Wireless Description

1 Wireless network protocols supported
2 Frequency bands of transmission / reception
3 Preferred frequency or frequency band
4 Bandwidth(s) supported
5 FCC EIRP of 2.4GHz Wi-Fi
6 FCC EIRP of 5.0GHz Wi-Fi
7 FCC EIRP of Bluetooth Low-Energy
8 ETSI EIRP of 2.4GHz Wi-Fi
9 ETSI EIRP of 5.0GHz Wi-Fi
10 ETSI EIRP of Bluetooth Low-Energy
11 SAR
Federal Communications Commission (FCC), Effective Isotropic Radiated Power (EIRP), European
Telecommunications Standards Institute (ETSI), Specific Absorption Rate (SAR)

Principles of operation

–
Vscan Air User Manual
Direction GP092020-1EN Rev 18
Wireless communication utilizes the 2.4GHz and 5GHz (UNII-1
and UNII-3) bands supporting the IEEE 802.11a, IEEE 802.11b,
IEEE 802.11g and IEEE 802.11n protocols. The wireless module
supports bandwidths of 20MHz and 40MHz. The preferred
frequency is 5GHz, with bandwidth 40MHz.
Table 1-2: Wireless description
Medical ultrasound images are created by computer and digital
memory from the transmission and reception of mechanical
high-frequency waves applied through a probe. The mechanical
ultrasound waves spread through the body, producing an echo
where density changes occur. The echoes return to the probe
where they are converted back into electrical signals.
These echo signals are amplified and processed by several
analog and digital circuits having filters with many frequency and
time response options, transforming the high-frequency
electrical signals into a series of digital image signals which are
stored in memory. Once in memory, the image can be displayed
in real-time on the display device.
A probe is an accurate, solid-state device, providing multiple
image formats. The digital design and use of solid-state
components provides highly stable and consistent imaging
performance with minimal required maintenance.
IEEE 802.11a/b/g/n
2.4GHz and 5GHz(UNII-1 and UNII-3)
5GHz
20MHz and 40MHz
17.01 dBm
13.59 dBm
7.61 dBm
17.81dBm
14.90 dBm
7.38dBm
0.540 W/kg (SAR Limit = 1.6 W/kg - over 1g)
0.295 W/kg (SAR Limit = 2.0 W/kg - over 10g)
