Multitech MTS2EA Quick Start Manual
Serial-to-serial device server and serial-to-ethernet device server
Hide thumbs
Also See for MTS2EA:
- Specification sheet (2 pages) ,
- Reference manual (7 pages) ,
- User manual (23 pages)
Related Manuals for Multitech MTS2EA
Summary of Contents for Multitech MTS2EA
- Page 1 ™ MultiConnect ™ MultiConnect Serial-to-Serial Device Server Serial-to-Ethernet Device Server Quick Start Guide...
- Page 2 Furthermore, Multi-Tech Systems, Inc. reserves the right to revise this publication from time to time in the content hereof without obligation of Multi-Tech Systems, Inc. to notify any person or organization of such revisions or changes. Revision...
- Page 3 Package Contents • One MultiConnect Device Server • One universal power supply with power cord included (Included with the MTS2SA-T build and the MTS2EA build) • One RS-232 cable • One mounting bracket • Four adhesive-backed rubber feet (table-top mounting) •...
- Page 4 15/16 inches center-to-center. To attach the brackets to the MultiConnect, slide the mounting brackets into the corresponding slots on the back of the MultiConnect chassis. Attach the device to the surface with two screws. Multi-Tech Systems, Inc. Quick Start Guide...
- Page 5 Serial-to-Serial Power Supply Connection: MultiConnects are powered in one of two ways: Powered by External Power Supply RS-232 Power (Pin 6) MTS2SA-T MTS2SA-T-R RS-232 Connector RS-232 Connector RS-232 & External Power Connectors RS-232 Power Pin Connector Multi-Tech Systems, Inc. Quick Start Guide...
- Page 6 Serial-to-Ethernet Power Connections Powered in one of two ways: Powered by External Power Supply MTS2EA Adapter Ethernet Connector Adapter Ethernet Connector RS-232 & External Power Connectors Multi-Tech Systems, Inc. Quick Start Guide RS-232 Power (Pin 6) MTS2EA-R RS-232 Power Pin Connector...
- Page 7 Pin 3 TX Pin 4 DTR Pin 5 GND Pin 6 DSR Pin 7 RTS Pin 8 CTS Pin 9 RI Multi-Tech Systems, Inc. Quick Start Guide MultiConnect Adapters With RS-232 Power Through Pin 6 Signal Pin 1 CD Pin 2 TX...
- Page 8 Two Ways to Login Login Using Telnet Client • Use Telnet Client to configure the MultiConnect for the first time. Type the default IP address of the Device Server: 192.168.2.1. Note: The workstation must be on the same subnet. • At the Login prompt, type admin. At the Password prompt, type admin.
