE PROCEDURES 8 - 17 8.11.4 Repair tools 8.11.4.1 General Under the softkey ’REPAIR TOOLS’, tests can be selected concerning the exchange of information in the area around the microprocessor and digitizer unit A8: Data exchange between keys/rotaries and microprocessor. Data exchange between microprocessor and the devices that control the oscilloscope circuits.
Page 472 8 - 18 CORRECTIVE MAINTENANCE PROCEDURES 8.11.4.3 Repair tools / I C bus This test displays the data (SDA) that is send by the microprocessor to a number of addressable devices. Synchronization is achieved via SCL. Each data block sent by the microprocessor is preceeded by an address on which the device can respond.
Page 473 CORRECTIVE MAINTENANCE PROCEDURES 8 - 19 8.11.4.5 Repair tools / hef To control simple on/off functions there are 7 buffers (of the type HEF4094) on unit A1: this structure is called the ’HEF-bus’. Each buffer has 8 outputs as shown in the figure. The buffers are divided into 2 groups: group 0 consists of 2 buffers and group 1 consists of 5 buffers.
Page 474 8 - 20 CORRECTIVE MAINTENANCE PROCEDURES The configuration is shown in the table: Enable signal Buffer Name of circuit diagram DLEN0-HT D9001 Control circuits DLEN1-HT D9002 Control circuits DLEN2-HT D9006 Main time base The data representation for D9006 is ’0:ABCD’. Each character represents the hexadecimal (16 possible states) information for 4 outputs.
Page 475 CORRECTIVE MAINTENANCE PROCEDURES 8 - 21 For N1001 and N2002 (unit A2) refer to the table below: Name/function of generated signal: value number N1001 N2002 LF sq. wave ASTDR LF sq. wave DARK Gain XHFADJ HF sq. wave XTRAGC Offset XCRTGCL Offset XCRTGCH...
Page 476 8 - 22 CORRECTIVE MAINTENANCE PROCEDURES...
Page 477: Safety Inspection And Tests After Repair And Maintenance In The Primary Circuit
SAFETY INSPECTION AND TESTS 9 - 1 SAFETY INSPECTION AND TESTS AFTER REPAIR AND MAINTENANCE IN THE PRIMARY CIRCUIT GENERAL DIRECTIONS Take care that the creepage distances and clearances have not been reduced. Before soldering, bend the wires through the holes of the solder leads, or wrap the wires around the leads in the form of an open U, or, maintain wiring ridigity by cable clamps or cable lacing.
Page 478 9 - 2 SAFETY INSPECTION AND TESTS...

This manual is also suitable for:

Autoranging combiscope pm3390b Autoranging combiscope pm3384b Autoranging combiscope pm3380b Autoranging combiscope pm3394b

Fluke Autoranging CombiScope PM3370B Service Manual

1 Safety Instructions

2 Characteristics

3 Descriptions

4 Parts

5 Unit Descriptions

Quick Links

Related Manuals for Fluke Autoranging CombiScope PM3370B

Summary of Contents for Fluke Autoranging CombiScope PM3370B

This manual is also suitable for:

Table of Contents
