4. Build your user database by filling in the following fields for each user.
User Name
The User Name can have as many as 39 characters. All printable characters are permitted with
the restriction that no blanks are allowed in the user name. In dial-in and dial-out applications, the
user name is treated as a case insensitive string.
User Password
The User Password can have as many as 7 characters. In places where the password is used as
a character string, it is treated as a case insensitive string. Elsewhere (PPPs CHAP), it is treated
as a case sensitive pattern.
Filter
The drop-down list enables you to select the unique filter entry that was defined in the ID field in
the Add/Edit Filters dialog box. This filter ID must be a unique alphanumeric identifier of up to 9
characters in length that identifies the remote user.
Call Back
You have to click this check box to enable the Call Back function. If the user is at a location where
he wants to be called at then he must be allowed to choose the specific location where he wants
to be called back at. To do this, the Call Back option must be enabled (activated) and the Call
Back Security Enabled option must NOT be enabled (activated). The remote user would then use
a standard PPP client or ASCII terminal dial-in.
To enable Call Back Security, the Call Back option must be checked (activated) and the following
three boxes/fields filled in.
• Call Back Security Enabled
This parameter is of use in dial-in applications where the user must always be called back at
a specific location. Enabling this parameter (Alt-S) results in having the administrator
assigning the call back parameters. Leave this function disabled if the user is to be allowed to
choose the call back number and the call back delay.
• Call Back Number
The Call Back Number is editable only if Call Back Security is enabled (checked). This is the
number where the user will be called back. The user cannot choose the location where he
wants to be called back.
Note: You can enter the Call Back Number with or without dashes, the modem will simply
ignore them.
• Call Back Delay
Call Back Delay is editable only if Call Back Security is enabled. This specifies the duration
(in seconds) after which the user will be called back at the administrator-assigned number.
Dial In Ports
The systems administrator can enable (highlight) WAN Ports 1, 2, and/or 3 to be made available
for dialing in to the RASFinder.
Dial Out Ports
The systems administrator can enable (highlight) WAN Ports 1, 2, and/or 3 to be made available
for dialing out from the RASFinder.
Click the Rights button to assign user permissions for the remote user.
